Philips SPE3031CC/00 Manual de usuario

External hard disk SPE3000 series

User manual 3

Manuel d’instructions 9

Benutzerhandbuch 15

Gebruikershandleiding 21

Manual del usuario 27

Manuale utente 33

Manuel do utilizador 39

Kurulum Kılavuzu 45

4 What’s in the box?

4 How to connect?

5 How to disconnect?

5 Installation for Mac,Windows 98 and

Windows ME?

6 Important information

7 Need help?

8 FCC Compliance

Contents EN

What’s in the box?

A : External hard disk

B : Power adapter

C : Power cord

D : USB cable

E : User manual

Howto connect?

Put the Power Adapter (B) and the Power Cord (C)

together and connect them to the external harddisk

and a power outlet.

Plug the USB cable (D) in the USB port of your external

harddisk. Connect the other side of the USB cable to

an empty USB port of your computer.

Adriveicon, Philips External HardDisk, appears in

Windows Explorer and the Blue light should light up.

(Touse the newhardware, the computer sometimes

needs to be restarted)

Your hard disk is now ready to use and you can now

save and copy data, just as you do when using your

internal hard disk.

How to disconnect?

Installation

1Double-click the Safely Remove Hardware icon

in the task bar in the lower right part of the screen.

2In the window that appears, select the name of the

device that is to be removed, then click the Stop

button.

3When the Stop a hardware device screen

appears, make sure the correct information is

displayed, and then click the OK button.

4When the message Safe to remove hardware

appears, remove the drive from the computer’s

USB port.

Installation for Mac,Windows 98 and

Windows ME?

The hard disk is preconfigured for Windows 2000 and

Windows XP, with a NTFS format.

For Mac,Windows 98 and Windows ME, the hard disk

needs to be formatted to FAT32.

Important information

How to find warranty information?

Look on your external hard disk and browse to the

folder ‘Philips Warranty’.

You need Adobe Reader software to open these files.

If you don’t have Adobe Reader, you can download it for

free on www.adobe.com.

The Philips warranty may not apply if damage is caused

by accidents, shock, misuse or neglect.

“The making of unauthorized copies of copy-protected

material including computer programs, files, broadcasts

and sound recordings, may be an infringement of

copyrights and constitute a criminal offence.

This equipment should not be used for such purposes.”

WEEE mark:“Information to the Consumer”

Disposal of your old product

Your product is designed and manufactured with

high quality materials and components, which can be

recycled and reused. Please inform yourself about the

local separate collection system for electrical and

electronic products, including those marked bythe

crossed-out wheel bin symbol.

Please act according to your local rules and do not

dispose of your old products with your normal

household waste.

WARNING

Plastic bags can be dangerous.

To avoid danger of suffocation, keep this bag away from

babies and small children.

Although this product has been designed with utmost

care for long-lasting performance. Philips does advise

Need help?

you to handle electronics with good care:Avoid contact

with water, exposure to extreme forces.

Please make sure you place the device in a

well-ventilated environment, to ensure longest possible

lifetime and optimal performance.

Specifications

Capacity Depending on model

Interface Hi-Speed USB 2.0

Transfer speed 480 Mb/s

Rotational speed 7200 rpm

Cache memory 8 MB

System requirements USB 1.1 (USB 2.0 for

max. transfer speed)

Windows 2000,

Windows XP

For interactive help and support:

www.philips.com/support

For software updates and frequentlyasked questions:

www.storageupdates.philips.com

FCC Compliance

Caution:

Changes or modifications made to this equipment not

expressly approved by Philips may void the FCC

authorization to operate this equipment.

Note:

This equipment has been tested and found to comply

with the limits for a Class B digital device, pursuant to

Part 15 of the FCC Rules.These limits are designed to

provide reasonable protection against harmful

interference in a residential installation.This equipment

generates, uses and can radiate radio frequency energy

and, if not installed and used in accordance with the

instructions, may cause harmful interference to radio

communications. However, there is no guarantee that

interference will not occur in a particular installation. If

this equipment does cause harmful interference to radio

or television reception, which can be determined by

turning the equipment off and on, the user is

encouraged to try to correct the interference by one or

moreof the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and

receiver.

• Connect the equipment into an outlet on a circuit

different from that to which the receiver is

connected.

•Consult the dealer or an experienced radio/TV

technician for help.

The shielded interface cable and connectors must be

used in order to comply with the limits for digital device

pursuant to subpart B of Part15 of FCC Rules.

Table des matières

10 Contenu de l'emballage

10 Raccordement

11 Déconnexion

11 Installation pour Mac,Windows 98 et

Windows ME

12 Informations importantes

13 Aide

Contenu de l'emballage

FA : Disque dur externe

B :Adaptateur secteur

C : Cordon d'alimentation

D : Câble USB

E : Manuel d'utilisation

Raccordement

Branchez le cordon d'alimentation (C) sur l'adaptateur

secteur (B) et raccordez l'ensemble au disque dur

externe et à la prise de courant.

Branchez le câble USB (D) sur le portUSB du disque

dur externe. Raccordez l'autreextrémité du câble USB

à un portUSB libre de l'ordinateur.

Une icône de lecteur Philips External HardDisk

apparaît dans Windows Explorer. Le témoin bleu doit

également s'allumer. (Pour utiliser le nouveau matériel, il

peut êtrenécessairede réinitialiser l'ordinateur.)

Le disque dur est prêt à être utilisé.Vous pouvez donc y

enregistrer et y copier des données comme avec un

disque dur interne.
