Thank you for selecting the Philips CDC 775

Compact Disc Changer.

A Compact Disc Changer of the state-of-the-art Philips

700 series, the CDC 775 combines supreme playback

quality with a high degree of user-friendliness by

offering the following possibilities:

– able to play CD-RW disc;

– changing CDs during play;

– quick access to a particular CD by means of QUICK

PLAY;

– storing 40 tracks from different CDs in any desired

order in the changer memory;

– storing the required recording time and playing time

in the EDIT mode.

Power Supply Setting

• Check that the type plate on the rear of your changer

indicates the correct supply voltage.

• If your mains supply voltage is different, consult your

dealer or our Service Organisation.

Siting the Compact Disc Changer

Free standing

• Always position the changer horizontally on a flat,

firm surface.

• Allow a free space of at least 3 cm above the

changer so as not to interfere with the cooling of the

changer.

In an audio rack

• The changer can be sited in any desired position.

Stacked

• Site the changer preferably at the bottom or at the

top.

• Never position the changer directly on top of a high-

power amplifier, as such an amplifier gives off a

substantial amount of heat.

RECEIVER

CD CHANGER

CASSETTE DECK

English

Introduction . . . . . . . . . . . . . . . . . . . . . . .9

Installation . . . . . . . . . . . . . . . . . . . .9 - 10

Functional Overview . . . . . . . . . . .11 - 13

Playback . . . . . . . . . . . . . . . . . . . . .14 - 18

Programming . . . . . . . . . . . . . . . . . . . . .18

Edit . . . . . . . . . . . . . . . . . . . . . . . . . .19 - 20

Additional Information . . . . . . . . .20 - 21

Troubleshooting . . . . . . . . . . . . . . . . . . .21

CONTENTS INTRODUCTION INSTALLATION

pg 09-21/CDC775/17-Eng 2/16/00 9:26 AM Page 9

Downloaded From Disc-Player.com Philips Manuals

Connections

1 Digital Out

This output supplies digital signal and can therefore

only be connected to an input which is suitable for

this signal. Use here a lead with one cinch plug on

either end.

Never connect this socket to a non-digital input

of an amplifier, such as AUX, CD, TAPE, PHONO

etc!

2 Analog Out

For the connecting cable to the amplifier.

• Insert a red plug into the ‘R’ socket and the

other plug into the ‘L’ socket.

• Insert the two other plugs into the corresponding

sockets of the CD or AUX input of your amplifier.

You can also use the TUNER or TAPE IN connection,

but never the PHONO input!

Connecting Headphones

• Connect headphones with a 6.3 mm jack plug to the

PHONES socket.

• The sound level is adjusted with the LEVEL control.

Note:

– The volume control on the remote control must not be

at the minimum level.

PHONES

LEVEL

MAX

MIN

English

INSTALLATION

COAXIAL

ANALOG

OUT

DIGITAL

OUTPUT

pg 09-21/CDC775/17-Eng 2/16/00 9:26 AM Page 10

Downloaded From Disc-Player.com Philips Manuals

English

FUNCTIONAL OVERVIEW

1POWER-ON/ OFF

Switching on and off.

2EDIT

Activating the EDIT function when making a

recording.

3PROGRAM

Opening the memory when compiling a program.

4TIME

Selecting the information you want to see on the

display.

5SCAN

Automatically playing the beginning of each track.

6REPEAT

Repeating play.

7FADER

Fading in and out during play.

PEAK SEARCH

Searching the loudest passage (peak) on a CD or in

a program when making a tape recording.

8DISPLAY

Informs you about the functioning of the player.

9I(nfra) R(ed) SENSOR

Receives the signals from the remote control.

0SHUFFLE

Playing in random order.

!PAUSE ;

Interrupting play.

@S T

– Selecting another track during play.

– Selecting a track to start play with.

– Selecting tracks when compiling a program.

– Fast search to a particular passage during play.

– Selecting the recording mode during edit.

– Selecting the recording time during edit.

#STOP 9

– Stopping play.

– Cancel a Program, Peak Search or Edit.

$PLAY 2

– Starting play.

– Returning to the beginning of a track.

%CD DIRECT PLAY

– Selecting another CD during play.

– Selecting a CD to start play with.

– Selecting CDs when compiling a Program, Peak

Search or Edit.

^OPEN/CLOSE

Opening and closing the CD compartment.

&CD CAROUSEL TRAY

*LEVEL

Adjusting the volume when listening with

headphones.

(PHONES

Connecting headphones.

)QUICK PLAY

Immediate playing of a particular CD.

¡LOAD

Rotating the turntable in the CD compartment when

inserting CDs.

POWER ON/OFF

SHUFFLE

PAUSE

12345

IR SENSOR

PROG SCAN

EDIT TIME

P-SEARCH

DISC SELECT

CD TEXT

SCROLL

PHONES

LEVEL

CD DIRECT PLAY

PREV NEXT STOP PLAY

OPEN/CLOSE

MAX

MIN

FADE/

REPEAT

CDC 775 • COMPACTDISC C AROUSELCHANGER

CD REWRITABLE COMPATIBLE

MULTI DISC CHANGER

DIGITAL OUTPUT

1234567 8 0!@#$%9

^&*(

TRACK PEAK TOT REM TRACK TIME

SHUFFLE

PAUSE

REPEAT DISC

54 13 2

PROGRAM

LEVELPHONES

IRSENSOR

TRACK PEAK TOT REM TRACK TIME

SHUFFLE

PAUSE

REPEAT DISC

PROGRAM

54 13 2

¡)

pg 09-21/CDC775/17-Eng 2/16/00 9:26 AM Page 11

Downloaded From Disc-Player.com Philips Manuals

Remote Control 1 PAUSE ;

Interrupting play.

2 SCAN

Automatically playing the beginning of each track.

3 PROG.

Opening the memory when compiling a program.

4 DISC

– Selecting another CD during play.

– Selecting a CD to start play with.

– Selecting CDs when compiling a Program, Peak

Search or Edit.

5 TRAY OPEN

Opening and closing the CD compartment.

6 SHUFFLE

Playing in random order.

7 1 - 0 DIGIT KEYS

– Selecting another track.

– Selecting a track to start play with.

– Selecting tracks when compiling a program.

8 REPEAT

Repeating play.

9 – VOLUME +

Adjusting the sound level when the changer is

connected via the ANALOG or DIGITAL OUT output

to an amplifier or HiFi system without its own

remote control. Also for adjusting the sound level

on the headphones.

10 í PREV. / NEXT ë

– Selecting another track during play.

– Selecting a track to start play with.

– Selecting tracks when compiling a program.

– Fast search to a particular passage during play.

– Selecting the recording mode during edit.

– Selecting the recording time during edit.

11 STOP 9

– Stopping play.

– Cancel a Program, Peak Search or Edit.

12 PLAY 2

– Starting play.

– Returning to the beginning of a track.

The life of the batteries of the remote control is around

one year. For replacement only use batteries of the type

RO3, UM4 or AAA.

PROG.

DISC

SCAN SHUFFLE

ëí

VOLUME

PAUSE REPEAT

PLAY

STOP

PREV. NEXT

DIGITAL REMOTE CONTROL



TRAY

OPEN

2 X 1.5 V R03 /

UM4 / AAA

English

FUNCTIONAL OVERVIEW

pg 09-21/CDC775/17-Eng 2/16/00 9:26 AM Page 12

Downloaded From Disc-Player.com Philips Manuals

Display

{

– Lights up when the changer receives a command from

the remote control.

1 - 5 CD number indicator

– Lights up when you switch the changer on.

– Indicates the number of CDs in the CD compartment.

– Indicates what CD is being played (CD number

flashes).

PROGRAM

– Flashes when a program is being compiled.

– Lights up when a program is being played.

TRACK –Indicates:

– what track is being played;

– the number of tracks on a CD or in a program.

PEAK

– Flashes when the loudest passage (peak) on a CD or

in a program is being searched.

– Lights up when the loudest passage (peak) has been

found.

TRACK TIME

– Indicates the elapsed playing time of the track being

played.

REM(aining) TRACK TIME

– Indicates the remaining playing time of the track

being played.

TOT(al) REM(aining) TIME

– Indicates the remaining playing time of a CD.

TOT(al) TIME

– Indicates the total playing time of a CD.

SHUFFLE

– Lights up when the tracks are played in random order.

PAUSE

– Lights up when play is interrupted.

REPEAT 1

– Lights up when you repeat a track.

REPEAT DISC

– Lights up when you repeat a CD.

REPEAT

– Lights up when you repeat all CDs or a program from

them.

Display messages:

REAd – Lights up when a CD's contents list is being

scanned.

NO dISC–Lights up when there are no CDs in the

CD compartment.

WRONG tRACK– Lights up when you select a non-

existent track number.

SELECt dISC– Lights up when you try to activate

a function for which you must first select a CD number.

INSERt dISC– Lights up when you give a play

command while the CD compartment is empty.

GO tO StOP – Lights up if you try to activate a

function for which you must first stop play.

– Lights up when the player is put into the

EDIT mode.

54 13 2

TRACK PEAK TOT REM TRACK TIME

SHUFFLE

PAUSE

REPEAT DISC

PROGRAM

54 13 2

English

FUNCTIONAL OVERVIEW

pg 09-21/CDC775/17-Eng 2/16/00 9:26 AM Page 13

Downloaded From Disc-Player.com Philips Manuals

Inserting the CDs

NOTE!

Use only audio CD; audio CD-R or audio CD-RW.

• Press POWER-ON/OFF to switch the changer on.

– The changer will now start CD detection to check how

many CDs there are in the CD compartment. The

turntable will rotate slowly until all positions (1 - 5)

in the CD compartment have been checked.

– The position which is being checked is always shown

on the display (dISC X).

– After CD detection the 1 - 5 CD number indicator will

show the number of CDs in the CD compartment.

• Open the CD compartment by pressing OPEN/CLOSE.

–OPEN lights up.

• Insert the CDs,

printed side up;

use the LOAD

button to rotate the turntable

in the CD compartment.

• Close the compartment by

pressing OPEN/CLOSE.

–CLOSE lights up. The

changer will start CD

detection again.

NOTE!

– CD detection may never be interrupted. If, during

detection, you press any button, then the changer

will stop detection and the display will give an

incorrect indication of the number of CDs in the CD

compartment.

–Always remove all CDs from the CD compartment if

you want to transport the changer.

Normal Playback (PLAY 2)

– The display shows the number of the current CD.

• Press PLAY 2to start playback.

– The CD number indicator (1-5) always shows what CD

is being played (BXflashes).

– The track being played and its elapsed playing time

are shown under TRACK and TRACK TIME.

See 'CALLING UP INFORMATION ON THE DISPLAY' if

you wish to see other information on the display.

– Play will stop after all CDs have been played.

• Press POWER-ON/OFF to switch the changer off.

Quick Play

• Use the PREFERRED POSITION

in the CD compartment if you

wish to insert only one CD and

then start play by pressing the

QUICK PLAY button. Play will

then start immediately with

the inserted CD.

NOTE!

– You can also press PLAY

immediately after in-

serting the CDs; the compartment then closes

automatically and play starts from the first available

CD.

– You can interrupt playback by pressing PAUSE ;;

PAUSE then lights up. Press PLAY 2or PAUSE ;; to

restart.

– If you press PLAY 2during play, the current track will

start again from the beginning.

– You can stop playback by pressing STOP 9.

– If you press OPEN/CLOSE during play, the CD

compartment will open while play continues. The

three CDs outside the changer may now be changed

without playback being interrupted.

TRACK TRACK TIME

13 2

English

PLAYBACK

LOAD

QUICK PLAY

PREFERRED

POSITION

LOAD

QUICK PLAY

PREFERRED

POSITION

pg 09-21/CDC775/17-Eng 2/16/00 9:26 AM Page 14

Downloaded From Disc-Player.com Philips Manuals

Selecting Another Track During Play

(S T)

• Press Tor S

(less than 0.5 seconds)

until the

desired track number appears under TRACK.

– The music stops and a moment later the selected

track begins to play.

WRONG tRACKlights up when you select a non-

existent track number.

Selecting Another CD During Play (CD

DIRECT PLAY)

• Key in the desired CD number.

– The music stops and a moment later the selected CD

begins to play.

NO dISC lights up when there is no CD in the

selected CD compartment. You can also select the num-

ber by using the DISC button on the remote control.

Searching For A Passage During Play

(S T)

• Hold Sdown to search backwards to the

beginning.

• Hold Tdown to search forwards to the end.

The searching speed is determined by how long a key is

pressed:

– the first 2 seconds fairly slowly, with sound;

– then at the maximum speed, with no sound.

If you reach the end of the last track and release T,

play will resume a few seconds before the end of the

CD.

Starting With A Particular CD

(CD DIRECT PLAY)

• Key in the required CD number.

– If the CD compartment was open, it will now close.

– Play starts from the selected CD.

NO dISC lights up when there is no CD in the

selected CD compartment. You can also select the num-

ber by using the DISC button on the remote control.

Starting With A Particular Track

(CD DIRECT PLAY, S T and

PLAY 2)

• First select the number of the required CD using CD

DIRECT PLAY or DISC on the remote control.

– If the CD compartment was open, it will now close.

• Then select the (track) number by using Tor

(press less than 0.5 seconds).

• Press PLAY 2.

– Play starts from the selected track.

WRONG tRACK lights up when you select a non-

existent track number.

NO dISC lights up when there is no CD in the

selected CD compartment.

Scanning CDs (SCAN)

All CDs:

• Press SCAN before or during play.

– If the CD compartment was open, it will now close.

–SCAN lights up and the first 10 seconds of each

track are played in turn (starting from the current

track). 10 seconds are counted down each time under

REM(aining) TRACK TIME.

• When the player reaches a track which you wish to

hear in full, press SCAN again or PLAY 2.

TRACK REM TRACK TIME

TRACK TRACK TIME

English

PLAYBACK

pg 09-21/CDC775/17-Eng 2/16/00 9:26 AM Page 15

Downloaded From Disc-Player.com Philips Manuals

Playing In Random Order (SHUFFLE)

All CDs:

• Press SHUFFLE before or during play.

– If the CD compartment was open, it will now close.

– SHUFFLE lights up and all the tracks are now played

in a random order.

– If you press T,you will select any one of the

following tracks.

• Press SHUFFLE again if you wish to return to normal

play.

NOTE!

– If, during play, you open the CD compartment to

change CDs (see 'NORMAL PLAYBACK') then

playback in random order will be cancelled. Playback

will stop as soon as the last track of the current CD

has been played (in normal order).

Calling Up Information On Display

(TIME)

In STOP mode:

Text display

– After loading the CDs and closing the CD

compartment, the display shows the number of the

CD to be played (= default display in STOP mode).

• Press TIME to shows the number of tracks and the

total playing time of the current CD (TOTAL TIME).

During play:

1. Time display

– When you start play (from STOP mode), the display

shows the elapsed playing time of the current track

(= default display in PLAY mode).

• Press TIME whenever you want to know the

remaining playing time of the current track (REM

TRACK TIME).

• Press TIME, if you wish to know the total playing

time from the beginning (TOTAL TIME).

• Press TIME again if you wish to know the remaining

playing time of the entire CD (TOTAL REM TIME).

Note :

– TOTAL REM(aining) TIME and TOTAL TIME indications

are not available in SHUFFLE mode.

2. Text display

• If you press TIME again, you will switch to text

display; the display shows the number of the current

CD.

• If you wish to know the total playing time of the

entire CD you must go back to STOP mode first and

then press TIME.

– The display now shows the number of tracks and the

total playing time of the current CD (TOTAL TIME).

Repeating Play (REPEAT)

Repeating a track:

• Press REPEAT before or during playback of the CD.

– REPEAT 1 lights up; the track will now be repeated

continuously.

• Press REPEAT three times to stop the track being

repeated.

Repeating a CD:

• Press REPEAT twice before or during playback of the

CD.

– REPEAT DISC lights up; the CD will now be repeated

continuously.

• Press REPEAT twice to stop the CD being repeated.

TRACK TRACK TIME

REPEAT DISC

TRACK TRACK TIME

REPEAT 1

13 2

TRACK TIME

REMTOT

TRACK TIME

TOT

TRACK TRACK TIME

REM

TRACK TRACK TIME

TRACK TIME

TOT

13 2

TRACK TRACK TIME

SHUFFLE

English

PLAYBACK

pg 09-21/CDC775/17-Eng 2/16/00 9:26 AM Page 16

Downloaded From Disc-Player.com Philips Manuals

Note:

– Repeating of a CD is not possible during shuffle or

program mode.

Repeating all CDs:

• Press REPEAT

three times

before or during playback.

– REPEAT lights up; all CDs will now be repeated

continuously.

• Press REPEAT again to stop the CDs being repeated.

NOTE!

– When a program has been stored (for one or more

CDs), then only the program will be repeated.

Searching For The Loudest Passage

(PEAK SEARCH)

• In STOP mode, press PEAK SEARCH.

–SELECt dISC lights up and PEAK starts

flashing.

• Press PEAK SEARCH again to select the last

selected disc or press any CD DIRECT PLAY button

or DISC

(on the remote control)

to select the desired

disc.

– The CD will now be scanned for the loudest passage

(the peak).

– The display shows the track being scanned and its

elapse playing time.

– When the loudest passage has been found it will be

repeated continuously (from 2 seconds before the

peak until 2 seconds after the peak) and PEAK lights

up.

• You can now adjust your recording device.

• You can stop the scan by pressing STOP 9: if you

press PLAY 2, the CD will be played from the

beginning.

NOTES!

– When searching for the loudest passage in a program

(from one or more CDs) there is no need to enter the

CD number(s).

– If you wish to record tracks from different CDs you

have to repeat peak search for each CD.

– You can interrupt PEAK SEARCH by pressing STOP 9.

Adjusting The Sound Level

(-VOLUME +)

(on the remote control only)

The volume output of the CD changer can be adjusted.

This will affects the analog out, digital out and

heaphones level.

• Press VOLUME -or +to reduce or increase the

sound level.

– The display will show a value between VOL 0 and

VOL 20.

Important!

The volume level will influenced the sound level

during recording. Set the volume level to the

maximum and do not change the volume setting

during recording.

Locking the volume

This unique feature allows you to lock the volume level

when listening to the heaphones or doing recording.

• Press EDIT for more than 2 seconds.

– The displays will show VOL LOCK.

Unlocking the volume

• Press EDIT for more than 2 seconds.

– The displays will show VOL 20.

Note:

– When you adjust the volume and the display shows

VOL LOCK

, it means that the volume is in the lock

mode.

Listening to the heaphones

• Connect the headphones to the PHONES socket.

• Adjust the headphones sound level with the LEVEL

control.

Note:

– Should there be no sound after adjusting the LEVEL

control to maximum; press VOLUME + on the remote

control to increase the sound level.

TRACK PEAK TRACK TIME

TRACK TRACK TIME

REPEAT

English

PLAYBACK

pg 09-21/CDC775/17-Eng 2/16/00 9:26 AM Page 17

Downloaded From Disc-Player.com Philips Manuals

Activating The Fade-In And Fade-Out

Function (FADER)

NOTE!

– The FADER function can be used if the changer is

connected to the amplifier or the system via the

ANALOG OUT output.

• During play press FADER.

– The sound level will now gradually decrease (FADE

OUT), after which the changer will go into the PAUSE

mode.

FAdE f≠

™

FAdE ≠

™

FAdE _

• Press FADER again.

– Play continues and the sound level will increase again

to the originally set level (FADE IN).

FAdE _

™

FAdE ≠

™

FAdE f≠

Storing A Program (PROGRAM)

– By programming the changer you can play up to 40

tracks in any required sequence.

–FULL lights up if you exceed the maximum of 40

tracks.

–NO dISC lights up when there is no CD in the

selected CD compartment.

• In STOP mode, press PROGRAM to open the

memory.

–SELECt dISC lights up and PROGRAM starts

flashing.

• Press PROGRAM again to select the last selected

disc or press any CD DIRECT PLAY button or DISC

(on the remote control)

to select the desired disc.

• Press Tor S

(less than 0.5 seconds)

until

the first track number you wish to program appears

under TRACK.

• Press PROGRAM again.

– The track number has now been stored in the

changers memory.

• Select the other track numbers required and store

each track by pressing PROGRAM.

– The number of tracks and the playing time of your

program will be shown under TRACK and TOT(al)

TIME.

• Press STOP 9to quit the PROGRAM mode.

Note:

– If the total playing time is more than “99:59”, then

“--:--” appears in the display instead of the total

playing time.

Playing The Program ( PLAY 2)

• Press PLAY 2.

– Playback starts with the first number of the program.

The PROGRAM and EDIT buttons cannot be used during

programmed play.

Search for a particular passage is only possible within

the track being played.

Erasing A Program (STOP 9or

OPEN/CLOSE)

In PLAY mode:

• Press OPEN/CLOSE or STOP 9

(twice).

In STOP mode:

•Press OPEN/CLOSE or STOP 9.

– The program has now been erased.

TRACK TRACK TIME

PROGRAM

English

PLAYBACK PROGRAMMING

pg 09-21/CDC775/17-Eng 2/16/00 9:26 AM Page 18

Downloaded From Disc-Player.com Philips Manuals

Tabla de contenidos

Otros manuales de Receptor estéreo de Philips

Philips

Philips DFR9000 Manual de usuario

Philips

Philips HTR5224/12 Manual de usuario

Philips

Philips FWM653 Manual de usuario

Philips

Philips 14RF50S Manual de usuario

Philips

Philips LX600 Manual de usuario

Philips

Philips DFR9000 Manual de usuario

Philips

Philips FR-968 Manual de usuario

Philips

Philips HTR3465/98 Manual de usuario

Philips

Philips HTR9900/12 Manual de usuario

Philips

Philips LX710/01 Manual de usuario

Philips

Philips US2-PH61153 Manual de usuario

Philips

Philips LX 8000SA Manual de funcionamiento

Philips

Philips MX-1015D Manual de usuario

Philips

Philips FR 911 Manual de usuario

Philips

Philips HTR3464/12 Manual de usuario

Philips

Philips HTR9900/12 Manual de usuario

Philips

Philips FR755 Manual de usuario

Philips

Philips LX600/01 Manual de funcionamiento

Philips

Philips Matchline FR970 Manual de usuario

Philips

Philips FR-963 Manual de usuario

Philips

Philips FR 931 Manual de usuario

Philips

Philips FR740/00 Manual de usuario

Philips

Philips LX710/01 Manual de usuario

Philips

Philips D 2999 Manual de instalación y operación

Manuales populares de Receptor estéreo de otras marcas

Marantz

Marantz CINEMA 70S Manual de usuario

Kenwood

Kenwood KMDX92 Manual de usuario

Yamaha

Yamaha RX-830 Manual de usuario

Pioneer

Pioneer AVH-Z7250BT Manual de usuario

Yamaha

Yamaha RX-750 Manual de usuario

Denon

Denon AVR-1311 Manual de usuario

Denon

Denon AVR-S760H Manual de usuario

Denon

Denon AVR-X7200W Manual de usuario

Pioneer

Pioneer SC-LX904 Manual

Sony

Sony XAV-1500 Manual de usuario

Radio Shack

Radio Shack DX-399 Manual de usuario

Sony

Sony STR-DE535 - Fm Stereo/fm-am Receiver Manual de usuario

Pioneer

Pioneer SX-1000TA Manual de usuario

Yamaha

Yamaha MusicCast TSR-5B3D Manual de usuario

Sony

Sony STR-DE335 - Fm Stereo/fm-am Receiver Manual de usuario

Sony

Sony STR-DG500 - Multi Channel Av Receiver Manual de usuario

Panasonic

Panasonic AJSD955B - DVCPRO50 STUDIO DECK Manual de usuario

Pioneer

Pioneer SX-838 Manual de usuario
