Philips TAS1505 Manual de usuario
User manual
TAS1505
Register your product and get support at
www.philips.com/support
EN 1
Contents
1 Important 2
Safety 2
2 Your wireless speaker 3
Introduction 3
What's in the box 3
Overview of the speaker 3
3 Get started 4
Charge the built-in battery 4
4
4 Play from Bluetooth devices 5
Play from Bluetooth devices 5
Control playback 5
5 Product information 6
6 Troubleshooting 7
General 7
Bluetooth 7
7 Notice 8
Compliance 8
Care of the environment 8
FCC Statement 8
Trademark notice 9
2EN
1 Important
Safety
Important safety instructions
• Make sure that the power supply voltage
CC
corresponds to the voltage on the back or
the underside of the unit.
• The speaker shall not be exposed to
dripping or splashing.
• Do not place any source of danger on the
speaker (e.g. liquid filled objects, lit candles).
• Make sure that there is enough free space
around the speaker for ventilation.
• Please use the speaker safely in an
environment with temperature between
• Only use attachments and accessories
specified by the manufacturer.
Battery safety precautions
• Danger of explosion if a battery is
incorrectly replaced. Replace only with the
same or equivalent type.
• A battery (battery pack or battery installed)
shall not be exposed to excessive heat such
as sunshine, fire or the like.
• A battery in extreme high or low
temperatures during use, storage or
transportation, and low air pressure at high
altitude can pose safety hazards.
• Do not replace a battery with an incorrect
type that can defeat a safeguard (for
example, some lithium battery types).
• Disposing a battery into fire or a hot oven,
mechanically crushing or cutting a battery
can result in an explosion.
• Leaving a battery in an extremely high
temperature surrounding, or an extremely
low air pressure environment may result in
an explosion or leakage of flammable liquid
or gas.
Warning
• Never remove the casing of this speaker.
• Never lubricate any part of this speaker.
• Place this speaker on a flat, hard and stable
surface.
• Never place this speaker on other electrical
equipment.
• Only use this speaker indoors. Keep this speaker
away from water, moisture and liquid-filled
objects.
• Keep this speaker away from direct sunlight,
naked flames or heat.
• Risk of explosion if a battery is replaced by an
incorrect type.
3EN
2 Your portable
speaker
Congratulations on your purchase, and
welcome to Philips! To fully benefit from the
support that Philips offers, register your product
at www.philips.com/welcome.
What's in the box
Check and identify the contents of your
package:
Overview of the speaker
Indicate battery or Bluetooth
connection status.
Speaker
USB cable
Quick start guide
Safety sheet
Worldwide warranty
Lanyard
1
2
3
LED indicator
DC IN
•
• Charge the built-in battery.
Turn the speaker on or o.
4EN
3 Get started
Always follow the instructions in this chapter in
sequence.
Charge the built-in battery
Turn on/off
To turn the speaker on, press and hold
" " for two seconds. You will hear the
prompt sound and Blue LED indicator
blinks.
Auto off in 15 minutes if no Bluetooth
connection.
5V 0.5 A
To turn the speaker off, press and hold
" " for two seconds. You will hear the
prompt sound and Blue LED indicator
turn off.
Charge the built-in battery
The speaker is powered by a built-in
rechargeable battery.
Connect the USB-C socket on the speaker to
an outlet (5V 0.5A) by using the provided USB
cable.
When the speaker is being charged,
Power on
LED is solid Red.
When the speaker is fully charged,
LED is solid Blue.
When the speaker is being charged,
Power o
LED is solid Red.
When the speaker is fully charged,
LED is o.
Note
·Before use, fully charge the built-in battery.
·The USB Type C socket is for charging only.
·It takes you approximately two hours to fully charge
the battery.
·Rechargeable battery has a limited number of charge
cycles. Battery life and number of charge cycles vary by
use and settings.
5EN
4 Play from
Bluetooth
devices
With this speaker, you can listen to audio from
Bluetooth-enabled devices.
Note
The speaker can memorize a maximum of eight paired
devices. The ninth paired device will replace the first one.
Any obstacle between this speaker and a Bluetooth
device can reduce the operational range.
Keep away from any other electronic device that may
cause interference.
The operational range between this speaker and a
Bluetooth device is approximately 20 meters (66 feet).
Connect a device
1
»
The LED indicator blinks blue.
2
On your Bluetooth device, enable
Bluetooth and search for Bluetooth devices
that can be paired.
3 Select [Philips S1505] displayed on your
device for pairing and connection. If
necessary, input “0000” as the pairing
password.
» After successful pairing and connection,
you'll hear the prompt sound, and the
LED indicator turns solid blue.
If you cannot find
[Philips S1505] on
your device, hold down the Power
button for 2 seconds to power off
before rebooting, and long press it for
2 seconds to enter into pairing mode.
4
Play audio on your Bluetooth device to start
streaming music.
Tip
· You can use your Bluetooth device to control play.
LED indicator (blue)
Indicator Bluetooth connection status
Fast blinking (2Hz) Pairing
Slow blinking (1Hz) Connecting
Solid blue Connected
Disconnect a device
Disable Bluetooth on your device; or
Move the device beyond the
communication range.
» The speaker beeps twice, and the LED
indicator blinks blue.
Note
Before connecting another Bluetooth device, disconnect
the
current device first.
Reconnect a device
When you turn on the speaker, it will reconnect
the last connected device automatically; If not,
select [Philips S1505] on your Bluetooth device
to start connection.
• To clear the pairing information, press and hold for
5 seconds until you hear the prompt sound, and the
LED indicator blinks blue.
Press for 2 seconds to turn the speaker
on.
2.5W RMS
6EN
5
0.14
150Hz-18kHz
1.5"
80
64 x 64 x 78mm
3.7 V,480 mAh
V5.0
A2DP V1.3,
AVRCP V1.6
Bluetooth Profile
20
Operation Ambient
IP protection class
0~40
IPX7*
*The IPX7 rating means the speaker driver can
be submerged for up to 30 minutes at a depth
of up to 1 m.
Philips S1505
If you cannot find [Philips S1505] on your
device, hold the for 2 seconds to power
off, and then long press the button for 6
seconds to clear the pairing information /
enter pairing mode.
Hereby, TP Vision Europe B.V. declares that
this product is in compliance with the
essential requirements and other relevant
provisions of Directive 1999/5/EC. You can find
the Declaration of Conformity on
www.philips.com/support.
Disposal of a battery into fire or a hot oven, or
mechanically crushing or cutting of a battery, that
can result in an explosion.
MMD Hong Kong Holding Limited may void
theuser's authority to operate the equipment.
FCC Statement
This device complies with Part 15 of the FCC
Rules. Operation is subject to the following
two conditions: (1) This device may not cause
harmful interference, and (2) This device must
accept any interference received, including
interference that may cause undesired
operation.
Warning: Changes or modifications not
expressly approved by the party responsible for
compliance could void the user’s authority to
operate the equipment.
Note: This equipment has been tested and
found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC
Rules.
These limits are designed to provide reasonable
protection against harmful interference in a
residential installation.
This equipment generates, uses and can
radiate radio frequency energy and, if not
installed and used in accordance with the
instructions, may cause harmful interference
to radio communications. However, there is
no guarantee that interference will not occur
in a particular installation. If this equipment
does cause harmful interference to radio or
television reception, which can be determined
encouraged to try to correct the interference
by one or more of the following measures: (1)
Reorient or relocate the receiving antenna. (2)
Increase the separation between the equipment
and receiver. (3) Connect the equipment into an
the receiver is connected. (4) Consult the dealer
or an experienced radio/TV technician for help.
RF Warning Statement
The device has been evaluated to meet general
RF exposure requirements. The device can be
used in portable exposure conditions without
restriction.
Trademark notice
MMD
Hong Kong Holding Limited is under license.
Other trademarks and trade names are those
of their respective owners.
The Bluetooth ® word mark and logos are
registered trademarks owned by the Bluetooth
SIG, Inc. and any use of such marks by
EN9
