Philips TAS2505 Manual de usuario

User manual

TAS2505

www.philips.com/support

EN 1

Contents

1 Important 2

Safety 2

2 Your wireless speaker 3

Introduction 3

What's in the box 3

Overview of the speaker 3

3 Get started 4

Charge the built-in battery 4

4 Play from Bluetooth devices 5

Play from Bluetooth devices 5

Control playback 5

Control phone call 5

5 Product information 6

6 Troubleshooting 7

General 7

Bluetooth 7

7 Notice 8

Compliance 8

Care of the environment 8

FCC Statement 8

Trademark notice 9

2EN

1 Important

Safety

Important safety instructions

• Make sure that the power supply voltage

corresponds to the voltage on the back or

the underside of the unit.

• The speaker shall not be exposed to

dripping or splashing.

• Do not place any source of danger on the

speaker (e.g. liquid ﬁlled objects, lit candles).

• Make sure that there is enough free space

around the speaker for ventilation.

• Please use the speaker safely in an

environment with temperature between

• Only use attachments and accessories

speciﬁed by the manufacturer.

Battery safety precautions

• Danger of explosion if a battery is

incorrectly replaced. Replace only with the

same or equivalent type.

• A battery (battery pack or battery installed)

shall not be exposed to excessive heat such

as sunshine, ﬁre or the like.

• A battery in extreme high or low

temperatures during use, storage or

transportation, and low air pressure at high

altitude can pose safety hazards.

• Do not replace a battery with an incorrect

type that can defeat a safeguard (for

example, some lithium battery types).

• Disposing a battery into ﬁre or a hot oven,

mechanically crushing or cutting a battery

can result in an explosion.

• Leaving a battery in an extremely high

temperature surrounding, or an extremely

low air pressure environment may result in

an explosion or leakage of ﬂammable liquid

or gas.

Warning

• Never remove the casing of this speaker.

• Never lubricate any part of this speaker.

• Place this speaker on a ﬂat, hard and stable

surface.

• Never place this speaker on other electrical

equipment.

• Only use this speaker indoors. Keep this speaker

away from water, moisture and liquid-ﬁlled

objects.

• Keep this speaker away from direct sunlight,

naked ﬂames or heat.

• Risk of explosion if a battery is replaced by an

incorrect type.

C C

3EN

2 Your portable

speaker

Congratulations on

welcome to Philips! To fully benefit from the

support that Philips offers, register your product

at www.philips.com/welcome.

What's in the box

Check and identify the contents of your

package:

Speaker

USB cable

Quick start guide

Safety sheet

Worldwide warranty

Lanyard

Overview of the speaker

Adjust volume.

5 DC IN

Charge the built-in battery.

Turn the speaker on or off.

Check the battery level.

Show the Bluetooth status.

Clear Bluetooth pairing information.

Respond to an incoming call through

Bluetooth connection.

In Bluetooth mode, press to pause or

resume play.

In Bluetooth mode, press twice to play

the next track.

Press to turn the Multi-color LED light on

or off.

your purchase, and

4EN

3 Get started

Always follow the instructions in this chapter in

sequence.

Charge the built-in battery

The speaker is powered by a built-in

rechargeable battery.

Note

· Before use, fully charge the built-in battery.

· The USB-C socket is for charging only.

· It takes you approximately two and a half hours to fully

charge the battery.

· Rechargeable battery has a limited number of charge

cycles. Battery life and number of charge cycles vary by

use and settings.

5V 1A Turn on/off

To turn the speaker on, press and hold

" " for two seconds. You will hear the

prompt sound and Blue LED indicator

blinks.

To turn the speaker off, press and hold " "

for two seconds. You will hear the prompt

sound and and the LED is off.

Auto off in 15 minutes if no Bluetooth

connection.

When the speaker is being charged,

Power on

LED is solid Red.

When the speaker is fully charged,

LED is solid Blue.

When the speaker is being charged,

Power o

LED is solid Red.

When the speaker is fully charged,

LED is o.

Caution

• Risk of speaker damage! Make sure the power

supply voltage corresponds to the voltage

printed on the back or the underside of the

speaker.

• Risk of electric shock! When unplug the USB

cable, always pull the plug from the socket.

Never pull the cable.

• Use only a USB cable speciﬁed by the

manufacturer or sold with this speaker.

Connect the USB-C socket on the speaker to

an outlet (5V 1A) by using the provided USB

cable.

5EN

4 Play from

Bluetooth

devices

you can listen to audio from

Bluetooth-enabled devices.

Note

The speaker can memorize a maximum of eight paired

devices.The ninthpaired device will replace the first one.

Any obstacle between this speaker and a Bluetooth

device can reduce the operational range.

Keep away from any other electronic device that may

cause interference.

The operational range between this speaker and a

Bluetooth device is approximately 20 meters (66 feet).

Connect a device

The LED indicator

On your Bluetooth device, enable

Bluetooth and search for Bluetooth devices

that can be paired.

3Select [Philips S2505] displayed on your

device for pairing and connection. If

necessary, input “0000” as the pairing

password.

» After successful pairing and connection,

you will hear the prompt sound and

the LED indicator turns solid blue.

If you cannot find

[Philips S2505] on

your device, press and hold

for more than three seconds until you

the prompt sound.

4Play audio on your Bluetooth device to

start streaming music.

Tip

· You can use your Bluetooth device to control play.

LED indicator (blue)

Indicator Bluetooth connection status

Fast blinking (2Hz) Pairing

Slow blinking (1Hz) Connecting

Solid blue Connected

Disconnect a device

To clear the pairing information, press and

hold for more than 5 seconds until

you hear the prompt sound.

Short press to disconnect from the

current pairing;

Disable Bluetooth on your device; or

Move the device beyond the

communication range.

» You will hear the prompt sound and

the LED indicator blinks blue.

Note

Before connecting another Bluetooth device, disconnect

the

current device first.

Reconnect a device

With this speaker,

blinks blue.

5EN

When you turn on the speaker, it will reconnect

the last connected device automatically; If not,

select [Philips S2505] on your Bluetooth device

to start connection.

Press for 2 seconds to turn the speaker

on.

3W RMS

6EN

0.19

120Hz - 18kHz

1.75"

91.5 x 91 x 41mm

850

V5.0

A2DP V1.3, HFP V1.7

AVRCP V1.6

2402-2480 MHz

Bluetooth Profile

Operation Ambient

IP protection class

0℃~40℃

IPX7

Philips S2505

If you cannot find

[Philips S2505] on your

device, hold down the button for 2

seconds to power off before rebooting, or

short press it to enter pairing mode.

MMD Hong Kong Holding Limited may void

theuser's authority to operate the equipment.

Hereby, TP Vision Europe B.V. declares that this

product is in compliance with the essential

requirements and other relevant provisions of

Directive 1999/5/EC. You can find the Declaration

of Conformity on www.philips.com/support.

Disposal of a battery into ﬁre or a hot oven, or

mechanically crushing or cutting of a battery, that

can result in an explosion.

EN9

FCC Statement

This device complies with Part 15 of the FCC

Rules. Operation is subject to the following

two conditions: (1) This device may not cause

harmful interference, and (2) This device must

accept any interference received, including

interference that may cause undesired

operation.

Warning: Changes or modiﬁcations not

expressly approved by the party responsible for

compliance could void the user’s authority to

operate the equipment.

Note: This equipment has been tested and

found to comply with the limits for a Class B

digital device, pursuant to Part 15 of the FCC

Rules.

These limits are designed to provide reasonable

protection against harmful interference in a

residential installation.

This equipment generates, uses and can

radiate radio frequency energy and, if not

installed and used in accordance with the

instructions, may cause harmful interference

to radio communications. However, there is

no guarantee that interference will not occur

in a particular installation. If this equipment

does cause harmful interference to radio or

television reception, which can be determined

encouraged to try to correct the interference

by one or more of the following measures: (1)

Reorient or relocate the receiving antenna. (2)

Increase the separation between the equipment

and receiver. (3) Connect the equipment into an

the receiver is connected. (4) Consult the dealer

or an experienced radio/TV technician for help.

RF Warning Statement

The device has been evaluated to meet general

RF exposure requirements. The device can be

used in portable exposure conditions without

restriction.

Trademark notice

MMD

Hong Kong Holding Limited is under license.

Other trademarks and trade names are those

of their respective owners.

The Bluetooth ®word mark and logos are

registered trademarks owned by the Bluetooth

SIG, Inc. and any use of such marks by

Otros manuales para TAS2505

Tabla de contenidos

Otros manuales de Oradores de Philips

Philips

Philips RWSS5512/93 Manual de usuario

Philips

Philips BT2500B/W-00 Manual de usuario

Philips

Philips SPA7355/77 Manual de usuario

Philips

Philips SPA30W Manual de usuario

Philips

Philips SGC5103BD - amBX 2.1-CH PC Multimedia Speaker... Manual de usuario

Philips

Philips AD7050W/37 Manual de usuario

Philips

Philips SPA4355 Manual de usuario

Philips

Philips SPA5162B Manual de usuario

Philips

Philips TAS4807 Manual de usuario

Philips

Philips HTL2160 Manual de usuario

Philips

Philips SPA7210R/10 Manual de usuario

Philips

Philips HTL1100 Manual de usuario

Philips

Philips 3000 series Manual de usuario

Philips

Philips HTB5544D Manual de usuario

Philips

Philips TAS3505 Manual de usuario

Philips

Philips SPA2360 Manual de usuario

Philips

Philips Fidelio SoundSphere Manual de usuario

Philips

Philips SBCBM130/05 Manual de usuario

Philips

Philips TAW6205/37 Manual de usuario

Philips

Philips Fidelio DS3880W/10 Manual de usuario

Philips

Philips BT6000 Manual de usuario

Philips

Philips Fidelio P9 Manual de usuario

Philips

Philips HTL2183B/79 Manual de usuario

Philips

Philips SPA2200 Manual de usuario

Manuales populares de Oradores de otras marcas

argon audio

argon audio IE20 Manual de usuario

Denon

Denon SC-N7 Manual de usuario

Gemline

Gemline Ace 3952 Manual de usuario

Focal

Focal ON WALL 300 Manual de instrucciones

HEADRUSH

HEADRUSH Maximus HRSP 5024 Manual de usuario

SoundLogic

SoundLogic BCCS-6/6395 Manual de usuario

Peavey

Peavey DTH 218 Manual de usuario

Avantree

Avantree Pluto Air Manual de usuario

Morel

Morel Integra Series INTEGRA OVATION 4 Manual de usuario

Oppo

Oppo SONICA Manual de usuario

Bose

Bose SoundLink Wireless Music System Manual de usuario

Rocksteady

Rocksteady Stadium Manual de usuario

Bowers & Wilkins

Bowers & Wilkins 4 Manual de usuario

Sonance

Sonance SONOS OUTDOOR Series Manual de usuario

Electro-Voice

Electro-Voice EVID FM4.2 Manual de usuario

Pioneer

Pioneer XW-HTD630 Manual de usuario

Onn

Onn BWA16AA002 Manual de usuario

HP GL313AA - USB Speakers PC Multimedia Manual de usuario
