EN User manual

CSP1000 CSP1200

10 ~ 15mm Speaker wire

(not supplied)

Amplifier

English

1. Important

Safety

Read and understand all instructions before you use the apparatus.•

If damage is caused by failure to follow instructions, the warranty does

not apply.

Use only the supplied mounting hardware for a safe and secure•

installation.

Thesubwooferisheavy.Attachitrmlytoasolidthickbafe-board.•

Donotcontinuouslyusethespeakersystembeyondthepeakpower•

handling capacity.

Keep credit cards, watches, recorded tapes etc. with magnetic coding•

awayfromthespeakersystemtopreventdamagecausedbythe

magnetsinthespeakers.

Clean the apparatus with soft, damp cloth. Never use substances such•

as alcohol, chemicals or household cleaners on the apparatus.

Notice

Environmental information

Allunnecessarypackaginghasbeenomitted.Wehavetriedtomake

thepackagingeasytoseparateintothreematerials:cardboard(box),

polystyrenefoam(buffer)andpolyethylene(bags,protectivefoamsheet.)

Your system consists of materials which can be recycled and reused if

disassembled by a specialized company. Please observe the local regulations

regardingthedisposalofpackagingmaterials,exhaustedbatteriesandold

equipment.

Anychangesormodicationsmadetothisdevicethatarenotexpressly

approved by Philips Consumer Lifestyle may void the user’s authority to

operate the equipment.

2009©KoninklijkePhilipsElectronicsN.V.Allrightsreserved.

Specicationsaresubjecttochangewithoutnotice.Trademarksaretheproper tyofKoninklijkePhilips

ElectronicsN.V.ortheirrespectiveowners.Philipsreservestherighttochangeproductsatanytime

withoutbeingobligedtoadjustearliersuppliesaccordingly.

Your car power subwoofer

Congratulations on your purchase, and welcome to Philips! To fully

benetfromthesupportthatPhilipsoffers,registeryourproductat

www.philips.com/welcome.

Introduction

Withthesubwoofer,youcanenjoyhighqualitysoundperformance

with powerful bass and beats.

What’s in the box A

Checkandidentifythecontentsofyourpackage:

aSubwoofer

b Screw_4x50mm(x10)

cFrame

2. Installation

Adepthofatleast124mmisrequiredtomountthesubwoofer.Measure

the depth of the area where you are to mount the subwoofer, and ensure

that the subwoofer does not obstruct any other components of the car.

Option 1: Mount on rear tray B

You can mount the subwoofer on the rear tray. a

1 Turnoffthecarignitionkey.

Ifthepowerison,theclicknoisegeneratedbytheconnection• maydamagethespeakers.

2Paste the supplied template onto the location for mounting the

subwoofer.

3 Markthecut-offholeandthe10boltholes. b

4 Cutoutthemarkedareaaanddrilltheboltholes. c

5 Connectthesubwoofertotheamplier. d

6 Mountthesubwooferintothereartraywiththesupplied

screws. e

Option 2: Install in a sealed enclosure C

If the subwoofer cannot be mounted on the car, place it in a sealed

enclosure. a

1 Makeasealedenclosureindimensionasbelow:

The box:

CSP1000 CSP1200

Height 338mm 358mm

Length 522mm 568mm

Width 232mm 238mm

The mounting hole:

CSP1000 CSP1200

Mounting hole diameter (Outside) 257. 3mm 307mm

Mounting hole diameter (Inside) 231.9mm 283.7mm

Screw hole diameter 3.3mm 3.3mm

2 Connectthesubwoofertotheamplier(seestep5of“Option1:

Mountonreartray”section).

3Install the subwoofer into the sealed enclosure with the supplied

screws. b

CSP1000_51_UM_V3.0

3. Product information

Note

Productinformationissubjecttochangewithoutpriornotice.

•

Model CSP1000 CSP1200

Speaker type 25cmsubwoofer 30cm subwoofer

RMS power (Watts) 250W 400W

Peak music power (Watts) 1000W 1600W

Sensitivity (dB/W/m) 88dB 89dB

Frequency response (Hz) 25-1000Hz 20-1500Hz

Impedance (ohms) 4 ohms 4 ohms

Magnet mass (Oz) 55.4Oz 55.4Oz

Mounting depth (mm) 124mm 146mm

4.Troubleshooting

Tokeepthewarrantyvalid,nevertrytorepairthesystemyourself.

If you encounter problems when using this apparatus, go to the Philips

website(www.philips.com/welcome).WhenyoucontactPhilips,ensure

that the apparatus is nearby and the model number and serial number

are available.
