Philips BT4200 Manual de usuario

2.0

BT4200

General information

Warnings

•Only use attachments or accessories specied by manufacturer.

•The battery shall not be exposed to excessive heat such as sunshine, re etc.

•Only for indoor use.

Care and safety information

Avoid high temperatures, moisture, water and dust

•Apparatus should not be exposed to dripping or splashing of liquid.

•Do not place any source of danger on the speaker

•Do not install near heat sources.

Do not block any ventilation opening

•

•Place the apparatus in a location with adequate ventilation to prevent internal heat build up. Allow at

least 10cm (4 inches) of free space all around the apparatus for adequate ventilation.

Care of the cabinet

•Use a soft cloth slightly moistened to clean the cabinet.

Do not use a solution containing alcohol, spirits, ammonia or abrasives.

Accessories

Item 3.5mm to stereo cable User manual USB cable

Quantity 1 1 1

Top & Back panel

86 7

AUX

ON OFF

DC IN

5V 1A

DC in USB socket

Top panel operation

A. Switch operation

B. LED

4. Yellow - charging and after fully charged it will be o.

5. Blue and Green - blue for BT and green for Aux in connection.

C. Back panel

6. AUX in - For Aux in cable in connection.

7. On/o - power on or o switch.

8. DC in USB socket - power in socket for charging from 5V DC,1A source only.

* In case of laptop BT connection, this will work with windows media player.

Prev Song/Track*

a. play or pause song

b. accept or reject an incoming call

Disconnect BT connection

Volume decreases,

when it reaches lower

volume it will make sound

Next Song/Track*

Volume increases,

when it reaches higher

volume it will make sound

short press

long press

mode.

AUX

mode.

Volume decreases,

when it reaches lower

volume it will make sound

Volume increases,

when it reaches higher

volume it will make sound

long press

1. 2. 3.

For bluetooth connection

1. When in Bluetooth mode, the speaker will give out 'Beep' sound, and the blue LED will ash quickly.

2. Turn on the bluetooth of the devices like mobile, computer or others, search the bluetooth name 'BT4200'.

3. Press 'Pair' in the device to connect with the speaker, it will give out a 'Beep' sound after pairing successfully.

Blue light will stop ash. (Normally no need to provide password. If need, just put '0000' as the password.)

4. After pairing sucessfully, the device will connect with speaker automatically next time.

Charging

Connect one side of the USB charging cable with the speaker, the other side connected with the

computor or a standard charger with 5V 800mA for charging. The LED light will be yellow when charging,

after it's full, the yellow light will disappear.

The charging time is 3~4 hours. The working time will depend on the volume user sets up.

When the speaker is low power, it will give out a 'Beep' sound, then it should be charged.

If no charging, the speaker will be shutdown for no power. If you are not using the speaker for long time,

ensure that it is being charged fully once every month in order to protect the battery.

Instruction of the LED light

Yellow light: Charging light;

Blue light: Bluetooth light and low power light.

Green light: AUX in connected

Troubleshooting

* In case these measures do not work contact the nearest PHILIPS service center or call at customer care numbers.

Warning -

Under no circumstances should you try to repair the system yourself, as this will invalidate the warranty.

below before taking the system for repair. If you are unable to remedy the problem by following hints

mentioned in below table, Consult your dealer or PHILIPS APSC for help.

Problem Solution

1. No power.

2. No sound or distorted sound.

3. Low hum or buzz sound.

4. No response from the speaker.

5. The audio quality is poor after

connection with Bluetooth enabled

device.

6. Cannot connect with the device.

Charge the unit by using USB charging cable.

Adjust the volume / select the correct source to choose the equipment

that you want to hear through the system.

Place the product as far away as possible from electrical devices that may be

causing interference.

Restart the speaker.

Move the device closer to this product or remove obstacle between them.

This product is already connected with another Bluetooth enabled device.

Disconnect that device and then try again.

This Philips 2.0 multimedia speakers system is warranted against any defect due to defective materials or

workmanship for 12 months from the date of purchase, should a defect develop during the period of warranty,

Gibson Innovations India Private Limited undertake to repair the apparatus FREE OF CHARGE through the dealer

from whom it has been purchased or at any of the Philips Authorised Service Centres.

The warranty is not valid in case :

1. Proof of purchase is not accompanied with this warranty card.

2. The warranty card is not completed immediately after purchase.

3. The apparatus is not used according to this manual.

4. Defects are caused by improper or reckless use.

5. Any repairs are done by persons other than Philips Authorised service centre.

7. The serial number is tampered with.

8. Defects due to causes beyond control like lightning, abnormal voltage, acts of God or while in

transit to the purchaser’s residence.

All consumables and parts susceptible to normal wear and tear are not covered under warranty.

Week/S.No.: ___________________________ Bill No. ___________________________

Date of purchase _________________________________________________________

Dealer’s name: ___________________________________________________________

Dealers stamp: __________________________________________________________

Customer’s name and address: _____________________________________________

Model No.: _____________________________________________________________

Dealer’s signature: ________________________________________________________

Warranty

Gibson Innovations India Private Limited 4th Floor, Block-1, Vatika Business Park, Sector 49, Sohna Road,

Gurgaon-122018, Haryana, India 07

Rated output power

Signal to Noise Ratio

10W RMS(5Wx2)

Audio input

Frequency Response

Speaker

Amplier

Bluetooth

>60db

Speaker Impedance 4 ohm

600MV

70Hz~20KHz

Speaker Driver 1.75 inch/4.5cm

80 dBm

Sensitivity

Bluetooth version V 4.0

V2.1+EDR

Bluetooth prole

Bluetooth freg 2.4GHz~248GHz

Bluetooth range Upto 10M(freespaee)

Or [email protected]

General Introduction

Power supply

Built in Battery Li-polymer battery

Dimension main unit 210x90x90

Weight 0.4 kg

5V, 1A

The Philips trademark and Philips shield emblem are

registered trademarks of koninklijke Philips N.V. used

under license.

This product has been manufactured by and sold

under the responsibility of Gibson Innovation India

Private Ltd. and Gibson Innovations India private Ltd.

is the warrantor in relation to this product.
