Philips CCD Manual de usuario
Technical specification
CCD CAMERA
Pick-up device 1/3" (Solid state CCD)
No. of picture elements
(H) x (V) 512 x 492 (EIA)
512 x 582 (CCIR)
Horizontal resolution > 380 TVL
Light sensitivity 0.5 ~ 30000 lux
Spectral sensitivity range 400 ~ 1000 nm
Signal to noise ratio >48dB
Output A/V RJ 11 E modular 'telephone'
socket
Built-in microphone electret
Lens type integrated
Lens viewing angle 59°H x 46°V
•focal length 4 mm
•relative aperture F 2.0
•focus range 1 ~ ∞m
Power supply 16 ~ 27 VDC (via system cable)
Power consumption 50 mA (at 24 VDC)
System cable 4-wire dual twisted pair
'telephone' cable
Tripod socket 1/4" B.S.W.
Dimensions (WxHxD) 70 x 70 x 79 mm (incl. lens)
Weight 205 gr
Ambient conditions Ammonia resistant
Ambient temperature
•operating +10 ~ +55°C
•storage -25 ~ +70°C
Ambient humidity
•operating 20% ~ 90%RH
•storage 99%RH
Specifications may be changed without notice.
53
12
53
4
CL 76610012_001.AI 00697
Figure A
5
4
3
2
4-5
2-3
5
4
3
2
4-5
2-3
5
4
3
2
5
4
3
2
Figure B
12
CL 76610012_002.AI 100697
13
CL 46610005/13G
10
CL 76610012_003.AI
0
X
1
200m
0-50m
100m
300m
0 X1
1415
R
A
E
N
>
<
R
A
F
1
CL 76610011_004.AI
Electro Magnetic Compatibility (EMC)
This equipment complies with European rules for EMC according to
EN55013, EN55020 and EN50082-1.
Operation is subject to the following two conditions:
1 This device may not cause harmful interference.
2 This device must accept any interference received, including interference
that may cause undesired operation.
The equipment conforms with the EMC directive and low-voltage
directive.
This device complies to FCC rules under test conditions that included
use of system cables and connectors between system components. If you
have any problems, contact your dealer.
Warnings
Any unauthorized modification to this equipment may cause violation of
the FCC rules resulting in the revocation of the authorization to operate
the equipment.
To prevent fire or shock hazard, do not expose this accessory to rain or
moisture. Do not attempt to disassemble the camera. In order to prevent
shock and fire hazard, do not remove screws or covers. There are no
user-serviceable parts inside.
The exclamation mark within a triangle is intended to alert the
user to the presence of important operating and maintenance
(servicing) instructions in the literature accompanying the
appliance.
g
g
1
Observation Camera
Introduction
Your new CCD camera is developed for use with a special observation
system monitor. It features a sensitive microphone thus registering both
images and sound via the monitor, as well as input contacts for
connecting external alarm devices.
Installation
Warning: "Disconnect the monitor from the mains supply before
disconnecting a camera or accessory.
Only operating the stand-by key is not sufficient.
When the mains supply is connected, all camera lines are scanned. The
monitor uses this to register the camera configuration of the system and
to check whether any modifications have been made.
Sound
If required, the microphone incorporated in the camera, can be switched
off (fig. A-14).
If an intercom box is included in the camera line, the sound of camera
and intercom box will be reproduced by the monitor.
English
The illustrations to which this manual refers, are shown on the front and
back jacket flap.
English
2
g
Alarm inputs
The camera has a three-pole terminal block (fig. A-13) for connecting
alarm sensors, such as doorcontacts. For normally open (N.O.) sensors,
connect to contacts N.O.. For normally closed (N.C.) sensors, connect to
contacts N.C..
Position
First you need to determine where the camera is to be installed. The best
results are obtained when the camera looks a little downwards and not
into a bright source of light.
•Hold the camera in your hand at the spot where you want to install it
and check on the monitor whether the camera does actually cover the
required area from that spot.
•Fasten the mounting bracket to the ceiling, the wall, or another even and
firm surface by means of the supplied screws and plugs.
•Tighten the knob (fig. A-3) of the ball-and-socket joint.
•Fasten the camera to the bracket by screwing the mounting hole in the
back or bottom of the camera (fig. A-1) onto the threaded end (fig. A-2).
•Loosen the knob of the ball-and-socket joint (fig. A-3) and, if necessary,
the screw (fig. A-4) on the mounting bracket and direct the camera
accurately at the object or area you want to have on screen.
•The knob and screw can be tightened again when the camera is in the
required position.
Remark: The camera can also be mounted on any other camera tripod
standardly provided with a 1/4" 20 UNC thread.
•Check if the cable length compensation (fig. A-15) selector is set to the
correct length. The length set must be the same as the length of the
system cable (0-300m/900ft max.) connecting monitor and camera.
Focus adjustment
Adjust the focus ring (fig. B-1) of the camera lens to obtain an optimal
image sharpness.
g
3
Protective cover
For outdoor use a protective cover (fig. A-10) (optional) has to be used to
protect the camera from rain and snow.
System connection
Connect the system cable to the output of the camera (fig. A-12).
The lens
Caution: Do not touch the glass of the lens. This could damage the delicate
coating on its surface. If the lens has to be cleaned, use a special lens cleaning tissue,
available at any good camera store.
Focus range
The built-in lens provides an optimal image sharpness for objects between
1 metre and infinity (depth of field).
Cable
A 4-wire system cable (see specifications) is supplied standardly.
For an optimum picture and sound quality a standard dual 'twisted-pair'
(telephone) cable should be used.
There is an extensive range of plugs and tools available in the hobby and
professional trade to extend the cable. Always pay attention that the
connection corresponds to figure B.
Caution: The plugs used for the observation system have the same dimensions as
standard telephone plugs. Never connect a telephone to the camera or system
monitor.
The maximum distance that can be bridged (without a cable extension
adapter) between the monitor and the cameras is 300 meters.
4
g
Tips for maintenance
Cleaning
The outside of the camera can be cleaned with a moist fluff-free cloth or
a shammy leather cloth.
When cleaning the objective a special lens cleaning cloth should be used.
Do NOT use cleaning fluids based on alcohol, methylated spirit,
ammonia, etc..
Avoid direct contact with water.
g
5
