Philips SBC RU 538 Manual de usuario

SBC RU 538/87U

Instructions for use

English 4

Instruzioni per l'uso

Italiano 12

Instrucciones de manejo

Español 20

Manual de utilização

Portugees 28

 

 36

Инструкции по

использованию

Русский 45

Návod k použití

Česky 53

Instrukcja obsługi

Polski 61

Universal

XP SBC RU 538/87.2 10-02-2004 09:54 Pagina 1

XP SBC RU 538/87.2 10-02-2004 09:54 Pagina 2

SBC RU 538

SHIFT

PROG

TV VCR DVD

VOL VOL

123

456

TITLE DISC ....

XP SBC RU 538/87.2 10-02-2004 09:54 Pagina 3

Contents

1. Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

2. Installing the remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-7

Inserting the batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Testing the remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Setting the remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Automatically setting the remote control . . . . . . . . . . . . . . . . . . . . . . . . 7

3. Keys and functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

4. Extra possibilities . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-10

Adjusting device selection (Mode-selector) . . . . . . . . . . . . . . . . . . . . . . 9

Adding a remote control function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Restoring the original remote control settings . . . . . . . . . . . . . . . . . . . 10

5. Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

6. Need help? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Code list of all brands / equipment . . . . . . . . . . . . . . . . . . . . . . . . . 69-78

1. Introduction

Congratulations on your purchase of the Philips SBC RU538 universal remote

control. After installing the remote control you can operate a maximum of

3 different appliances with it:TV,VCR and DVD players/recorders.

You can find information about how to prepare this remote control for use in

the chapter ‘Installing the remote control’.

Instructions for use

English

XP SBC RU 538/87.2 10-02-2004 09:54 Pagina 4

Instructions for use

English

2. Installing the remote control

Inserting the batteries

1Press the cover inwards and slide it in

the direction of the arrow.

2Place two R03, UM4 or AAA type batteries

into the battery compartment, as shown.

3Slide the cover back and click it firmly into

place.

Testing the remote control

The remote control has been programmed to operate most Philips

appliances. Because the RU538 may use different signals for each make and

even for different models of the same make, it is advisable to test whether

your appliance responds to the RU538.

The example below (TV) instructs you how to do this.

You can repeat the same steps for other appliances

(VCR and DVD players/recorders) which you want to operate using the

RU538.

Example of TV:

1Turn your TV on manually or use the original remote control.

Tune to channel 1.

2Use the RU538’s mode selector to select TV.

Press the key until the green light under TV in

the selector window lights up.

If no green light appears, check whether the

batteries are properly inserted

(see ‘Inserting the batteries’).

3Check whether all the keys are working.

For an overview of the keys and their

functions see ‘3. Keys and functions’.

– If the TV responds as it should to all of the

key commands the RU538 is ready for use.

• If the device does not respond at all or not to all of the

key commands, follow the instructions under

‘Setting the remote control’.

PROG

VOL VOL

TV VCR DVD

TITLE DISC ....

XP SBC RU 538/87.2 10-02-2004 09:54 Pagina 5

Setting the remote control

This is only necessary if your appliance does not respond to the RU538.

If that is the case, the RU538 does not recognize the brand and/or model of

your appliance and you need to program the remote control to do so.

The example below (TV) instructs you how to do this.

You can repeat the same steps for other appliances

(VCR, DVD player/recorder) which you want to operate using the RU538.

Example of TV:

1Turn on the TV manually or use the original remote control.

Tune in to channel 1.

2Look up the brand of your TV in the code list at the back of this

manual. One or more four-figure codes are shown for each brand.

Note the first code.

Be careful! There are separate tables for TV,VCR and DVD.

Make sure you use the codes from the correct table.

3Select TV with the mode selector.

(See ‘Testing the remote control’.)

4Keep keys ‘1’ and ‘3’ pressed simultaneously

for three seconds until the green light under

TV in the selector window flashes twice and

then remains lit.

5Then enter the code noted in step 2 using the digital keys.

– The green light in the selector window will now flash twice.

If the light flashes once for an extended period, the code has not been

entered properly or the wrong code has been entered.

Start again from step 2.

6Point the RU538 at the TV and check that it responds as it should.

– If the TV responds to all of the key commands, the RU538 is ready for

use. Do not forget to note your code.

• If the device does not respond at all, or not to all of the

key commands, start again from step 2 and try the next code

from the list.

SHIFT

123

456

TV VCR DVD

TITLE DISC ....

Instructions for use

English

XP SBC RU 538/87.2 10-02-2004 09:54 Pagina 6

Automatically setting the remote control

If you cannot find the right code for your brand device,

the remote control can automatically search for the right code.

Example of TV:

1Make sure the TV is switched on and select a channel using the original

remote control or the keys on the TV (for example channel 1).

The RU538 emits the ‘switch off TV’ signal for all models of TV that are

stored in the memory.

• If the device is a DVD-player or video recorder,

insert a disk or tape and start playback.

2Then keep keys 1 and 3 on the RU538

pressed simultaneously for three seconds,

until the green light under TV in the selector

window flashes twice and then remains lit.

3Press the Standby key of the RU538 briefly.

– The RU538 now starts emitting all known

‘TV off ’ signals, one by one.

Each time a code is sent, the green light under

TV in the selector window lights up.

4When your TV switches off (stand-by),

you press the Standby key of the RU538

twice within 1 second, to confirm.

– The RU538 has now found a code that works

on your TV.

5Check if you can operate all functions on your TV with the RU538.

• If this is not the case, you can redo the automatic setting.

The RU538 will then search for a code that perhaps works

better.

– After the RU538 has run through all the known codes,

the search will stop automatically and the green light will stop flashing.

– Automatic programming of a TV takes a maximum of 5 minutes.

For VCR and DVD this time is 2 minutes.

TV VCR DVD

TITLE DISC ....

TV VCR DVD

TITLE DISC ....

TV VCR DVD

TITLE DISC ....

SHIFT

123

456

Instructions for use

English

XP SBC RU 538/87.2 10-02-2004 09:54 Pagina 7

3. Keys and functions

The illustration on page 3 gives an overview of all keys and their functions.

1yStandby . . . . . . . . switches TV,VCR ,or DVD mode on or off.

2Mode-selector . . . . selects the device you want to operate:

TV,VCR or DVD.

3s. . . . . . . . . . . . . . . . mutes the sound of the TV.

4- VOL +. . . . . . . . . . . adjusts the TV volume.

5MENU . . . . . . . . . . . turns the menu on and off.

6Digital keys. . . . . . . direct choice of channels and other functions.

7SHIFT . . . . . . . . . . . for extra functions. When pressed at the same

time as a second key, the second key will get

another function. For example:

SHIFT + PROG+: . 'menu up'

SHIFT + PROG-:. . 'menu down'

SHIFT + VOL+: . . . 'menu right'

SHIFT + VOL-: . . . 'menu left'

Tr y out other combinations with the Shift-key on your appliance in order to

find out which functions are available.

Only functions featured on the original remote control are available.

81. . . . . . . . . . . . . . . . - red teletext key

- rewind (VCR/DVD)

99. . . . . . . . . . . . . . . . - green teletext key

- stop (VCR/DVD)

00. . . . . . . . . . . . . . . . tv: P1P, previous channel

VCR: record

DVD: clear

!;. . . . . . . . . . . . . . . . . - yellow teletext key

- pause (VCR/DVD)

@6. . . . . . . . . . . . . . . . - blue teletext key

- wind (VCR/DVD)

#2. . . . . . . . . . . . . . . . - white teletext key

- index

- play (VCR/DVD)

$/. . . . . . . . . . . . . . . . selects between one- and two-figure channel

numbers.

%OK. . . . . . . . . . . . . . . confirms your selection.

^- PROG + . . . . . . . . selects a previous or following channel.

&AV . . . . . . . . . . . . . . . switches between external inputs of your

equipment.

*. . . . . . . . TV: teletext keys

DVD: disc, title, eject, open/close, subtitle

VCR: timer, Showview

If you use the (ﬁ) 'memory off' key to get to the next teletext page on your

Philips TV, you can press the STOP key for this. See also ‘Troubleshooting’.

• If the device does not respond at all, or not to all of the key

commands, follow the instructions under ‘Setting the remote

control’. It is possible that you must enter another code for the

device.

TITLE DISC ....

Instructions for use

English

XP SBC RU 538/87.2 10-02-2004 09:54 Pagina 8

4. Extra possibilities

Adjusting device selection (Modeselector)

The RU538 is default set for operating TV,VCR and DVD.You can select the

device you wish to operate with the Mode selector. Each option allows

operation of one device only. If desired, you can program the Mode selector

to select a different kind of device.

For example, if you want to operate a second TV.

In the following example you will see how to configure the DVD mode for a

second TV.

1Switch on the second TV.

2Press the Mode selector to select DVD.

3Then keep 1 and 6 on the RU538 pressed

simultaneously for five seconds, until the

green light under DVD in the selector window

flashes twice and then remains lit.

4Press keys 9, 9 and 2, in that order.

5Press the Mode selector to select TV.

6Press the 1 key.

– The green light under DVD flashes twice.

DVD will now allow you to operate your

second TV.

7Program the RU538 to operate the second TV.

See ‘Setting the remote control’.

SHIFT

123

456

SHIFT

123

456

SHIFT

123

456

TV VCR DVD

TITLE DISC ....

Instructions for use

English

XP SBC RU 538/87.2 10-02-2004 09:54 Pagina 9

Adding a function to the remote control

If you want to add a function to the RU538, you can contact the

Philips service line for Universal Remote Control to ask for the 3-figure code

for the extra function.

1Using the Mode selector, select the device

for which you want to add the function.

2Then keep 1 and 6 on the RU538 pressed

simultaneously for five seconds, until the

green light under TV in the selector window

flashes twice and then remains lit.

3Press keys 9, 9 and 4, in that order.

4Enter the 3-figure code which you received from the service line within

thirty seconds.

5Press the key under which you want to store the new function.

– The light flashes twice.

The extra function has been successfully added to the RU538.

• If you want to store the function under Shift in combination with

another key, first press the Shift key and then press the required

function key.

• For restoring the original function of the key,

see ‘Restoring the original functions of your remote control’.

Restoring the original functions of your remote

control

1Keep keys 1 and 6 on the RU538 pressed

simultaneously for five seconds, until the

green light under TV in the selector window

flashes twice and then remains lit.

2Press keys 9, 8 and 1, in that order.

– The light flashes twice.

All original functions have now been restored

and any extra functions have been deleted.

SHIFT

123

456

SHIFT

123

456

SHIFT

123

456

SHIFT

123

456

TV VCR DVD

TITLE DISC ....

Instructions for use

English

XP SBC RU 538/87.2 10-02-2004 09:54 Pagina 10

Otros manuales para SBC RU 538

Este manual sirve para los siguientes modelos

Tabla de contenidos

Idiomas:

Otros manuales de Mando a distancia de Philips

Philips

Philips Prestigo SRU8015 Manual de usuario

Philips

Philips SRU2103S Manual de usuario

Philips

Philips SBCRU252/00 Manual de usuario

Philips

Philips SBCRU641/00 Manual de usuario

Philips

Philips Hue Bridge 2.0 Manual de usuario

Philips

Philips Prestigo SRU6006/10 Manual de usuario

Philips

Philips SBCRU440/00U Manual de usuario

Philips

Philips RC1974503/00RF Manual de usuario

Philips

Philips SRP2104/27 Manual de usuario

Philips

Philips ipronto TSi6400 Manual de usuario

Philips

Philips Trilingual Front CoverArt PHBIG3 Manual de usuario

Philips

Philips Perfect replacement SRP2003/27 Manual de usuario

Philips

Philips Elite SRP4219G/07 Manual de usuario

Philips

Philips SRU740NC/05 Manual de usuario

Philips

Philips SRC3036/27 Manual de instalación y operación

Philips

Philips Perfect replacement SRP5107WM/17 Manual de usuario

Philips

Philips SBCRU422 Manual de usuario

Philips

Philips SRU4002X/10 Manual de usuario

Philips

Philips SRP6207 Manual de usuario

Philips

Philips US2-PDVD6 Manual de usuario

Philips

Philips SRU4208WM/17 Manual de usuario

Philips

Philips Perfect replacement SRC2063WM Manual de usuario

Philips

Philips SpeechMike LFH3500 Manual de usuario

Philips

Philips Pronto TSU9405 Manual de usuario

Manuales populares de Mando a distancia de otras marcas

Panasonic

Panasonic EUR7622KB0 Manual de usuario

Bang & Olufsen

Bang & Olufsen Beo4 Manual de usuario

Sunwave Tech.

Sunwave Tech. RemoteComm SRC-7000 Manual de usuario

Multiplex

Multiplex PROFI TX 9 Manual de usuario

One Remote

One Remote RMB4 Manual de usuario

FUTABA

FUTABA 9ZAP - PART2 Manual de usuario

HR Matic

HR Matic HR MULTI 3 Manual de usuario

Yamaha

Yamaha ACC-GNRST-30-20 Manual de usuario

EisSound

EisSound KBSOUND Manual de usuario

Marantz

Marantz RC101 Manual de usuario

Conrad

Conrad FS20 TC6 Manual de usuario

Anritsu

Anritsu MP1777A Manual de usuario

Niles

Niles WVC100 Guía de solución de problemas

RCA

RCA RCU1300 Manual de usuario

Bang & Olufsen

Bang & Olufsen BEO6 Manual de usuario

GE 94901 Manual de usuario

Onbon

Onbon YQ1-75 Manual de usuario

FUTABA

FUTABA R7108SB Instrucciones de instalación
