Philips SA5000 Manual de usuario

SA5000

Philips Digital audio player

User manual

EN User manual 1

Need help?

1. Look up our Support Centre website

www.philips.com/support

2. Call our Customer Care helpline in your country

Country Helpdesk Tariff / min Keep ready

China 4008 800 008 Local tariff Date of Purchase, Model number and Serial number

Hong Kong 2619 9663 Local tariff Date of Purchase, Model number and Serial number

Korea 02 709 1200 Local tariff Date of Purchase, Model number and Serial number

Contents

4 How to UseThis Manual

5 Introduction

6 Accessories

7 Getting Started

7 Overview

9 LCD Display

9 Main Menu

10 Normal Playback Mode

11 Recharging the Li-Polymer Battery

11 Battery Status

12 Lock Switch

13 CD

14 Connecting and Disconnecting

14 Connecting to a Computer

15 Safely Removing from a Computer

16 Basic Usage

16 Power On

16 Power Off

17 Select and Enter a Function

17 Music

17 Music Playback

19 Adding Songs to a Playlist

19 Removing a Song from a Playlist

20 Deleting a Song from the Device

21 SRS WOW Enhancement Effect

22 Set EQ

22 Set Repeat Mode

23 Photo

23 View Photo

24 Slideshow

24 Rotate Photo

25 Puzzle

26 Multimedia

26 Play multimedia

27 Notes

27 Read *.txt File

28 Browser

28 Browse Contents

29 Setting

29 SRS

30 Set EQ

31 Set Repeat Mode

32 Record Quality / Source

33 Slide Interval / Slide Repeat / Transitions

34 Power Off

34 Backlight Off

35 Brightness

35 Language

36 Date and Time

37 Master Reset

38 Info

38 Record

38 Line-In Recording

39 Microphone Recording

40 Language Learning Function

41 Synchronize Songs

43 Specifications

44 Update / Recovery Firmware

44 Update Firmware

45 Recover Firmware

46 Important Safety Information

46 General Maintance

47 Hearing Safety

 

48 Copyright Information

48 Disposal of your old product

 

How to Use This Manual





ME / 2000 / XP, and that you are capable to follow the step-by-step instructions to install the

utility program used with the SA5000. For users who are not able to manage the operating

system properly, it is suggested that you first learn more about MicrosoftWindows by refer-



 Introduction, tells you about the main features of the SA5000 and lists the

accessories that included in the package.

 Getting Started, introduces the function keys on the SA5000, and shows the



 Connect and Disconnect, describes how to safely connect and disconnect

the SA5000 to and from your PC using the USB cable provided.

 Basic Usage,           

recommended that you read this chapter carefully before using your SA5000.

 Specification, 

 Update / Recover Firmware, describes how to recover and upgrade firmware

on the SA5000.

Congratulations on becoming a new owner of the SA5000.The new SA5000 improves the



The SA5000 is a high-performance, portable, digital audio player that enables users to play

MP3/ WMA audio, view M-JPEG and JPEG graphics, record voice/ Line-in, and to store per-



 Digital Audio Player

 Multimedia Player

 Photo Browser

 TXT File Reader

 Voice Recorder



 

 A-B Section Repeat         

normal playback. Using this function, users can focus on repeated playback to

learn a language.

 EQ and SRS effect

to enhance your music listening experience.

 USB Storage Device

capacity depends on the model you bought.)

 Micro SD Card Slot 



Introduction

 Hold Switch

for preventing any accidental operation while recording or playing. Once the

Hold Switch is switched to lock position, all function keys are disabled.

Accessories

Please check that all the following accessories are included when you open the packing box.

If any of the items are damaged or missing, please immediately contact the vendor where

you purchased the SA5000.

 

   

user manual

 

Getting Started

Overview

1 Display Screen Status and information is shown in this window.

2 MIC Built-in microphone.

3 Record

Repeat A->B



Mode).

Press to activate A-B repeat function during Playback Mode.

4 Lock switch Switch to the hold position to lock all buttons, preventing

any accidental operation. Switch back to unlock the buttons.

5 Exit/

Submenu

Press to exit to the previous menu level.

Hold for two seconds to display the available options.

6 Play/Pause

Power

Press to play a selected track.While playing, press to pause

playback and press again to resume.

When turned off, press once to power on; when turned on,

hold for 2 seconds to power off.

7 Up

Volume Up

Press to select items.

During playback, press to increase volume level.

8 Down

Volume Down

Press to select items.

During playback, press to decrease volume level.

9 Left

Previous/ Rewind

Press to select options.

During playback, press to go to the previous track, or press

and hold to rewind a track.

10 Right

Next/Forward

Press to select options.

During playback, press to go to the next track. Press and

hold to fast-forward a track.

11 PLAY/ Enter 

12 Strap Hole You can tie a strap here.

13 USB Connecter Connect one end of the supplied USB extension cable here

to connect to a PC, or to be USB Host.

14 In-ear headphones Jack Plug the supplied in-ear headphones in here.

15 Micro SD Slot 
