Philips ACT200 Manual de usuario

digital audio player

psa[64

Portable Sport Audio by Philips

product manual

controls and connections, accessories ––––––––––––––––––––––––– 4

minimum computer system requirements –––––––––––––––––––––––– 6

general information ––––––––––––––––––––––––––––––––––––––––––– 7

power supply ––––––––––––––––––––––––––––––––––––––––––––––––– 8

power on/off, playback and pause 2;

power saving mode ––––––––––––––––––––––––––––––––––––––––––– 9

adjusting volume - / + and eq settings––––––––––––––––––––––––– 10

selecting a different track

fast searching 5 , 6 –––––––––––––––––––––––––––––––––––––––– 11

button lock –––––––––––––––––––––––––––––––––––––––––––––– 11

remote control, clip magnets, armband –––––––––––––––––––– 12-14

psa audio management

installing musicmatch jukebox ––––––––––––––––––––––– 14-16

installing the psa drivers –––––––––––––––––––––––––––––––– 17

connecting the psa to your computer –––––––––––––––––––– 18

creating mp3 & windows media audio files from cds ––––– 19

playlist –––––––––––––––––––––––––––––––––––––––––––––––––– 20

download music to the psa from your computer –––––– 21-22

updating MUSICMATCH software,

upgrading your audio player ––––––––––––––––––––––––––––– 23

recovery –––––––––––––––––––––––––––––––––––––––––––––––– 24-25

helpful tips –––––––––––––––––––––––––––––––––––––––––––––– 26-27

technical data ––––––––––––––––––––––––––––––––––––––––––– 28-29

2 contents

in the U.K and certain countries, the copying of material protected by copyright

may require the permission of the copyright holders.

contents 3

this product complies with the radio interference requirements

of the European Union.

CAUTION

use this device according to the instructions that follow failure

to do so could be hazardous to your health.

users of pacemakers or other implanted devices should consult

their physician before using magnets or devices that may gen-

erate electro-magnetic interference.

environmental information

we have reduced the packaging to its minimum and made it easy to separate into

mono materials: PET, PS, PE.

your set consists of material which can be recycled if disassembled by a specialized

company. please observe the local regulations to dispose of packaging, exhausted

batteries and old equipment.

12;

switches the set on / off;

starts / pauses playback

25 / 6

skips to the beginning of a

previous/next track

3- / +

adjusts the volume

4indicator

lights up: red (battery low / power

down), green (power up) or orange

(button lock activated / pause mode)

5eq

enhance your listening experience.

select from 4 equalizer settings.

3.5 mm line out to connect

7locks buttons to prevent them

from being activated

8battery cover latch

uses 1 x AAA alkaline or Ni-MH bat-

tery

9usb in

(found in the battery compartment)

connect the supplied usb cable from

here to the usb port of your computer

supplied accessories

make sure these items are in the

package. if any item is missing,

please contact your dealer.

one usb cable

one psa software & user guide cd-rom

one set of headphones, HJ020

one remote control, AY3776

one set of clip magnets

one armband, AY3285

one AAA alkaline battery

4 controls and connections

the model & serial numbers are located inside the battery compartment.

controls 5

front view

rear view

Windows system requirements

you need to have a usb port. computers that were upgraded from Win 95 to Win 98

may not have usb compatibility! check out the other requirements:

– Pentium® MMX 166MHz processor or better

– usb port with Windows 98 / Me / 2000 / XP

– 64MB ram

– 50MB ram drive space

– cd rom drive

– video display card

– sound card

– Microsoft Internet Explorer 5.0 or better, Netscape 4.0 or better, and internet

access

Mac system requirements

– G3 or better

– MacOS 8.6- 9.x

6 minimum computer system requirements

psa[64 is a solid-state, portable, digital audio player:

– plays mp3 & windows media audio files e.g. digitized and compressed cd tracks,

tape tracks, audio books, newspapers, sound effects, etc., that are encoded into

mp3 & windows media audio format.

– software upgradeable and will support future playback formats and sofware exten-

sions that will be made available on www.nike-philips.com.

– will support for future digital rights management technology, including the Secure

Digital Music Initiative (SDMI).

take care when using headphones

hearing safety: listen at a moderate volume. using headphones at high volume can

impair your hearing.

traffic safety: do not use headphones while driving or cycling as you may cause an

accident.

general maintenance

to avoid damage or malfunction:

– do not expose to excessive heat caused by heating equipment or direct sunlight.

– do not drop the psa or allow objects to fall on the psa.

– do not allow the psa to be submersed in water. do not expose earphone socket or

battery compartment to water as water entering the set may cause major damage.

– do not use any cleaning agents containing alcohol, ammonia, benzene, or abra-

sives as these may harm the set.

– active mobile phones in the vicinity may cause interference.

general information 7

battery

1press 4to open the battery cover latch and insert

one AAA /UM4 /LRO3 battery (preferably

alkaline) or Ni-MH rechargeable as indicated.

2insert the lower edge of cover as shown to close

the battery cover latch.

beep beep! indication of empty battery

when the power level is almost empty, the psa64 will

beep at intervals and the inidicator lights up red. the psa will eventually switch

itself off. always replace the battery after the first battery

warning beep is heard.

IMPORTANT!

– remove the battery if: battery drained or the psa

will not be used for more than two weeks.

– batteries contain chemical substances, so they should

be disposed of properly.

8 power supply

power on and playback, 2;

press and hold 2; for 2 seconds to turn on.

– indicator: green light flashes briefly and play-

back starts automatically.

– psa beeps: if no content has been stored in

the psa, the psa powers down.

power off, 2;

press and hold 2; for 2 seconds to turn off.

– indicator: lights up red briefly.

pause, 2;

during playback, press 2; to pause. press 2;

again to resume playback.

indicator: if psa on pause, orange light flashes.

power-saving standby mode

the psa automatically switches off when playback is paused longer than 30 seconds

and no buttons are pressed.

power on/off, playback ... 2; 9

volume

press - / + to decrease / increase the volume.

eq sound options - bring out the bass or top up

on treble!

press eq again and again to select your equalizer

option.

10 adjusting volume - / + and eq settings
