Philips MCM765/77 Manual de usuario

MP3 LINK

Quick Start Guide

What’s in the Box?

You should find these items upon opening the box.

User Manual

FM antenna Remote Control

Quick Start Guide

User manual

MCM765

Pull out the plastic

protective sheet

before use.

MP3 cable

MCM765 QUG_Eng 2008.5.14, 11:041

Connect the speaker cables.

Connect the FM antennas.

Connect the power cable of the system.

Tip

See the User Manual for how to

connect other equipment to this

system.

Speaker

(right)

Speaker

(left)

AC power cord

FM wire antenna

Warning!

If your system is equipped with a

voltage selector, set the VOLTAGE

SELECTOR to the local power voltage.

Note:

There are two groups of wires for each speaker

box, one is blue-black wire for high frequency

(connect the blue wire to "+" and the black one

to "-"), and the other is red-black wire for low

frequency (connect the red wire to "+" and

black one to "-").

MCM765 QUG_Eng 2008.5.14, 11:042

Enjoy

Playing a disc

Press OPEN/CLOSEçto open the disc tray and load in a disc, then press the same

button again to close the disc tray.

➜Make sure the label side of the disc is facing up.

Press ÉÅ to start playback.

To stop playback, press 9.

Setting the clock

In standby mode, press and hold CLOCK SET on the system.

When the hour digits flash, turn the VOLUME control on the front panel to

set the hours.

Press CLOCK SET again and the minute digits flash.Then turn the

VOLUME control on the front panel to set the minutes.

Press CLOCK SET again to confirm the time setting.

MCM765

MP3 LINK

Notes for remote control:

– First select the source you wish to control by pressing one of the source select

keys on the remote control (for example iPod, TUNER).

– Then select the desired function (for example

, S, T).

MCM765 QUG_Eng 2008.5.14, 11:043

Enjoy

Insert the USB device’s USB plug into the socket on the set.

Press SOURCE once or more to select USB (or USB on the remote control).

Play the USB’s audio files as you do with the albums/tracks on a CD.

Playing a USB device

With the Hi-Fi system, you can use USB flash memory (USB 2.0 or USB1.1),

USB flash players (USB 2.0 or USB1.1), memory cards (requires an additional card reader to

work with this Hi-Fi system).

Tip

Detailed playback features and additional functions are described in the

accompany owner's manual.

CRoyal Philips Electronics N.V. 2008

http://www.philips.com PDCC-JS/JW-0815

Programming and tuning to

radio stations

Press SOURCE repeatedly to select the tuner source.

Press PROGRAM for more than two seconds to program all

available stations in order of waveband.

Press 4or 3until the desired preset station is displayed.

MCM765

MP3 LINK

MCM765 QUG_Eng 2008.5.14, 11:044
