Philips MCM2350/61 Manual de usuario

www.philips.com/support

User manual

Always there to help you

MCM2350

Question?

Contact

Philips

1EN

Contents

1 Important 2

Safety 2

Notice 2

2 Your Micro Music System 4

Introduction 4

What's in the box 4

Overview of the main unit 5

Overview of the remote control 6

3 Get started 7

Connect speakers 7

Connect power 7

Prepare the remote control 7

Demonstrate the features 8

Power on 8

Set the clock 8

Select a source 9

4 Play 10

Play from disc 10

Play from USB 10

Control play 10

Skip tracks 11

Program tracks 11

5 Listen to the radio 12

Tune to a radio station 12

Program radio stations automatically 12

Program radio stations manually 12

Select a preset radio station 12

6 Adjust sound 13

Select a preset sound effect 13

Adjust volume level 13

Mute sound 13

7 Other features 14

Set the alarm timer 14

Set the sleep timer 14

Listen to an external device 14

8 Product information 16

Specications 16

USB playability information 17

Supported MP3 disc formats 17

9 Troubleshooting 18

2EN

1 Important

Safety

Read and understand all instructions before

you use this micro music system. If damage is

caused by failure to follow the instructions, the

warranty does not apply.

This 'bolt of lightning' indicates uninsulated

material within the device may cause an

electrical shock. For the safety of everyone in

your household, please do not remove the

covering.

The 'exclamation mark' calls attention to

features for which you should read the enclosed

literature closely to prevent operating and

maintenance problems.

WARNING:Toreducetheriskofreorelectric

shock, the device should not be exposed to rain

ormoistureandobjectslledwithliquids,such

as vases, should not be placed on the device.

CAUTION:To prevent electric shock, fully

insert the plug. (For regions with polarized

plugs:To prevent electric shock, match wide

blade to wide slot.)

Safety

Warning

• Never remove the casing of this apparatus.

• Never lubricate any part of this apparatus.

• Never look into the laser beam inside this apparatus.

• Never place this apparatus on other electrical

equipment.

• Keep this apparatus away from direct sunlight, naked

amesorheat.

• Ensure that you always have easy access to the power

cord, plug or adaptor to disconnect the apparatus from

the power.

• The device shall not exposed to dripping

or splashing.

• Do no place any source of danger on the

device(e.g.liquidlledobjects.litcandles).

• Where the MAINS plug or an appliance

coupler is used as the disconnect device,

the disconnect device shall remain readily

operable.

• Make sure that there is enough free space

around the product for ventilation.

• Battery usage CAUTION –To prevent

battery leakage which may result in bodily

injury, property damage, or damage to the

unit:

• Install all batteries correctly, + and - as

marked on the unit.

• Do not mix batteries (old and new or

carbon and alkaline, etc.).

• Batteries (packed or installed) shall not

be exposed to excessive heat such as

sunshine,reorthelike.

• Remove batteries when the unit is not

used for a long time.

• Onlyuseattachments/accessoriesspecied

by the manufacturer.

Notice

Anychangesormodicationsmadetothis

device that are not expressly approved by

Gibson Innovations may void the user’s

authoritytooperatetheequipment.

3EN

Compliance

This product complies with the radio

interferencerequirementsoftheEuropean

Community.

This apparatus includes this label:

Care of the environment

Disposal of your old product and battery

Your product is designed and manufactured

withhighqualitymaterialsandcomponents,

which can be recycled and reused.

This symbol on a product means that the

product is covered by European Directive

2012/19/EU.

This symbol means that the product contains

batteries covered by European Directive

2013/56/EU which cannot be disposed of with

normal household waste.

Inform yourself about the local separate

collection system for electrical and electronic

products and batteries. Follow local rules and

never dispose of the product and batteries

with normal household waste. Correct disposal

of old products and batteries helps prevent

negativeconsequencesfortheenvironmentand

human health.

Removing the disposable batteries

To remove the disposable batteries, see battery

installation section.

Environmental information

All unnecessary packaging has been omitted.

We have tried to make the packaging easy to

separate into three materials: cardboard (box),

polystyrene foam (buffer) and polyethylene

(bags, protective foam sheet.)

Your system consists of materials which can

be recycled and reused if disassembled by

a specialized company. Please observe the

local regulations regarding the disposal of

packaging materials, exhausted batteries and old

equipment.

The making of unauthorized copies of copy-

protected material, including computer

programs,les,broadcastsandsound

recordings, may be an infringement of

copyrights and constitute a criminal offence.

Thisequipmentshouldnotbeusedforsuch

purposes.

Care for your product

• Do not insert any objects other than discs

into the disc compartment.

• Do not insert warped or cracked discs into

the disc compartment.

• Remove the discs from the disc

compartment if you are not using the

product for an extended period of time.

• Onlyusemicroberclothtocleanthe

product.

Note

• The type plate is located on the back of the product.

4EN

2 Your Micro

Music System

Congratulations on your purchase, and

welcometoPhilips!Tofullybenetfromthe

support that Philips offers, register your product

at www.philips.com/support.

Introduction

With this unit, you can:

• enjoy audio from discs, USB devices, and

other external devices;

• listen to radio stations.

You can enrich sound output with below

sound effect:

• Digital Sound Control (DSC)

The unit supports these media formats:

What's in the box

Check and identify the contents of your

package:

• Main unit

• Remote control (with one AAA battery)

• Speaker boxes (×2)

• Short user manual

• Safety and notice

5EN

Overview of the main unit

• Turn on the product.

• Switch to standby mode or ECO

power standby mode.

b AUDIO IN

• Connect external audio devices.

c Display panel

• Show current status.

d /

• Skip to previous/next track.

• Search within a track/disc.

• Tune to a radio station.

• Adjust time.

• Start or pause play.

f VOLUME knob

• Adjust volume.

• Open or close the disc compartment.

• Stop play.

• Erase a program.

i Disc compartment

ade

cb f

ghijkl

j SOURCE

• Select a source: DISC, USB,TUNER,

AUDIO IN.

• Connect USB storage devices.

l SPEAKER OUT socket

• Connect with the speakers.

m ANTENNA socket

• Connect with the FM antenna.

n AC MAINS ~

6EN

Overview of the remote

control

• Turn the unit on or off.

• Switch to standby mode or ECO

power standby mode.

b CD

• Select CD source.

c USB

• Select USB source.

d /

• Skip to the previous/next track.

• Search within a track/disc/USB.

• Tune to a radio station.

• Adjust time.

• Play tracks randomly.

f ALBUM/PRESET /

• Select a preset radio station.

• Skip to previous/next album.

g DISPLAY

• Adjust display brightness.

• During playback, display the play

information.

h SLEEP/TIMER

• Set sleep timer.

• Set alarm timer.

i CLOCK

• Set the clock.

• View clock information.

j PROG

• Program tracks.

• Program radio stations.

• Auto store FM radio stations.

• Mute or unmute the sound.

l SOUND

• Enrich sound effect with Digital Sound

Control (DSC).

m VOL +/-

• Adjust volume.

• Play a track or all tracks repeatedly.

• Stop play or erase a program.

• Start, pause, or resume play.

q FM

• Select FM source.

r AUDIO IN

• Select AUDIO IN source.

7EN

3 Get started

Caution

• Use of controls or adjustments or performance of

procedures other than herein may result in hazardous

laser exposure or other unsafe operation.

Always follow the instructions in this chapter in

sequence.

Connect speakers

Note

• Insert the stripped portion of each speaker wire into

the socket completely.

• Forbettersoundquality,usethesuppliedspeakersonly.

1 Fortherightspeaker,ndthesocketson

the back of the main unit marked "R".

2 Insert the red wire into the red (+) socket,

and the black wire into the black (-) socket.

3 Fortheleftspeaker,ndthesocketsonthe

main unit marked "L".

4 Repeat step 2 to insert the left speaker

wire.

To insert each speaker wire:

1 Holddownthesocketap.

2 Insert the speaker wire fully.

3 Releasethesocketap.

Connect power

Caution

• Risk of product damage! Ensure that the power supply

voltage corresponds to the voltage printed on the back

or the underside of the unit.

• Before you connect the AC power cord, ensure that

you have completed all other connections.

Connect the power cable to the wall socket.

Prepare the remote control

Caution

• Risk of product damage! When the remote control is

not used for long periods, remove the batteries.

To insert the remote control battery:

1 Open the battery compartment.

2 Insert the supplied AAA battery with

correct polarity (+/-) as indicated.

3 Close the battery compartment.

8EN

Demonstrate the features

In standby mode, press to demonstrate

features of this device.

» The features are displayed one by one

across the display panel.

• To turn off the demonstration, press

again.

Power on

Press .

» The product switches to the last selected

source.

Switch to standby mode

Press again to switch the product to standby

mode.

» The clock (if set) is displayed on the

panel.

• In standby mode, press to switch

between working mode and standby

mode.

Note

• The product switches to standby mode after 15

minutes inactive.

Switch to ECO power standby mode

Press and hold for more than two seconds.

» The red ECO power standby indicator

turns on.

• In Eco power standby mode, press to

switch between working mode and ECO

power standby mode.

Note

• The product switches to ECO power standby mode

after 15 minutes in standby mode.

Switch between standby mode and ECO

powerstandby mode:

• Press and hold for more than two

seconds.

Note

• If no button is pressed over 15 minutes in standby

mode, this product goes to ECO standby mode

automatically.

Set the clock

1 In standby mode, press and hold CLOCK

for more than two seconds to enter the

clock setting mode.

» [24H] or [12H] is displayed.

2 Press / to select 24H or 12H hour

format, and then press CLOCK.

» The hour digits begin to blink.

3 Press / to set the hour, and then

press CLOCK.

» The minute digits begin to blink.

4 Press / to set the minute, and then

press CLOCK.

» The set clock is displayed.

Note

• To view clock information in working mode, press

CLOCK.

• If no button is pressed in 90 seconds during setting,

the product exits clock setting without saving earlier

operations.

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Micro sistema de música de Philips

Philips

Philips DCM378 Manual de usuario

Philips

Philips DCM713/12 Manual de usuario

Philips

Philips MCM765/55 Manual de usuario

Philips

Philips DCM1130/12 Manual de usuario

Philips

Philips MCDB710/05 Manual de usuario

Philips

Philips MCM103B/77 Manual de usuario

Philips

Philips DualDock DCM3260 Manual de usuario

Philips

Philips MCM103/93 Manual de usuario

Philips

Philips MCM1055/96 Manual de usuario

Philips

Philips MCM1150 Manual de usuario

Philips

Philips MCM177/05 Manual de usuario

Philips

Philips MCD177/98 Manual de usuario

Philips

Philips BTM2660 Manual de usuario

Philips

Philips MCD710/12 Manual de usuario

Philips

Philips DCM276 Manual de usuario

Philips

Philips MCM148 Manual de usuario

Philips

Philips MCM1110/12 Manual de usuario

Philips

Philips MCB2305 Manual de usuario

Philips

Philips MCD113/93 Manual de usuario

Philips

Philips DCB2272 Hoja de información del producto

Philips

Philips DCM186/12 Manual de usuario

Philips

Philips DCM2260 Manual de usuario

Philips

Philips MCM2300/55 Manual de usuario

Philips

Philips DCB3270W Manual de usuario

Manuales populares de Micro sistema de música de otras marcas

Rautz

Rautz MC-5100DU Manual de usuario

Sanyo

Sanyo DC-D9 Manual de usuario

Curtis

Curtis RCD744 Manual de usuario

Samsung

Samsung MM-UC8 Manual de usuario

Akai

Akai AMP300UCI Manual de usuario

Hyundai

Hyundai MS 132 DU3BL Manual de usuario

JVC

JVC UX-GP5 Manual de usuario

Tiger Electronics

Tiger Electronics Hitclips Beat Bot 6000 Manual de usuario

Optimus

Optimus SYSTEM 731 Manual de usuario

Hitachi

Hitachi AXM209UK Manual de usuario

Sharp

Sharp XL-MP110DVD Manual de usuario

Tiger Electronics

Tiger Electronics Hitclips Micro Music Watch 59947 Manual de usuario

ProAudio

ProAudio MC 9010 iP Manual de usuario

Samsung

Samsung MM-ZJ9 Manual de usuario

Sharp

Sharp MD-X7 Manual de usuario

Sharp

Sharp DK-KP95P Manual de usuario

Akura

Akura APTCDC832PR Manual de usuario

iLive

iLive IHB248B Manual de usuario
