Philips MCD1165 Manual de usuario

Philips

Micro music system

70W

MCD1165

Enjoy great movie experience

Obsessed with sound

Be assured of cinematic room-filling sound with the Philips DVD micro system

MCD1165. The speaker system backed with 70W RMS maximum output power allows

you to feel every sound effect. Also features USB Direct for photo and music playback.

Enjoy your favorite movies and music

• Play DVD, (S)VCD, MP3-CD, CD(RW) and Picture CD

• Dolby Digital for ultimate movie experience

• USB Direct for photos and MP3/WMA music playback

• Karaoke for endless singing entertainment at home

Enrich your sound experience

• Bass Reflex Speaker System delivers a powerful, deeper bass

• 70W RMS maximum output power

• Digital Sound Control for optimized music style settings

Easy to use

• FM digital tuning to preset up to 20 stations

• Motorized CD loader for convenience access

• Wake up and sleep timer functions

MCD1165/55

Highlights

Micro music system

70W

Bass Reflex Speaker System

Bass Reflex Speaker System delivers a deep

bass experience from a compact loudspeaker

box system. It differs from a conventional

loudspeaker box system in the addition of a

bass pipe that is acoustically aligned to the

woofer to optimize the low frequency roll-off

of the system. The result is deeper controlled

bass and lower distortion. The system works

by resonating the air mass in the bass pipe to

vibrate like a conventional woofer. Combined

with the response of the woofer, the system

extends the overall low frequency sounds to

create a whole new dimension of deep bass.

Karaoke for endless singing

Karaoke for endless singing entertainment at

home

Digital Sound Control

Digital Sound Control offers you a choice of

pre-set Balance, Clear, Powerful, Warm and

Bright controls you can use to optimise the

frequency ranges for different musical styles.

Each mode uses graphic equalizing technology

to automatically adjust the sound balance and

enhance the most important sound

frequencies in your chosen music style.

Ultimately, Digital Sound Control makes it

easy for you get the most out of your music by

precisely adjusting the sound balance to match

the type of music you are playing.

Issue date 2013-04-15

Version: 1.0.2

12 NC: 8670 001 02907

EAN: 87 12581 68751 9

Specifications are subject to change without notice.

Trademarks are the property of Koninklijke Philips

Electronics N.V. or their respective owners.

www.philips.com

MCD1165/55

Specifications

Micro music system

70W

Sound

• Sound Enhancement: Digital Sound Control

• Sound System: Dolby Digital

• Maximum output power (RMS): 70W

Loudspeakers

• Speaker drivers: 3.5"

• Subwoofer types: passive

Video Playback

• Playback Media: DivX, DVD-Video, Picture CD,

Video CD/SVCD, DVD+R/+RW, DVD-R/-RW

• Disc Playback Modes: A-B Repeat, Angle, PBC,

Slow Motion, Zoom, Parental control, Disc Menu,

Fast Backward, Fast Forward, OSD, Resume

Playback from Stop

•DVDRegion.:4

• Video Enhancement: Progressive Scan

Audio Playback

• Playback Media: MP3-CD, CD, CD-R, CD-RW

• Disc Playback Modes: 20-Track Programmable,

Repeat/one/all/program, Shuffle Play, Fast Forward/

Backward, Next/Previous Track Search

• Loader Type: Motorised, Tray

• USB Direct Modes: Fast Backward/Fast Forward,

Play/Pause, Previous/Next, Program Play, Repeat,

Shuffle, Stop

Still Picture Playback

• Picture Compression Format: JPEG

• Picture Enhancement: Slideshow with MP3

playback

• Playback Media: Picture CD, CD-R/RW, DVD+R/

+RW

Tuner/Reception/Transmission

• Tuner Bands: FM Stereo

• Auto digital tuning

• Tuner Enhancements: Auto Store

• Station presets: 20

Connectivity

• Video Output - Analog: Composite CVBS (yellow

cinch), Component Y Pb Pr (cinch)

• Audio Connections: Analogue Audio In (L/R)

• USB: USB host

• Microphone: Microphone socket

Convenience

• Alarms: CD Alarm, Sleep timer, Radio Alarm, USB

alarm

• Clock: On main display

• Indications: DIM mode

Accessories

• Included accessories: Composite video cable (Y),

AC Power Cord

• User Manual: Multi-languages

•Remotecontrol

Dimensions

•Grossweight:7.5kg

• Main unit depth: 220.4 mm

• Main unit height: 119 mm

• Main unit width: 180 mm

• Main speaker dimensions (W x D): 127 x 160 mm

• Main speaker height: 170 mm

• Subwoofer dimensions (W x H x D):

170x 265 x 250 mm

• Packaging depth: 557 mm

• Packaging height: 244 mm

• Packaging width: 557 mm

Power

• Power supply: 100-240V, 50/60 Hz

•
