Philips DCM2170/12 Manual de usuario

Philips

Micro music system

•iPhone5

• with Lightning connector

DCM2170

Sound that fits your home

Obsessed with sound

Compatible with the iPhone 5's Lightning connector, this Philips micro sound system

delivers great sound as well as a great, stylish design. Sit back and relax, enjoy your music

your way, with one simple control.

Enrich your sound experience

• Bass Reflex Speaker System delivers a powerful, deeper bass

• Digital Sound Control for optimized music style settings

• 70W RMS maximum output power

Enjoy your music from multiple sources

• Fast charging and play music via Lightning connector

• Play MP3/WMA-CD, CD and CD-RW

• USB Direct for MP3/WMA music playback

• Audio-in for portable music playback

• Digital tuning with preset stations for extra convenience

DCM2170/12

Highlights

Micro music system

iPhone 5 with Lightning connector

Play and charge via Lightning

Enjoy your favorite music while charging your

iPod/iPhone via the new Lightning connector!

Just dock it directly on the speaker to play your

hand-picked tunes in superb sound. It also

charges your device quickly while playing, so

you don't have to work about the battery

running out.

Bass Reflex Speaker System

Bass Reflex Speaker System delivers a deep

bass experience from a compact loudspeaker

box system. It differs from a conventional

loudspeaker box system in the addition of a

bass pipe that is acoustically aligned to the

woofer to optimize the low frequency roll-off

of the system. The result is deeper controlled

bass and lower distortion. The system works

by resonating the air mass in the bass pipe to

vibrate like a conventional woofer. Combined

with the response of the woofer, the system

extends the overall low frequency sounds to

create a whole new dimension of deep bass.

Digital Sound Control

Digital Sound Control offers you a choice of

pre-set Jazz, Rock, Pop and Classic controls

you can use to optimise the frequency ranges

for different musical styles. Each mode uses

graphic equalizing technology to automatically

adjust the sound balance and enhance the most

important sound frequencies in your chosen

music style. Ultimately, Digital Sound Control

makes it easy for you get the most out of your

music by precisely adjusting the sound balance

to match the type of music you are playing.

Audio-in

The Audio in connectivity allows direct

playback of Audio in content from portable

media players. Besides the benefit of enjoying

your favorite music in the superior sound

quality delivered by the audio system, the

Audio in is also extremely convenient as all you

have to do is to plug your portable MP3 player

to the audio system.

USB Direct

With the USB Direct mode, simply plug in your

USB device to the USB port on your Philips

device and your digital music will be played

directly from the Philips device.

Issue date 2013-05-21

Version: 1.0.8

12 NC: 8670 001 01979

EAN: 87 12581 68401 3

Specifications are subject to change without notice.

Trademarks are the property of Koninklijke Philips N.V.

or their respective owners.

www.philips.com

DCM2170/12

Specifications

Micro music system

iPhone 5 with Lightning connector

Audio playback

• Playback media: CD, CD-R, CD-RW, MP3-CD,

WMA-CD

• Disc playback modes: fast forward/backward, next/

previous track search, repeat/shuffle/program

• Others: ID3-tag support

• USB Direct playback modes: fast backward/fast

forward, play/pause, previous/next, program play,

repeat, shuffle, stop

• Docking playback modes: fast forward and

backward, next and previous track, play and pause

Sound

• Sound enhancement: digital sound control

• Volume control: up/down

• Maximum output power (RMS): 70W

Loudspeakers

• Speaker types: bass reflex speaker system

• Speaker drivers: 4" woofer with soft dome tweeter

Tuner/Reception/Transmission

• Tuner bands: FM stereo

• Station presets: 20

• Tuner enhancement: auto digital tuning

Connectivity

• Audio in (3.5mm)

• USB: USB host

Convenience

• Alarms: CD alarm, radio alarm, iPod alarm, USB

alarm

• Loader type: tray

• Charging device: iPhone, iPod

Accessories

•Remotecontrol

• User Manual: multi-languages

Dimensions

•Grossweight:5.7kg

• Main speaker dimensions (W x D): 140 x 185 mm

• Main speaker height: 260 mm

• Main unit width: 180 mm

• Main unit height: 177 mm

• Main unit depth: 239 mm

• Packaging width: 224 mm

• Packaging height: 314 mm

• Packaging depth: 518 mm

Power

• Power supply: 110-240V, 50/60Hz

iPod compatibility

• Compatible with: iPod nano 7th generation, iPod

touch 5th generation

iPhone compatibility

• Compatible with: iPhone 5

•
