Philips DCB146/12 Manual de usuario

DCB146

www.philips.com/welcome

Quick Start Guide

User Manual

Remote Control

Main unit

User Manual Quick Start Guide

2 x Loudspeaker boxes

4 x iPod adaptors

Quick Start Guide

DCB146_12_QSG_EN_V1.1.indd 1 2010-6-10 16:16:43

PULL TO OPEN

AConnect

BPlay a disc

1Press DISC to select the disc source.

2Lift the CD door on the top of the system

to open the CD compartment.

3Insert a disc with the printed side facing up

and press down the CD door to close the

CD compartment.

4Press to start playback.

1 Fortherightspeaker,ndthesocketson

the main unit marked ‘RIGHT’.

2Insert the red wire to the red (+) socket.

3Insert the black wire into the black (-)

socket.

4 Fortheleftspeaker,ndthesocketsonthe

main unit marked ‘LEFT’.

5Repeat steps 2-3.

1Connect the power adaptor to the wall

outlet.

DCB146_12_QSG_EN_V1.1.indd 2 2010-6-10 16:16:44

Play from iPod

Tune to DAB stations

Program and tune to FM stations

1Press SOURCE to select DAB to start an

automatic search of available DAB stations.

2Press / to change the DAB stations.

3Press OKtoconrmaselection.

4 Toperformascan,pressbrieySCAN.

5To access setup options, press MENU

then use the navigation control buttons to

select.

1Select TUNER source.

2Press SCAN for more than two seconds to

program all available stations (FM only).

3Press / to select the desired preset

station.

Tip

Detailed playback features and additional•

functions are described in the accompanied user

manual.

MIC

PUSH TO OPEN

DOCK FOR iPOD

RO SYSTEMDCB146

SOURCE

DOCK

STANDBY-ON

CD/CD-R/CD-RW COMPAT IBLE

PRESET

VOL

TUNING

1Select a dock adaptor (supplied) that

matches your iPod type.

2Press PUSH TO OPEN to open the dock

on the main unit.

3Snap the suitable dock adaptor into the

dock on the main unit.

4Plug your iPod into the dock adaptor.

5Press iPod on the remote control to select

iPod source.

The connected iPod plays automatically.»

DCB146_12_QSG_EN_V1.1.indd 3 2010-6-10 16:16:45

DCB146_12_QSG_V1.1

FSet clock

1Press and hold CLOCK/DISPLAY on the

remote control for 2 seconds.

2Press PROG repeatedly to select 12 hour

or 24 hour format.

3Press CLOCK/DISPLAYtoconrmthe

selection.

4Press / to set the hour.

5Press CLOCK/DISPLAYtoconrmthe

hour setting.

6Press / to set the minute.

7Press CLOCK/DISPLAYtoconrmthe

setting.

DCB146_12_QSG_EN_V1.1.indd 4 2010-6-10 16:16:46
