Philips Streamium WAS7000 Guía de inicio rápido

WAS7000

Connect to your PC

Connect Philips Wireless Music Station to your PC if you want to do

the following:

●Access music files stored on your PC from Philips Music Station’s

UPnP source

●Upgrade firmware of Philips Music Station

REC MARK/UNMARK

DBB

SEARCHCD/MP3-CD HD SOURCE

SOURCE

To connect to Philips Music Station, your minimum PC requirements must be:

UPnP playback

●Windows 2000/XP (Home or Professional)

●Pentium III 500MHz processor or higher

●256MB RAM

●CD-ROM Drive

●Ethernet Adapter (for wired connection)/ Wireless

Network Adaptor 802.11 b/g (for wireless connection)

●Free hard disk space of 500MB

●Windows Media Player® 9.0 or later installed

Wireless Music Station

Eng

Set up a wired connection

Connect the Station to PC directly with the supplied (orange)

Ethernet cable

Connect the Station directly to Access Point with the supplied

(orange) Ethernet cable

Tips:

●Make sure that Ethernet port on your PC is 'Enabled' to make WADM

connection.

ETHERNET

LAN

Set up a wireless connection

PC StationAccess Point PC Station

On Station :

●Press the MENU button

●Select Settings>Network >

Wireless > (Select desired net-

work) >

(Input the encryption key by

using the 1way remote con-

trol) > Automatic > Apply

Settings > Yes

Do you have a wireless Access Point?

YES NO

a. On Station :

●Press SOURCE to enter

UPnP mode

●Press MENU, select

Information >Wireless> SSID

> (write down SSID code)

●Press MENU, select

Information >Wireless> WEB

Key > (write down WEB key)

b. On PC :

●Select Start > Control Panel >

Network Connections >

Enable Wireless Network

Connections > View Available

Wireless Networks > Select

the network that matches

Station's SSID > Input

retrieved Station’s WEP key

Tips:

●Check that PC’s wireless network adaptor is enabled.

●Locate the Station closer to your wireless Access Point.

●Make sure that DHCP is enabled on your wireless Access Point.

If not available, choose Static and key in IP configuration

Install and launch WADM

Insert PC Suite CD into PC

Select desired language and accept license terms

Select ‘WADM’ and select ‘Next’ to start installation

To launch WADM, double click the desktop icon

A list of found Center/ Station appears

Select desired Station, and then click Connect now

Tips:

●Log onto your PC with administrator's privileges enabled.

●If Station’s IP configuration is not in the default range (Subnet mask: 255.255.0.0;

IP address: 172.31.x.x). Select Connection Wizard >Custom Mode. Input

Station’s current IP configuration as prompted. Press the MENU button and

select Information >Ethernet to check IP configuration.

●For Windows®XP SP2 users, make sure your Windows Firewall has been

turned off by clicking Start >Control Panel >Security Center >

Windows Firewall >Off (Visit www.microsoft.com for more details).

●If some of the WADM functions cannot be used, it might be because

your anti-virus software blocked them. It is recommended to turn off

your anti-virus software temporarily.

●When WADM is running, Internet access may be disabled. Close WADM to

restore access.

●If your PC operation system is Windows Vista, please right click on

WADM, select Properties --> Compatibility, and make sure the

check-box under "Compatibility mode" and "Privilege level" is marked,

then click OK. Otherwise your WADM may not able to be launched.

Install and launch WADM

If desired Station is not found :

●Wired connection: Select Connection Wizard >

Express mode>Next to build new connection

Note: If you selected Connection Wizard >Custom mode,

it will select Wireless network adaptor automatically by

default if the PC has both wired and wireless adapter.

Please select Wired network adaptor manually.

●Wireless connection: Check that wireless Access Point is

broadcasting preferred wireless network SSID AND that PC’s

wireless network adaptor is working

Use WADM

In the sub-menu of Device configuration, you can see System

information, manage the Network settings, upgrade Firmware,

and to view the device's connection with external network.

For details on how to upgrade firmware, see User Manual:

Firmware upgrade

Check you have installed Philips

Media Manager (PMM) on PC

To launch PMM, double click the

desktop icon if it is created

The first time you launch PMM,click Add Music >Add Files or

Folders to specify music folders on your PC

Station:

Press SOURCE, and then

select preferred music server

Use UPnP

REC MARK/UNMARK

DBB

SEARCHCD/MP3-CD HD SOURCE

SOURCE

Tips:

●UPnP device may not necessarily be a PC but any content serving

device.

●If UPnP device is not detected after 5 minutes, powering it off and

on again might re-establish a faster connection.

Specifications are subject to change without notice.

Trademarks aree the property of Koninklijke Philips Electronics N.V. or their respective owners.

www.philips.com

CountryCountry HelpdeskHelpdesk Tariff / minTariff / min Keep readyKeep ready

0820 901115

070 253 010

3525 8761

09 2290 1908

08 9165 0006

0180 5 007 532

0 0800 3122 1223

01 601 1161

199 404 042

26 84 30 00

0900 0400 063

2270 8250

2 1359 1440

902 888 785

08 632 0016

02 2310 2116

0906 1010 017

Need help?

Online help: www.philips.com/support

Contact line: 1 800 531 0039

Gracenote and are registered trademarks of Gracenote.The Gracenote logo and

logotype, and the “Powered by Gracenote” logo are trademarks of Gracenote.
