Philips MCD708/37B Manual de usuario

MCD 708

Quick Start Guide

What’s in the Box?

You should find these items upon opening the box.

User Manual

Quick Start Guide

Quick start guide

User manual

Composite video and audio

cables

(yellow, white, red)

Remote control with two

AAA batteries

FM and AM antennas

Control Cable

MCD708 QUG_Eng-37 2006.3.6, 13:521

SUB WOOFER

LINE OUT

OFER

Tips

–See the User Manual for otherTV

connection options.

–For connecting to a Progressive Scan

TV, refer to the user manual for proper

connections and detailed setup.

Setting up the TV

Press SOURCE (DISC on the remote) to select disc source.

Turn on the TV and set it to the correct Video In channel.

Connect the speaker cables.

Connect the AM and FM antennas.

Connect the control cable.

Connect the composite video and audio cables to a TV.

Connect the power cords of the system and TV.

AC power

FM antenna

AM antenna

Speaker

(right)

Speaker

(left)

MCD708 QUG_Eng-37 2006.3.6, 13:522

Setting the clock

In standby mode, press and hold CLOCK on the remote.

When the hour digits flash, turn VOLUME-/+ on the system or press VOLUME+/- on the

remote to set the hours.

Press CLOCK again and the minute digits flash.Then turn VOLUME-/+ on the system or

press VOLUME+/- on the remote to set the minutes.

Press CLOCK again to confirm the time setting.

Setting DVD menu options

IMPORTANT!

If the progressive scan feature is activated but the connected TV does not support

progressive signals or the cables are not connected accordingly, see the user

manual for proper progressive scan setup or deactivate the progressive scan

feature as below:

1) Turn off your TV progressive scan mode or turn on to interlaced mode.

2) Press SYSTEM on the remote to exit the system menu and then DISC to exit

progressive scan.

Tip

See chapters "Getting Started" and "System Menu Options" in the

User Manual for detailed descriptions.

MCD708 QUG_Eng-37 2006.3.6, 13:523

Playing a disc

Press OPEN •CLOSEç(çon the remote) to open the disc tray and load in a disc,

then press the same button again to close the disc tray.

Load in a disc with the label side facing up.

Playback will start automatically. If not pressÉÅ.

To stop playback, press PRESET-/9(9on the remote).

Programming and tuning to radio stations

Press SOURCE (TUNER on the remote) to select tuner source.

Press PROG on the remote for more than two seconds to program all available stations in

order of waveband.

Press PRESET+/- (CH +/- (¡/ ™)on the remote) until the desired preset station is

displayed.

PDCC-JS/JW-0609

2005 CKoninklijie Philips Electronics

http://www.philips.com

Tip

Detailed playback features and

additional functions are described in the

accompany owner's manual.

Notes for remote control:

–First, select the source you wish to control by

pressing one of the source select keys on the

remote control (DISC orTUNER, for example).

–Then select the desired function (

for example).

MCD708 QUG_Eng-37 2006.3.6, 13:524
