3Enjoy
What’s in the box?
Start disc playback
APress çto open the disc tray.
BPlace a disc with the disc label facing up.
CPress çto close the disc tray.
DPlayback starts automatically.
EIf the disc menu appears on the TV, use
keys or the numeric keypad to select an option in
the menu and press OK to start playback.
FPress to stop playback.
Note When you press ubutton,
playback resumes from where it last stopped.
To start playback from the beginning, you
have to press .
Need help?
User Manual
See the user manual that came with your Philips DVD Home Theatre System.
2008 CKoninklijke Philips N.V.
All rights reserved.
www.philips.com
Listen to radio
APress RADIO.
The display panel will show “AUTO INSTALL ....
PRESS PLAY”.
BPress u.
All the available radio stations with strong reception
signal will be stored automatically.
Note This feature is only available for the rst time
setup. If you wish to reinstall all the radio stations,
press and hold REPEAT (PROGRAM) until ‘START’
appears on the display panel.
COnce complete, use íë keys or numeric keypad
(0-9) to select a preset radio station.
DTo delete a preset radio station, press and hold x
until “FM/AM/MW X DELETED” appears.
Experience surround sound
APress SURROUND to switch between Multi-
Channel, Stereo sound or Party sound.
BPress SOUND MODE +- to select a preset
digital sound effect.
Register your product and get support at
www.philips.com/welcome
Quick Start Guide
Connect
Set up
Enjoy
1
2
3
HTS3011
Main Unit Remote Control
and 2 batteries
User
Manual
1 centre, 2 front, 2 rear speakers
and subwoofer
FM wire antenna
Composite
video cable
hts3011_98_qsg_eng_final808.indd1 1hts3011_98_qsg_eng_final808.indd1 1 2008-02-21 4:25:44 PM2008-02-21 4:25:44 PM
1Connect
A
Placement
Proper speakers system placement is important to
ensure optimum sound performance.
FRONT
RIGHT
FRONT
LEFT
CENTER
REAR
RIGHT
REAR
LEFT
SUBWOOFER
APlace the centre speaker above or close to the TV.
BPlace the subwoofer on the floor, at least one metre
away from the TV.
CPlace the front speakers at equal distances from the
TV.
DPlace the rear speakers at the back or beside the
listening position.
B
Connect the main unit to TV
VIDEOIN
(CVBS)
VIDEO IN
(CVBS)
Y
zUse the supplied composite video cable to connect
the CVBS socket on the main unit to the VIDEO IN
socket on your TV.
Note It is important to connect the main unit
directly to your TV.
2Set up
C
Connect the speakers and subwoofer
Connect the various coloured plugs from the speakers
and subwoofer to the same coloured sockets at the rear
of the main unit.
A
Finding the viewing channel
APress STANDBY-ON on the main unit to turn it
on.
BTurn on the TV. Use the TVs remote control to
select the correct viewing channel.
Note To search for the correct viewing channel,
press the Channel Down button on the TVs remote
control repeatedly (or AV, SELECT, °button) until
you see the Video In channel.
B
Select the display language on the
screen
APress OPTIONS.
The { General Setup } appears.
BPress
.
Press OPTIONS to exit menu
General Setup
Disc Lock
Display Dim
OSD Language
Screen Saver
DivX(R) VOD Code
Sleep
English
Malayu
CUse keys to select { OSD Language } and press
.
DUse keys to select a language option in the
menu and press OK to confirm.
EPress OPTIONS to exit.
Note The language set here is only for the menus
that are shown on the TV while operating this Home
Theatre system, not for the DVD disc menu.
There are various setup options (Audio Setup, Video
Setup, Preferences) available on this Home Theatre
System. Refer to the user manual for more information.
D
Connect the radio antenna and
power cable
Keep the antennas away from the electronic devices to
prevent unwanted interference.
B
A
AConnect the FM antenna (supplied) to the inner pin
of the FM 75 socket. (For some models, it has
been connected in the factory.) Extend the wire for
optimum reception.
Bthe power cable from the main unit to the AC
power outlet.
E
Connect audio output from TV
(optional)
To hear the TV audio through this unit, use a red and
white audio cables (not supplied) to connect the
AUDIO IN-AUX sockets on the main unit to the
AUDIO OUT sockets on your TV.
AUDIO
OUT
AUDIOIN
AUDIO
OUT
AUDIOOUT
Note When watching the TV programs, you can
press AUX repeatedly on the remote control until
‘AUX1’ or ‘AUX2’ is displayed to get the sound output
from the speakers.
Television (rear)
Main Unit (rear)
Main Unit (rear)
FM antenna
SUBWOOFER
FRONT
RIGHT
FRONT
LEFT REAR
RIGHT
REAR
LEFT
FRONT CENTER
Main Unit (rear)
Main Unit (Front)
TV (rear)
Main Unit (rear)
hts3011_98_qsg_eng_final808.indd2 2hts3011_98_qsg_eng_final808.indd2 2 2008-02-21 4:25:48 PM2008-02-21 4:25:48 PM
