Philips HR7772/00 Manual de usuario

ServiceManual

Philips Consumer Lifestyle

Published by Philips Consumer Lifestyle Printed in the Netherlands © Copyright reserved Subject to modification

Foodprocessor

HR7772/00

09/03

PRODUCT INFORMATION

Features

- Extra Large feeding tube The XL feeding tube takes whole fruits and vegetables so you don’t need to pre-cut them

anymore.

- Large 3.4L bowl The large 3.4 L bowl allows for maximum volumes to be processed in 1 go: capacity for 2 L

soup, 1.7 kg dough, 7 egg whites.

- 31 functions 7 tools for 31 different functions. They are: a SS blade for chopping, crumbling, cutting,

mashing, mincing; a reversible slicing disk; a shredding disk for medium or ﬁne shredding

or grating; whisk accessory for whipping, whisking, emulsifying, stirring, mixing, creaming,

beating; a kneading tool for heavy mixing, kneading, folding in; a blender for blending,

crushing, foaming, grinding, (heavy) pureeing, homogenizing, liquidizing, milling, shaking,

stirring, measuring; a citrus press for pressing citrus fruits.

- 700 W motor + 3 speed With the powerful 700 W motor plus 3 speed button you can adjust speed precisely to get

desired results.

- Sturdy base The sturdy base comes with suction feet to ensure it does not move, even when you use it for

heavy applications like kneading dough.

Accessories

- Chopping knife Chopping, beating, creaming, crumbling, cutting, folding in, mashing, mincing

- Kneading tool For kneading, heavy kneading, mixing dough, batter

- Whisk Accessory Whisking, whipping, mixing and emulsifying

- Reversible shredding disk For medium and ﬁne shredding

- Reversible slicing disk For medium and ﬁne slicing

- Break resistant blender For blending, crushing, foaming, grinding, pureeing, homogenizing, liquidizing, milling,

shaking, stirring

- Citrus press For pressing of citrus fruits

HR7772/00

2-6

Safety

- Automatic resettable thermal cut off Protecting the motor against overheating.

- Built-in safety lock Detects whether lid & bowl are assembled.

- Brake system Stops the accessories within 1,5 seconds.

SPECIFICATIONS

General speciﬁcations Integrated cord storage, Non-slip feet

Technical Speciﬁcations

- Cord length 1,20 m

- Voltage 220 - 240 V

- Frequency 50 - 60 Hz

- Bowl volume capacity dry 3,4 l

- Bowl working capacity liquid 2 l

- Bowl working capacity dough 1700 g

- Bowl working capacity ﬂour 1000 g

- Blender working capacity 1,5 l

- Safety Lid & bowl detection, mechanical 1,5 sec brake

- Speeds 3 speed

- Function buttons Pulse, rotary

Design speciﬁcations

- Housing, bottom, speed knob, pusher ABS

- Toolholder PA + 30 %

- Disks, chopping blade Stainless steel

- Kneading tool, citrus press PP

- Colours Bright white, citrus yellow, paprika red, capoeira grey

- Bowl + lid, blender, inner pusher SAN

- Knife protection PET

Product size:

Length : 230 mm

Width : 230 mm

Height : 170/400 mm (with food pusher)

DISASSEMBLY- AND RE-ASSEMBLY ADVISE

- No specific issues.

REPAIR INSTRUCTION

- No specific issues.

TECHNICAL INFORMATION

HR7772/00

3-6

PARTS LIST

Pos Service code Description

4203 035 87710

4203 035 87720

4203 035 87730

4203 035 88050

4203 035 88010

4203 035 87760

4203 035 87770

4203 035 88060

4203 035 88070

4203 035 87800

4203 035 88080

4203 035 88090

4203 035 87830

4203 035 87840

4203 035 87850

4203 035 82650

4203 035 87860

4203 035 87870

4203 035 87880

4203 035 87890

4203 035 87900

4203 035 87910

4203 035 88020

4203 035 88030

4203 035 87940

4203 035 87950

4203 035 87970

4203 035 87980

4203 035 87990

4203 035 88000

Housing

Bottom + airtunnel

Sucker Foot (1 pcs)

Motor - incl. wires + gearing

3 speed Switch knob assembly

PCBA HR7772

Holder safety switch I

Safety switch HR7772

Cordset WEu

Cordset Storage Box

Holder safety switch II

Safety switch lever

Measuring cap

Jar Lid

Jar

Sealing ring

Knife unit Jar

Inner pusher

Pusher

Bowl Lid

Toolholder

Bowl

Julienne disc

Shredding disc

Kneading tool

Chopping knife + protection

Press cone

CP Sieve

Gear Unit - Whisk Accessory

Whisk basket

HR7772/00

4-6

EXPLODED VIEW

5 12

HR7772/00

5-6

EXPLODED VIEW

HR7772/00

6-6

EXPLODED VIEW
