Philips BVP510 Guía del usuario

443000016381_A

07/2015

Data subject to change

Printed in Spain

www.philips.com/lighting

Optivision LED Floodlight BVP510

Mounting instruction

Instructions de montage

Instrucciones de montaje

Kokoonpano- ja kiinnitysohjeet

Szerelési utasítások

Montageanleitung

Instrucões de montagem

Montaj yönergesi

Návod k montáži

Montage instruktie

Monteringsinstruktioner

Oδηγίες συναρμολόγησης

Монтажная инструкция

Istruzioni di montaggio

Monteringsvejledning

Instrukcja montazu

LUMEN

BVP510

40000h

81K/740

81000

1014

15ºC

-30ºC

●

BVP510

40000h

79K/740

79000

954

25ºC

BVP510

40000h

71K/740

71000

836

35ºC

BVP510

40000h

58K/740

58000

607

BVP510

40000h

62K/740

62000

683

45ºC

BVP510

40000h

41K/740

41000

374

35ºC

BVP510

40000h

93K/757

93000

1012

15ºC

BVP510

40000h

90K/757

90000

954

25ºC

BVP510

40000h

82K/757

82000

841

35ºC

BVP510

40000h

67K/757

67000

607

BVP510

40000h

72K/757

72000

688

45ºC

BVP510

40000h

47K/757

47000

374

35ºC

BVP510

20000h

81K/740

81000

1014

25ºC

BVP510

20000h

79K/740

79000

954

35ºC

BVP510

20000h

69K/740

69000

798

45ºC

BVP510

20000h

57K/740

57000

601

35ºC

BVP510

20000h

52K/740

52000

529

45ºC

BVP510

20000h

93K/757

93000

1012

25ºC

BVP510

20000h

90K/757

90000

954

35ºC

BVP510

20000h

80K/757

80000

803

45ºC

BVP510

20000h

65K/757

65000

601

35ºC

BVP510

20000h

59K/757

59000

529

45ºC

BVP510

10000h

65K/740

65000

721

35ºC

BVP510

10000h

63K/740

63000

676

45ºC

BVP510

10000h

75K/757

75000

726

35ºC

BVP510

10000h

72K/757

72000

681

45ºC

Max. 23,3 Kg 1,25 m RG2 0,18/15º 0,24/40º 0,22/65º

LIFE

L80B10

Risk Group 2: - CAUTION Retinal Blue Light: Do not look into operating lamp, may be harmful to the eyes

443000016381_A

07/2015

Data subject to change

Printed in Spain

www.philips.com/lighting

DIMENSION: 785x615x446 mm

WEIGHT : 23,3 Kg

TOP

BOTTOM

TOP

BOTTOM

443000016381_A

07/2015

Data subject to change

Printed in Spain

www.philips.com/lighting

- M16 with extra large washer (not provided)

- M12 with extra large washer (not provided)

±40 mm

(x2)

50 Nm

(x1)

50 Nm

Higher >3m

Use 2nd fixing security

(x2)

50 Nm

17 Nm

443000016381_A

07/2015

Data subject to change

Printed in Spain

www.philips.com/lighting

MAINTENANCE

x2 17 Nm

LIGHT-MODULE LABEL

12 NC: 91XXXXXXXXXX

I: 0,8-2,0 A

Tc: 90ºC

Mark the

position

before

untightening

Rotate back to

the marked

position before

tightening

OPTIC TYPE

S2 TO S8

OPTIC TYPE

NB/MB/WB/VWB

Disconnect

from connection

box

2,5 Nm

Connect the

cable module to

connection box

443000016381_A

07/2015

Data subject to change

Printed in Spain

www.philips.com/lighting

ACCESSORIES

External spill-light control louvre ZVP420 L or zero candela louvre ZVP520 L-A90

Precision aiming device ZVP520 PAD A30 or ZVP420 PAD A0

50 Nm

x8 srews: 4x10 mm

2,5 Nm

ZVP420 PAD A0

ZVP520 PAD A30

12NC: 912300022588 (ZVP420 L)

12NC: 912300022867 (ZVP520 L-A90)

443000016381_A

07/2015

Data subject to change

Printed in Spain

www.philips.com/lighting

CONNECETION BOX

x2 screws: 5x10 mm

3,2 Nm

CAN CHOOSE

BOTH SIDES OF

THE BRACKET

Cable tie to fix

the cables

Only use when the connection box

is not mounted on the luminaire

cable tie to fix

the cables

x1 screws: 5x10 mm

3,2 Nm

THE USE OF THE CONNECTION BOX IS MANDATORY FOR THE CORRECT

FUNCTIONING OF THE LUMINAIRE

3,2 Nm

x4 screws: 4x10 mm

2,5 Nm

Cable tie to fix

the cables

Ensure the tightening of the

cableglands for protection against

ingress of dust and moisture (IP66)

2,5 Nm

443000016381_A

07/2015

Data subject to change

Printed in Spain

www.philips.com/lighting

WIRING BETWEEN IP20 DRIVER BOX & CONNECTION BOX (MANDATORY)

Distance to

driver

Shielded

Yes

<=30m

<=100m

<200m

CABLES INSTALLER

443000016381_A

07/2015

Data subject to change

Printed in Spain

www.philips.com/lighting

WIRING BETWEEN IP66 DRIVER BOX & CONNECTION BOX (MANDATORY)

Ensure the tightening of the

cableglands for protection against

ingress of dust and moisture (IP66)

M121,6 Nm

M202,5 Nm

M255,0 Nm
