Philips FlatTV 15PF4121 Manual de usuario

Turn up your viewing experience

with Crystal Clear

Here is an LCD TV that not only enhances the décor of your home with its European

styling and slim design, but also provides a great audio-visual experience with Crystal

Clear and Virtual Dolby Surround.

Better quality images that reveal more detail

• High-definition LCD XGA display, 1024 x 768p

• Crystal Clear improves picture depth

Superb sound reproduction

• Virtual Dolby Surround for a cinema-like audio experience

Stylish design

• Compact design

Designed for your convenience

• PC input lets you also use your TV as a PC monitor

• Smart Picture and Smart Sound to personalize your viewing

For advanced performance

• DVI-I provides the best picture and flexible connectivity

Philips

widescreen flat TV with

Digital Crystal Clear

15"

LCD

15PF4121

15PF4121/05

Widescreen flat TV with Digital Crystal Clear

15" LCD

Specifications

Picture/Display

•Aspect ratio: 4:3

•Brightness: 450 cd/m²

•Contrast ratio (typical): 500:1

•Response time (typical): 16 ms

•Viewing Angle (H / V): 130 / 100 degree

•Diagonal screen size: 15 inch / 38 cm

•Display screen type: LCD XGA Active Matrix TFT

•Panel resolution: 1024 x 768p

•Picture enhancement: Crystal Clear, Contrast

Plus, 2D Combfilter, Colour Temperature

Adjustment, Progressive Scan, Sharpness

Adjustment

•Screen enhancement: Anti-Reflection coated

screen

Supported Display Resolution

Sound

•Equaliser: 5-bands

•Output power (RMS): 2 x 2W

•Sound Enhancement: Dynamic

•Sound System: Mono, Nicam Stereo, Virtual

Dolby Surround

Convenience

•Clock: Sleep Timer

•Ease of Installation: Auto Program Naming,

Automatic Channel Install(ACI), Automatic

Tu ning Sys tem (ATS), Autostore, Fine Tun ing, PLL

Digital Tuning, Program Name, Sorting

•Ease of Use: Auto Volume Leveller (AVL), Menu,

On Screen Display, Program List, Smart Picture

Control, Smart Sound Control

•Remote Control: TV

•Remote control type: RCFE05ZAU00

•Screen Format Adjustments: 16:9 compress, 4:3,

4:3 expand

•Teletext: 10 page Smart Text

•Teletext enhancements: 4 favourite pages,

Program information Line

Tuner/Reception/Transmission

•Aerial Input: 75 ohm coaxial (IEC75)

•TV system: PAL I, PAL B/G, PAL D/K, SECAM B/

G, SECAM D/K, SECAM L/L', PAL, SECAM

•Video Playback: NTSC, SECAM, PAL

•Tuner bands: Hyperband, S-Channel, UHF, VHF

•Number of Preset Channels: 100

•Tuner Display: PLL

Connectivity

•Ext 1 Scart: Audio L/R, CVBS in/out, RGB

•Number of Scarts: 1

•Front / Side connections: Audio in, CVBS in,

Headphone out, S-video in

•Other connections: DVI-I, PC Audio in, Antenna

IEC75

Power

•Ambient temperature: 5 °C to 40 °C

•Power consumption: 42 W

•Power supply: AC 90-240

•Standby power consumption: 1.5 W

Dimensions

•Colour cabinet: Silver / Black

•Set dimensions (W x H x D):

472 x 308 x 76.5 mm

•Dimensions (with base) (W x H x D):

472 x 348 x 153 mm

•Product weight: 5.12 kg

•Box dimensions (W x H x D):

548 x 390 x 191 mm

•Weight incl. Packaging: 6.9 kg

•Set weight: 5.12 kg

Accessories

•Included Accessories: Table top stand, Power

cord, Quick start guide, User Manual, Registration

card, Remote Control

•

•Computer formats

Resolution Refresh rate

640 x 480 60, 67, 72, 75Hz

720 x 400 70Hz

800 x 600 56, 60, 72, 75Hz

832 x 624 75Hz

1024 x 768 60, 70, 75Hz

•Video Formats

Resolution Refresh rate

640

720

1280 x 720p 3Fh

1920 x 1080i 2Fh

15PF4121/05

Widescreen flat TV with Digital Crystal Clear

15" LCD

Product highlights

Issue date 2007-11-22

Version: 4.0

12 NC: 8670 000 24086

EAN: 87 10895 96513 2

Specifications are subject to change without notice.

Trademarks are the property of Koninklijke Philips

Electronics N.V. or their respective owners.

www.philips.com

LCD XGA display, 1024 x 768p

This XGA display with state-of-the-art LCD screen

technology has a widescreen HD resolution of 1024 x

768p pixels. It produces brilliant flicker-free progressive

scan pictures with optimum brightness and superb

colours. This vibrant and sharp image will provide you

with an enhanced viewing experience.

Crystal Clear

Combining picture enhancements like Contrast plus and

colour improvement, Crystal Clear improves picture

depth.

Virtual Dolby Surround

Virtual Dolby Surround is a processing technology for

enhancing surround sound effects. It will create the

sensation of Dolby Pro Logic without the necessity of

additional rear speakers. You become totally immersed in

your television experience.

PC input

With PC input you can connect your TV to a computer

and use the TV as a PC monitor.

Smart Picture and Smart Sound

Philips preset modes for Smart Picture and Smart Sound

provide you with direct access via a single key on the

remote control. You can select optimized picture and

sound settings for the various picture and sound modes.

DVI-I Input

A DVI-I input connects the non-compressed high-

bandwidth digital RGB signal from source to screen. By

eliminating the conversion of the digital signals to

analogue, it delivers an unblemished and noise free

image, that is clear and flicker free. The DVI input

supports HDCP copy protection that allows viewing of

copy protected programs from Digital Set top boxes,

DVD players and HD recorders. DVI-I is future proof as

it can be connected to all HDMI devices (a converter

cable is required). The DVI-I input also supports analogue

PC-VGA signals.
