Philips 42PFL5578/V7 Manual de usuario

www.philips.com/welcome

EN User manual

32PFL5578/V7

42PFL5578/V7

Cover 2 Blank

EN 1

Contents

1 Notice 2

2 Important 3

Use your TV 5

4 Use more of yourTV 10

Play photos, music and videos

7 Product information 26

6 Troubleshooting

on USB storage devices

Product Disposable Guidelines 4

8 Consumer Guideline 29

9 Warranty 30

2 EN

1 Notice

Pixel characteristics

This LCD/LED product has a high number of

color pixels. Although it has effective pixels of

99.999% or more, black dots or bright points of

light (red, green or blue) may appear constantly

on the screen.This is a structural property of

the display (within common industry standards)

and is not a malfunction. Any operation expressly prohibited

in this manual, or any adjustments and

assembly procedures not recommended

or authorised in this manual shall void the

warranty.

Warranty

No components are user serviceable. Do not

open or remove covers to the inside of the

product. Repairs may only be done by Philips

Service Centres and official repair shops.

Failure to do shall void any warranty, stated

or implied.

Disclaimer:

DTH service partner: Videocon d2h

Note

EN 3

Risk of injury or damage to the TV!

• Two people are required to lift and carry

a TV that weighs more than 25 kg or 55

lbs.

• When stand mounting the TV, use only

the supplied stand. Secure the stand to

the TV tightly. Place the TV on a flat, level

surface that can support the combined

weight of the TV and the stand.

• When wall mounting the TV, use only a

wall mount that can support the weight of

the TV. Secure the wall mount to a wall

that can support the combined weight of

the TV and wall mount.PE Electronics

Ltd. bears no responsibility

for improper wall mounting that result in

accident, injury or damage.

Risk of injury to children!

Follow these precautions to prevent the

TV from toppling over and causing injury to

children:

• Never place the TV on a surface covered

by a cloth or other material that can be

pulled away.

• Ensure that no part of the TV hangs over

the edge of the surface.

• Never place the TV on tall furniture (such

as a bookcase) without anchoring both

the furniture and TV to the wall or a

suitable support.

• Educate children about the dangers of

climbing on furniture to reach the TV.

Risk of swallowing batteries!

• The product/remote control may

contain a coin-type battery, which can be

swallowed. Keep the battery out of reach

of children at all times!

Risk of overheating!

• Never install the TV in a confined space.

Always leave a space of at least 4 inches

or 10 cm around the TV for ventilation.

Ensure curtains or other objects never

cover the ventilation slots on the TV.

2 Important

Read and understand all instructions before you

use yourTV. If damage is caused by failure to

follow instructions, the warranty does not apply.

Safety

Risk of electric shock or fire!

• Never expose the TV to rain or water.

Never place liquid containers, such as

vases, near the TV. If liquids are spilt on

or into the TV, disconnect the TV from

the power outlet immediately. Contact

Philips Consumer Care to have the TV

checked before use.

• Never place the TV, remote control or

batteries near naked flames or other

heat sources, including direct sunlight. To

prevent the spread of fire, keep candles

or other flames away from the TV, remote

control and batteries at all times.

• Never insert objects into the ventilation

slots or other openings on the TV.

• When the TV is swivelled ensure that

no strain is exerted on the power cord.

Strain on the power cord can loosen

connections and cause arcing.

Risk of short circuit or fire!

• Never expose the remote control or

batteries to rain, water or excessive heat.

• Avoid force coming onto power plugs.

Loose power plugs can cause arcing or

fire.

4 EN

alcohol, chemicals or household cleaners

on the TV.

• Risk of damage to the TV screen! Never

touch, push, rub or strike the screen with

any object.

• To avoid deformations and colour fading,

wipe off water drops as soon as possible.

Risk of damage to the TV!

• Before you connect the TV to the power

outlet, ensure that the power voltage

matches the value printed on the back

of the TV. Never connect the TV to the

power outlet if the voltage is different.

Risk of injury, fire or power cord damage!

• Never place the TV or any objects on the

power cord.

• To easily disconnect the TV power cord

from the power outlet, ensure that you

have full access to the power cord at all

times.

• When you disconnect the power cord,

always pull the plug, never the cable.

• Disconnect the TV from the power

outlet and antenna before lightning

storms. During lightning storms, never

touch any part of the TV, power cord or

antenna cable.

Risk of hearing damage!

• Avoid using earphones or headphones at

high volumes or for prolonged periods of

time.

Low temperatures

• If the TV is transported in temperatures

below 5°C or 41°F, unpack the TV and

wait until the TV temperature matches

room temperature before connecting the

TV to the power outlet.

Screen care

• Avoid stationary images as much as

possible. Stationary images are images

that remain on-screen for extended

periods of time. Examples include:

on-screen menus, black bars and time

displays. If you must use stationary

images, reduce screen contrast and

brightness to avoid screen damage.

• Unplug the TV before cleaning.

• Clean the TV and frame with a soft,

damp cloth. Never use substances such as

Note

Pictures and drawings shown in this user

guide book are just for representation.

Actual Product may look different than

representation.

Subscription of DTH service is subject to

separate contract with the service provider.

On purchase of the product, Subscription of

DTH service is not mandatory.

RoH

COMPLIANT

Product disposal Guidelines:

Visit-http://www.philips.com

For the purpose of recycling to facilitate effective utilization of resources, please

return this product to a nearby authorized collection center, registered dismantler,

recycler, service center when disposing of this product.

In case of further assistance, you may contact nearest authorized service center.

Or Please see the Company website for further information on sustainability etc.

Visit-http://www.philips.com

Toll :1860 200 0129,MTNL User:33550129

( )

Toll :1860 200 0129, MTNL User:33550129

EN 5

3 Use your TV

Congratulations on your purchase, and welcome to Philips. To fully benefit from the

support that Philips offers, register your TV at www.philips.com/welcome.

3.1 Name and Function of Control on Set

Note :

Above sketch and connectivity are just for representation actual product may look

different.

10) IF IN

12) VGA AUDIO IN

19) YPbPr

20) AV2 IN

21) AV1 IN

9) AC POWER IN

11) RF IN

13) VGA IN

14) HDMI 1

15) HDMI 2

16) USB

17) SMART CARD SLOT

18) AV OUT

1) LED INDICATOR

2) IR SENSOR

3) VOL+

4) VOL-

5) CH+

8) STANDBY/

POWER

6) CH-

7) MENU

B) Connectivity

A) TV Controls and Indicators

( )42PFL5578/V7

VGA IN

IF IN

AV 1 IN

VGA

AUDIO IN

RF IN

YPbPr

AV 2 IN

USB

HDMI 2HDMI 1

17 18

AV OUT

6 EN

32PFL5578/V7

3.3 Name and Function of Control on Remote

EN 7

A V

CTI E

SOURCE

MO ISA C

AVORIT

LANGUAGE

INFO

d2h

EXIT ATV MENU

OPT ONS

BACK d2h

SWAP

ADJUST

8 EN

3.4 Remote control usage

When you use the remote control, hold it close

to the TV and point it at the remote control

sensor. Make sure that the line-of-sight between

the remote control and TV is not blocked by

furniture, walls or other objects.

8 +/-

• Adjust volume.

9 0-9

Numeric buttons

• Select channels.

ACTIVE

• View the Active Services in DTH.

OPTIONS

• Access options for the current

activity or selection.

14 OK

• Confirm an entry or selection.

15 (Navigation buttons)

• Navigate through menus and select

items.

d2h Menu

• Access the DTH menu.

SWAP

• Swap between two channels.

In USB, it functions as Play/Pause.

In USB, it functions as Fast Forward

In USB, it functions as Fast Reverse.

menu pages, tracks, albums or

folders.

In USB, navigate through

16 ATV Menu (Analog TV Menu)

• Access the ATV menu.

17 Color buttons (Only in DTH source)

• Select tasks or options.

• Access DTH source directly from

d2h

any other source.

19 INFO

• View Info about DTH channels

20 LANGUAGE

• Toggle DTH language between

English and Hindi.

• Mute or restore audio. 21 MOSAIC(View channels in PIP)

• Access Mosaic menu of DTH

22 SOURCE

• Select connected devices.

ACTIVE

SOURCE MOSAIC

FAVORITE

LANGUAGE INFO

d2h

EXIT ATVMENU

OPTIONS

BACK d2h

SWAP

ADJUST

• Access the favorite channels

in DTH menu.

2FAVORITE

• Exit from any ATV or DTH

menu in one click.

X EXIT

ADJUST

• Access the menu to adjust settings.

CH+/ CH-

• Switch channels.

• Return to the previous menu.

1(Standby-On)

• Switch the TV ON or OFF.

and current source.

The TV is not powered off completely

unless it is physically unplugged.

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Televisor de pantalla plana de Philips

Philips

Philips 29PT8618 Manual de usuario

Philips

Philips matchline 32PW9723 Manual de usuario

Philips

Philips 26HFL5561L/27 Manual de usuario

Philips

Philips 42PF5320 Manual de usuario

Philips

Philips 32PFL7582D - annexe 1 Manual de usuario

Philips

Philips 17-LCD HDTV MONITOR FLAT TV CRYSTAL CLEAR III... Manual de usuario

Philips

Philips 32PF7320A Manual de usuario

Philips

Philips Cineos 42PF9731D Manual de usuario

Philips

Philips Cineos 50PF9631D Manual de usuario

Philips

Philips 47PFL7422D Manual de usuario

Philips

Philips 32PF5411 Manual de usuario

Philips

Philips Epic 50PF9966 Manual de usuario

Philips

Philips 42PFL9703 Manual de usuario

Philips

Philips Matchline 50FD9935/01S Manual de usuario

Philips

Philips Cineos 42PFL9532 Manual de usuario

Philips

Philips Cineos 42PF9830 Manual de usuario

Philips

Philips Flat TV Manual de usuario

Philips

Philips 42PFL7432D/37 Manual de usuario

Philips

Philips 37PF1600T/96 Manual de usuario

Philips

Philips 50FW9220 Manual de usuario

Philips

Philips 52PFL7932D/78M Manual de usuario

Philips

Philips 52PFL8803D Manual de usuario

Philips

Philips 19PFL5403/60 Manual de usuario

Philips

Philips 29PT5509 Manual de usuario

Manuales populares de Televisor de pantalla plana de otras marcas

Samsung

Samsung LT-P326W Manual de instrucciones

Sony

Sony WEGA KE-50XBR900, KE-42XBR900 Manual de usuario

JVC

JVC LT-26DX7BFN Manual de usuario

Samsung

Samsung CT2Z45 Manual de usuario

Samsung

Samsung LNR1550X Manual de usuario

Westinghouse

Westinghouse TX-42F970Z Manual de usuario

Toshiba

Toshiba 32BV500B Manual de usuario

Samsung

Samsung Smart TV UN55D6000 Guía

RCA

RCA MR53R400 Manual de usuario

JVC

JVC GGT0362-001A-H Manual de usuario

Sanyo

Sanyo FVM4212 Manual de usuario

JVC

JVC LT-32Z48 Manual de usuario

Sony

Sony KE-42XBR900 - 42" Xbr Plasma Wega™ Integrated... Instrucciones de uso

Vizio

Vizio M190MV Manual de uso y cuidado

Samsung

Samsung UN55F7050AF Manual de usuario

RCA

RCA TruFlat F20TF30 Manual de usuario

Samsung

Samsung LW32A33W Guía de inicio rápido

Sony

Sony FD Trinitron Wega KV-30HS420 Manual de usuario
