EN User manual

24PFL5505/V7

32PFL4305/V7

24PFL4505/V7

42PFL3505/V7

32PFL3305/V7

support

Contents

1 Notice 2

2 Important 3

Side controls and indicators

4 Use your TV 8

5 Use more of yourTV

Attention:

Frequently Asked Question

3 Your TV

Switching on

Switching off

Menu Introduction

Automatic Channel Set-up

Smart Channel Set-up

Manual Channel Set-up

Fine Tuning a Channel

Channel Edit

Adjusting the Picture

6 FAQ

Adjusting the Sound

Function Settings

Selecting a Signal Source

Geometry Settings

USB Functions

7 Other Information 15

Troubleshooting 15

EN 1

8 16

Product information

Supported display resolutions

Multimedia

Tuner/Reception/Transmission

Remote control

Power

Supported TV mounts

Product specification

Sockets 5

Remote Control Functions

1 Notice

Pixel characteristics

This LCD/LED product has a high number of

colour pixels.Although it has effective pixels of

99.999% or more, black dots or bright points of

light (red, green or blue) may appear constantly

on the screen.This is a structural property of

the display (within common industry standards)

and is not a malfunction.

Warranty

No components are user serviceable. Do not

open or remove covers to the inside of the

product. Repairs may only be done by Philips

Service Centres and official repair shops.Failure

to do so shall void any warranty, stated or

implied.

Any operation expressly prohibited in

this manual, any adjustments,or assembly

procedures not recommended or authorised in

this manual, shall void the warranty.

2 EN

When stand mounting the TV, use only

the supplied stand. Secure the stand to

the TV tightly. Place the TV on a , level

surface that can support the combined

weight of the TV and the stand.

When wall mounting the TV, use only a

wall mount that can support the weight of

the TV. Secure the wall mount to a wall

that can support the combined weight of

the TV and wall mount.

PE Electronics bears

that result in accident, injury or damage .

Risk of injury to children!

Follow these precautions to prevent the

TV from toppling over and causing injury to

children:

Never place the TV on a surface covered

by a cloth or other material that can be

pulled away.

Ensure that no part of the TV hangs over

the edge of the surface.

Never place the TV on tall furniture (such

as a bookcase) without anchoring both

the furniture and TV to the wall or a

suitable support.

Educate children about the dangers of

climbing on furniture to reach the T V.

Risk of overheating!

Never install the TV in a space.

Always leave a space of at least 4 inches

or 10 cm around the TV for ventilation.

Ensure curtains or other objec ts never

cover the ventilation slots on the TV.

Risk of damage to the TV!

Before you connect the TV to the power

outlet, ensure that the power voltage

matches the value printed on the back

of the TV. Never connect the TV to the

power outlet if the voltage is different.

Risk of injury, or power cord damage!

Never place the TV or any objects on the

power cord.

To disconnect the TV power cord easily

from the power outlet, ensure that you

have full access to the power cord at all

times.

2 Important

Read and understand all instructions before you

use yourTV. If damage is caused by failure to

follow instructions, the warranty does not apply.

Safety

Risk of electric shock or fire !

Never expose the TV to rain or water.

Never place liquid containers, such as

vases, near the TV. If liquids are spilt on

or into the TV, disconnect the TV from

the power outlet immediately. Contact

Philips Consumer Care to have the TV

checked before use.

Never place the TV, remote control or.

batteries near naked flames or other heat

sources, including direct sunlight.

To prevent th e spread of fire,keep

candles or other flames away from the

TV, remote control and batteries at all

times.

Never insert objec ts into the ventilation

slots or other openings on the TV.

When the TV is swiveled ensure that

no strain is exerted on the power cord.

Strain on the power cord can loosen

connections and cause arcing.

Never expose the remote control or

batteries to rain, water or excessive heat.

Avoid force coming on to power plugs.

Loose power plugs can cause arcing or

Risk of injury or damage to the TV!

Two people are required to lift and carry

a TV that weights more than 25 kg.

EN 3

fire.

flat

confined

fire

Risk of electric shock or fire !

no responsibility for improper wall mounting

Disposal of your old product and

batteries

Your product is designed and manufactured

with high quality materials and components,

which can be recycled and reused.

When you disconnect the power cord,

always pull the plug, never the cable.

Disconnect the TV from the power

outlet and antenna before lightning

storms. Dur ing lightning storms, never

touch any par t of the TV, power cord or

antenna cable.

Risk of hearing damage!

Avoid using earphones or headphones at

high volumes or for prolonged periods of

time.

Low temperatures

If the TV is transpor ted in temperatures

below 5

until the TV temperature matches room

temperature before connecting the TV to

the power outlet.

Screen care

Avoid stationary images as much as

possible. Stationary images ar e images

that remain on-screen for extended

periods of time. Examples include:

on-screen menus, black bars and time

displays. If you must use stationar y

images, reduce screen contrast and

brightness to avoid screen damage.

Unplug the TV before cleaning.

Clean the TV and frame with a soft,

damp cloth. Never use substances such as

alcohol, chemicals or household cleaners

on the TV.

Risk of damage to the TV screen! Never

touch, push, rub or strike the screen with

any object.

To avoid deformations and colour fading,

wipe off water drops as soon as possible.

4 EN

C, unpack the TV and wait

USB socket (input) at the side

This socket can be used to connect an USB device.

Note: The number of USB sockets on the TV may vary according to TV model.

Sockets

Note: The location and names of the sockets on the TV may vary according to

TV model, and not all sockets available on all models.

1. CHANNEL UP/DOWN button

Scans up/down through the channel list. In the menu system. They act like the up/down direction buttons on the

remote and adjust menu controls.

MENU button

Brings up the menu system.

SOURCE button

Press to select signal source.

5. POWER button (Note: The location of the power button on the TV may vary according to TV model.)

Turns the TV on or off.

Note: The positions and names of the function buttons on the TV may vary according to TV model.

. VOLUME UP/DOWN button

Increases/decreases the volume. In the menu system, they act like the right/left direction buttons on the remote

and adjust menu controls

USB

AV2 RCA audio + video sockets (input) at the side

These sockets can be used to connect a range of equipment, including video

recorders, camcorders, decoders, satellite receivers, DVD players, or games

consoles. The VIDEO IN2 socket provides composite video connection.

AUDIO

VIDEO

AV IN2

VOL

SOURCE

3 Your TV

EN 5

Side controls and indicators

VOL

SOURCE

HDMI IN1

HDMI1 and HDMI2 socket (input) at the back

The HDMI can be used to connect a

PC with a compatible video card installed, certain DVD players or a high-definition

compatible digital satellite decoder. This socket p

(High-Definition Multimedia Interface) socket

rovides an uncompressed digital

connection that carries both video and audio data by way of an integrated mini-plug

cable.

VIDEO

AV OUT

AUDIO/VIDEO sockets (output) at the back

a VCR to record programs. You must leave

the TV on the same channel you are recording.

composite video connection.

These sockets can be used to connect

The VIDEO OUT socket p

rovides

HDMI IN2

SPDIF OUT

SPDIF socket (output) at the back

Use a digital coaxial cable to connect your TV to a compatible audio receiver.

AV1 RCA audio + video sockets (input) at the back

These sockets can be used to connect a range of equipment, including video

recorders, camcorders, decoders, satellite receivers, DVD players, or games

consoles. The VIDEO IN1 socket p

rovides composite video connection.

AUDIO

VIDEO

AV IN1

AUDIO

VGA socket (input) at the back

This socket can be used to connect a computer.

VGA IN

ANTENNA IN

ANTENNA IN socket (input) at the back

This socket can be used to connect the outside aerial or cable network.

VGA/COMPONENT

AUDIO IN

AUDIO IN sockets (input) at the back

These sockets can be used to connect a range of equipment, including video

recorders, camcorders, satellite receivers, DVD players, or games consoles.

AUDIO IN sockets are shared by VGA and YPBPR sockets.

VGA/COMPONENT

YPBPR component sockets (input) at the back

These can be used to connect a device that has component video sockets, such as

a DVD player. The component sockets can recognize if the device you're connecting

to is Y Pb Pr compatible or Y Cb Cr compatible. The component sockets provide

excellent picture quality because the video is separated into three separate parts.

Pb/Cb

Pr/Cr

COMPONENT

Headphone socket (output) at the side

This socket can be used to connect headphones or stereo earphones.

Warning: Excessive sound pressure from earphones and headphones can

cause hearing loss.

Note: When connecting headphones, you can press the button on the remote

control to mute the sound coming from the speakers.

In MUTE condition, Pressing the VOL+ and VOL- could change the volume of earphone.

And you need to press the MUTE button on the remote to release the mute of speaker

6 EN

Remote Control Functions

Most of your television's functions are available via the menus that appear on the

screen. The remote control supplied with your set can be used to navigate through

the menus and to configure all the general settings.

SOURCE Press to select signal source.

(On/Off button) Turns the TV on or off.

USB

Access the USB mode.

TV Access the TV mode.

EN 7

Note: -Remote Control ( Depending on the models) and operation of remote control

may be affected by bright artifical light near to the TV.

MENU Brings up the menu system.

FORMAT

Selects a picture format.

DEMO

Toggles the demonstration menu on or off.

DUAL

Switches Stereo and Nicam Stereo to

Mono. Selects first language (Dual I)

or second language (Dual II) in bilingual programmes.

SLEEP

Sets a delay after which the TV switches off.

FREEZE Freezes the picture.

EXIT Exits the menu system.

(up, down, left and right direction buttons) Highlights different items

in the menu system and adjusts the menu controls.

OK Confirms your selection.

BACK A/CH

Returns to a previous screen.

Toggles between the current channel

and the last viewed channel.

INFO Displays the status information.

(MUTE) Reduces the TV's volume to its minimum level. Press again

CH +/- Scans up or down through the current channel list.

+/-

Increases or decreases volume.

0-9 (numeric buttons) Enters channel numbers.


SOUND

SCENEA Deletes the selected file in the playlist .

Note: -DEMO.SCENEA,DUAL

SLEEP

Toggles through the sound modes:STEREO,MUSIC,MOVIE ,NEWS,

Toggles through the picture preset settings:STANDARD,BRIGHT,

SOFT and PERSONAL.

keys depend on model.

Red,Green,Blue keys depend on model be work in USB mode.

To restore the volume.

and PERSONAL.

Note:-Mute can not be release by VOL+/- key

TV USB

FREEZE EXIT

SCENEA

Switching on

Follow the instructions on this page on how to switch on your TV set and the remote

control before going on to following pages describing how to use the channel set-up

procedure.

1. Insert two AAA batteries in the remote control.

Precautions on using batteries:

- Only use the battery types specified.

- Make sure you use the correct polarity.

- Do not mix new and used batteries.

- Do not use rechargeable batteries.

- Do not expose batteries to excessive heat such as sunshine, fire or the like,

throw them in a fire, recharge them or try to open them, as this could cause

them to leak or explode.

- Remove the batteries from the remote control if you are not using it for a long

period of time.

3. Connect the outside aerial or cable network to the ANTENNA IN socket at the

back of the TV set.

The aerial socket (75 OHM - VHF / UHF / cable) can be used for connecting

an external aerial or other equipment fitted with a modulator (video recorder,

satellite receiver, etc.). We recommend that you do not connect other equipment

(video recorder, satellite receiver, etc.) to your TV set to begin with, so as not to

complicate the set-up procedure with the additional steps involved. Connect

them when you have finished setting up the channels.

4. Switch the TV on by pressing the power button.

The location and name of the power button on the TV may vary according

to TV model.

If the TV set is in standby mode, press the button on the remote control or the

CH+/- buttons on the TV set to turn on the TV.

Note:

2. Connect the power cable to a mains socket. (If the power cable is not connected

to the television, please first connect the power cable to the television.)

Your TV set should only be connected to anAC supply. It must not be connected

to a DC supply. If the plug is detached from the cable, do not, under any

circumstances, connect it to a mains socket, as there is a risk of electric shock.

Note: The figures are for representation only. The location of the power socket at

the back of the television might differ depending on the model.

Switching off

press the power button

To put the TV set into standby mode, press the button on the remote control.

The TV set remains powered up, but with low energy consumption.

To switch off the TV set, .

8 EN

4 Use your TV

Automatic Channel Set-up

Channel set-up involves selecting all the settings required

to be able to search for and store all the channels you can

receive. Make sure that the television is switched on and

follow all the steps in turn specified hereafter.

Display the menu by pressing the MENU button. Press the

left or direction button to select the CHANNEL icon

and press the or down direction or OK button to display

the CHANNEL menu.

Press the up or down direction button to select

Channels are arranged in a pre-set order. Refer to the

following sections if you want to fine tune or skip a

channel, or swap two channels.

right

1. the

AUTO SCAN option.

2. Press the direction or OK button to start channel

search.

Note: Depending on the number of channels you

receive, it may take several minutes for the channel

search to finish. If you want to interrupt the process,

press the MENU button. The channels already found

will be stored.

right

Smart Channel Set-up

This operation will keep all the existed channels and add

newly found channels to the end of the channel list.

ress the up or down

direction button to select

Note: If you want to interrupt the process, press the

MENU button. The channels already found will be

stored.

1. Activate the CHANNEL menu and p

the SMART SCAN option.

2. Press the direction or OK button to start smart

scan.

right

Manual Channel Set-up

Follow the below procedure if you find that some channels

have not been stored after the automatic set-up as well

as the smart set-up.

right

left or right

Press MENU to return or EXIT to close the menu.

1. Activate the CHANNEL menu and p

the MANUAL SEARCH option.

2. Press the direction or OK button to enter the

MANUAL SEARCH menu.

3. Select the CH option and press the

press the

the

SEARCH option and press the

ress the up or down

direction button to select

direction

button to select a channel number to store the channel

that will be found.

4. If necessary, press the up or down direction button to

select the FRE SECT option and

direction button to toggle among VHFH, UHF and VHFL.

5. Press the up or down direction button to select

direction

button to search manually.

MANUAL SEARCH

FRE SECT

1 CH

VHFL

49.70 Mhz

MENU KEY TO RETURN EXIT KEY TO EXIT

42.25Mhz

CHANNEL

AUTO SCAN

SMART SCAN

MANUAL SEARCH

FINETUNE

CHANNEL EDIT

Fine Tuning a Channel

If the picture is not clear you can fine tune the channel.

1. Activate the CHANNEL menu and p

the FINETUNE option.

2. Press the left or right direction button to fine tuning

ress the up or

down direction button to select

3. Press MENU to return or EXIT to close the menu.

If there is no new programme found, the number keeps

unchanged, staying at 0.

PICTURE: Adjusting the Picture.

FUNCTION: Function Settings.

CHANNEL: Chanel Search and Edit .

MEDIA: USB Functions.

of CH stands for the newly searched programmes.

During the process of SMART SCAN, the number in front

Menu Introduction

SOURCE: Selecting a Signal Source

SOUND: Adjusting the Sound

EN 9

Always start tunning from channel number 1

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Televisor de pantalla plana de Philips

Philips

Philips 42PFL5432D/37E Documento técnico

Philips

Philips 15-LCD TELEVISION 15LCD35 Manual de usuario

Philips

Philips 20HF8432 Manual de usuario

Philips

Philips Cineos 50PF9631D Manual de usuario

Philips

Philips 37PF7321D Manual de usuario

Philips

Philips 42PFL7962D - annexe 3 Manual de usuario

Philips

Philips 26PF4310 Manual de usuario

Philips

Philips 29PT8608 Manual de usuario

Philips

Philips 40PFL9715K Manual de usuario

Philips

Philips 15PF7846 - annexe 1 Manual de usuario

Philips

Philips 26-REAL FLAT COMMERCIAL WIDESCREEN HDTV... Manual de usuario

Philips

Philips 36PW9765/05 Manual de usuario

Philips

Philips FTR9955/12 Manual de usuario

Philips

Philips 42 IN PLASMA FLAT TV HDTV MONITOR 42FD9954 Manual de usuario

Philips

Philips 42PFL9703 Manual de usuario

Philips

Philips MatchLine 23PF9945 Manual de usuario

Philips

Philips FLATTV 23PF5121 Manual de usuario

Philips

Philips 22PFL3415H/60 Manual de usuario

Philips

Philips 42HFL3381 Manual de usuario

Philips

Philips matchline 32PW9566 Manual de usuario

Philips

Philips Cineos 42PF9541 Manual de usuario

Philips

Philips MatchLine 42PF9996 Manual de usuario

Philips

Philips 15HF8442 Manual de usuario

Philips

Philips 32PFL7332D Manual de usuario

Manuales populares de Televisor de pantalla plana de otras marcas

Samsung

Samsung LT-P326W Manual de instrucciones

Sony

Sony WEGA KE-50XBR900, KE-42XBR900 Manual de usuario

JVC

JVC LT-26DX7BFN Manual de usuario

Samsung

Samsung CT2Z45 Manual de usuario

Samsung

Samsung LNR1550X Manual de usuario

Westinghouse

Westinghouse TX-42F970Z Manual de usuario

Toshiba

Toshiba 32BV500B Manual de usuario

Samsung

Samsung Smart TV UN55D6000 Guía

RCA

RCA MR53R400 Manual de usuario

JVC

JVC GGT0362-001A-H Manual de usuario

Sanyo

Sanyo FVM4212 Manual de usuario

JVC

JVC LT-32Z48 Manual de usuario

Sony

Sony KE-42XBR900 - 42" Xbr Plasma Wega™ Integrated... Instrucciones de uso

Vizio

Vizio M190MV Manual de uso y cuidado

Samsung

Samsung UN55F7050AF Manual de usuario

RCA

RCA TruFlat F20TF30 Manual de usuario

Samsung

Samsung LW32A33W Guía de inicio rápido

Sony

Sony FD Trinitron Wega KV-30HS420 Manual de usuario
