Philips 23PF5320 Manual de usuario

Philips

Flat TV with Crystal Clear

III

58 cm (23")

LCD HD Ready

23PF5320

Turn up your viewing experience

with Crystal Clear III

Here is a new TV that not only gives you great picture and sound but also modern styling

and quality finish. It features Crystal Clear III for better quality images that reveal more

detail and Incredible Surround for superb audio.

Vivid, natural and razor sharp images

• HD LCD WXGA display, with a 1366 x 768p resolution

• HDTV Monitor for the highest quality display of HDTV signals

• Crystal Clear III for natural images with enhanced quality

• 3D combfilter separates colors for a razor-sharp image

Exciting and lifelike sound

• Incredible Surround™ for enhanced audio enjoyment

Slim, stylish design to complement your interior

• Compact and slim design that fits in every room

Multi-purpose convenience

• PC input lets you also use your TV as a PC monitor

• Smart Picture provides personalized image settings

Leading interface for digital quality audio/video

• DVI-D provides the best digital picture

23PF5320/98

Highlights

Flat TV with Crystal Clear III

58 cm (23") LCD HD Ready

LCD WXGA display, 1366 x 768p

This WXGA display with state-of-the-art LCD

screen technology gives you widescreen HD

resolution of 1366 x 768p pixels. It produces

brilliant flicker-free progressive scan pictures

with optimum brightness and superb colors.

This vibrant and sharp image will provide you

with an enhanced viewing experience.

HDTV Monitor

HDTV is the latest and best television signal

available. It produces picture quality more than

twice that of traditional analog broadcasts. In

order to effectively maximize the HDTV signal,

a television must incorporate advanced signal

input connectivity

Crystal Clear III

Crystal Clear III combines a whole range of

enhancements to provide a better picture.

They include a 2D Comb filter, Dynamic

contrast, Blue stretch and Green enhancement

so that you always get the most natural looking

colors.

3D Combfilter

The 3D comb filter separates brightness and

color signals better in 3D domain to eliminate

cross-color, cross-luminance and dot-crawl

distortion - all of which detract from your

viewing pleasure. The 3D digital comb filter

performs field-by-field comparisons of the

television image to accurately separate the

color from the black-and-white information

and remove both horizontally and vertically

hanging dots, as well as dot crawl. The result is

a razor sharp image.

Incredible Surround™

Incredible Surround is an audio technology

from Philips that dramatically magnifies the

sound field to immerse you in the audio. Using

state-of-the-art electronic phase shifting,

Incredible Surround mixes sounds from left

and right in such a way that it expands the

virtual distance between the two speakers.

This wider spread greatly enhances the stereo

effect and creates a more natural sound

dimension. Incredible Surround allows you to

experience total surround with greater depth

and width of sound, without the use of

additional speakers.

PC input

With PC input you can connect your TV to a

computer and use the TV as a PC monitor.

Smart Picture

Smart Picture provides the optimum picture

settings for color, brightness, saturation,

contrast, sharpness, and so on, to enhance

your overall viewing experience at all times.

DVI-D input

A DVI-D input makes an uncompressed digital

RGB connection from source to screen. By

eliminating the conversion of the digital signal

to analog, it delivers an unblemished image.

Thanks to the non-degraded signal, you get less

flicker and a clearer picture. The DVI input is

fully backward compatible with HDMI sources,

and also uses HDCP copy protection.

Issue date 2012-05-20

Version: 8.0.11

12 NC: 8670 000 21678

EAN: 87 10895 87542 4

Specifications are subject to change without notice.

Trademarks are the property of Koninklijke Philips

Electronics N.V. or their respective owners.

www.philips.com

23PF5320/98

Specifications

Flat TV with Crystal Clear III

58 cm (23") LCD HD Ready

Picture/Display

• Aspect ratio: Widescreen

• Brightness: 500 cd/m²

• Contrast ratio (typical): 450:1

• Diagonal screen size: 23 inch / 58 cm

• Display screen type: LCD WXGA Active Matrix

TFT

•Picture enhancement: Crystal Clear III, Progressive

scan, Sharpness Adjustment, 3D Combfilter

• Screen enhancement: Anti-Reflection coated

screen

• Panel resolution: 1366 x 768p

• Response time (typical): 16 ms

• Viewing angle (H / V): 140 / 125 degree

Supported Display Resolution

•Computer formats

Resolution Refresh rate

1024 x 768 60Hz

1280 x 768 60Hz

640 x 480 60, 67, 72, 75Hz

800 x 600 56, 60, 72, 75Hz

•Video Formats

Resolution Refresh rate

640 x 480i 1Fh

640 x 480p 2Fh

720 x 576i 1Fh

720 x 576p 2Fh

1280 x 720p 3Fh

1920 x 1080i 2Fh

Sound

• Output power (RMS): 2 x 5W

• Sound System: Nicam Stereo, Mono

• Sound Enhancement: Incredible Surround

Convenience

• Ease of Installation: Automatic Tuning System

(ATS), Autostore, Fine Tuning

• Ease of Use: Smart Picture, Smart Sound, Top

Controls, Auto Volume Leveller (AVL), Menu

Control, On Screen Display

• Teletext: 10 page Smart Text

• Clock: Sleep Timer

• VESA Mount: 100 x 100 mm

• Child Protection: Child Lock+Parental Control

• Screen Format Adjustments: 4:3, Widescreen,

Super Zoom, Subtitle Zoom, Movie expand 14:9,

Movie expand 16:9

Tuner/Reception/Transmission

• Tuner bands: Hyperband, S-Channel, UHF, VHF

• Video Playback: NTSC, PAL, SECAM

• TV system: PAL D/K, PAL B/G, PAL I, PAL,

SECAM, SECAM B/G, SECAM D/K

Connectivity

• AV 1: YPbPr (2fh), Audio L/R in

• AV 2: Audio L/R in, Component Video in

• AV 3: CVBS in, S-Video Y/C, Audio L/R in

• Other connections: PC-In VGA, DVI-D, PC Audio

in, Composite video (CVBS) out, Analog audio

Left/Right out, Antenna IEC75

Power

• Power consumption: 85 W

• Standby power consumption: < 1 W

• Ambient temperature: 5 °C to 40 °C

• Power supply: AC 90-240

Accessories

• Included accessories: Table top stand, Power cord,

Quick start guide, Remote Control, User Manual

Dimensions

• Product weight: 10.5 kg

• Dimensions (with base) (W x H x D):

615 x 473 x 234 mm

• Set dimensions (W x H x D): 615 x 436 x 114 mm

•
