20” LCD Flat-TV

• Flat and slim design

• TFT LCD Screen - 640x480 pixels

• Integrated TV tuner

• Brightness 450cd/m2 - Contrast Ratio 400:1

• Progressive Scan

• Digital Comb filter

• Stereo Integrated Sound System 2x2WRMS

• Graphic Equalizer

• Closed Captioning

• AutoLock™(V-chip)

• 1fh YUV (YPbPr) input

• ‘Arch’ table-top stand

20PF 9925

‘Arch’ stand incl.

20” LCD Flat-TV

Liquid Crystal (Display) Television works by trapping a liq-

uid crystal solution between two sheets of polarized glass.When

an electric current is passed through the liquid crystals, they align

so light cannot pass trough. Each crystal then either blocks or

allows light to pass through it based on the broadcast informa-

tion. For clear, crisp color that rivals traditional CRT displays, a

thin film transistor, known as a TFT is employed.

LCD allows screens to be thinner, and televisions lighter and more

energy efficient than ever before.The result is television that not

only can fit on a wall, it can fit in places conventional televisions

cannot.

L75

DC 15V ANT INS-VIDEO

YLR

AUDIO VIDEO VIDEO

COMPONENT (480i/480p)

DVD/DTV IN

Pr L

RAUDIO L

MONITOR OUT

RAUDIO

Rear connectors

Y-ZD

00CC

MENU OK

SLEEPEXT

RC282605

Release date : February 2002

Predecessor(s) : –

Date of issue : Nov. 2001

A Division of Philips Electronics North

America Corp.

Printed in USA

Specifications subject to change without notice.

Technical specifications

Screen / Picture

• Visible screen size : 20.1"

• Picture Aspect Ratio 4:3

• LCD technology :Thin Film Transistor - TFT

• # pixels : 640 x 480

• Response time LCD : 25ms (typical)

• Light output : 450cd/m2

• Contrast Ratio : 400:1

• Viewing angles : 140h / 120v

• Anti glare coating

• Progressive Scan

• De-interlacer

• Color Transient Improvement

• Digital Comb filter (4H)

• Contrast / Brightness control

Sound

• Sound system : BTSC / SAP Stereo

• Output : 2x2W RMS

• Speakers : 2x2 - full range + tweeter

• Graphic Equalizer

•AVL

Operation

• EasyTune™

• Multi-language menu / OSD (Eng, Fre, Spa, Port)

• Sleeptimer up to 180 minutes.

• AutoLock™ to protect young kids from objec-

tionable programming with V-chip technology

• Closed Captioning

Reception

• Tuning system: PLL Digital Tuning

• Color transmission systems

Off-air: NTSC - M

NTSC video playback

• Channel selections : 125 channels

• Aerial input: 75 Ohm (F-threaded)

Remote Control

• RC282605

Connections

• Audio / Video

- Component video in

YUV-in / YPbPr (cinch) input + audio L-R

- Video CVBS in, audio L-R in(cinch)

- S-Video in (Y/C)

- Monitor out :Video CVBS, audio L-R (cinch)

- headphone jack 3.5mm

• DC input

- 15V / 4.5 A

• Antenna

- Input 75Ohm F-pin

Miscellaneous

• Ambient temperature : +0/+40°C

• Mains : AC 95–264V, 50/60Hz

• Power consumption: 70W (normal operation) ;

Stand by : <3W

• Weight : 21.2 lbs (incl. ‘arch’; excl. packaging)

• Dimensions (WxHxD):

product : 25.3x 16.7x 3.3 in. (excl. ‘arch’)

carton : 30.0x 22.9x 12.2 in.

UPC : 0 00000 00000 0

EasyTune and AutoLock are trademarks of Philips

Consumer Electronics Company.

Internet address

http://www.philips.com

20PF 9925
