Philips 19PFL3504D - 19" LCD TV Manual de usuario
Philips 3000 series
LCD TV with Digital
Crystal Clear
19" class
digital TV
19PFL3504D
Clearly the smart choice
Designed for ease of use, this Flat TV features modern design, 2 HDMI connections, a
powerful 720p, 60Hz display and brilliant Digital Crystal Clear engine. Making the smart
choice in total picture quality has never been easier.
See brilliant picture quality
• Digital Crystal Clear for detail depth and clarity
• HD LCD display, with a 1366 x 768p resolution
• Up to 5ms response time for clear, fast moving action
• Dynamic contrast for incredible rich black details
Hear crisp and clear sound
• 2x3W RMS audio power
Easy to connect and enjoy
• Settings assistant for effortless personalized TV settings
• PC-input allows you to use your TV as a PC monitor
• 2 HDMI inputs with Easylink for HD connection
Ready for digital
• ATSC & QAM tuner receives over the air and unscrambled cable
19PFL3504D/F7
Highlights
LCD TV with Digital Crystal Clear
19" class digital TV
Digital Crystal Clear
Digital Crystal Clear is a package of picture
innovations that digitally adjusts and optimizes
picture quality to optimal contrast, color and
sharpness levels. It's like watching vivid cinema-
like images.
LCD display, 1366 x 768p
This WXGA display with state-of-the-art LCD
screen technology gives you widescreen HD
resolution of 1366 x 768p pixels. It produces
brilliant flicker-free progressive scan pictures
with optimum brightness and superb colors.
This vibrant and sharp image will provide you
with an enhanced viewing experience.
5ms response time
Response time measures signal reaction speed in
milliseconds. Faster response time is better as it
eliminates visible image artifacts that could
dampen your experience when viewing fast
moving images or objects. In this case, this LCD
panel gives you 5ms response time so that you
can watch your LCD TV with a clear, fast
moving action.
Dynamic contrast
You want the LCD flat display with the highest
contrast and most vibrant images. Philips
advanced video processing combined with
unique extreme dimming and backlight boosting
technology results in vibrant images. Dynamic
contrast will increase the contrast with
excellent blacklevel and accurate rendition of
dark shades and colors. It gives a bright, lifelike
picture with high contrast and vibrant colors.
Settings assistant
Settings assistant for effortless personalized TV
settings. The new settings assistant
personalisation wizard guides you to
personalised settings with unparalleled ease. It
includes not only picture, but the complete
viewing experience, including sound and
Ambilight settings. The wizard shows a few
screens with easy to choose options to select
the essential settings. The TV performance is set
to the your personal preference without difficult
terms or settings, and this very quickly.
2 HDMI inputs with EasyLink
EasyLink uses the HDMI CEC industry standard
protocol to share functionality between
connected devices and the TV. With Easylink
only one remote control is needed to operate
main functionalities on your TV and connected
devices. HDMI makes an uncompressed digital
RGB connection from the source to the screen
for the ultimate picture quality. HDMI uses
HDCP copy protection. With 1 HDMI input on
the back and 1 HDMI on the side of the TV you
can connect multiple HD sources, for instance
an HD settop box, a Blu-ray player, and Game
Console or Digital Camcorder.
PC input (VGA)
With PC input you can connect your TV to a
computer by a VGA cable and use the TV as a
PC monitor.
Built-in ATSC & QAM tuner
Built-in ATSC & QAM tuner for reception of
over-the-air and unscrambled HD cable
programs
19PFL3504D/F7
Specifications
LCD TV with Digital Crystal Clear
19" class digital TV
Picture/Display
• Aspect ratio: Widescreen
• Brightness: 300 cd/m²
• Contrast ratio (typical): 1000:1
• Viewing angle: 170º (H) / 160º (V)
• Dynamic screen contrast: 4000:1
• Response time (typical): 5 ms
• Diagonal screen size: 19 inch / 48.1 cm
• Panel resolution: 1366 x 768p
• Picture enhancement: Digital Crystal Clear, 3D
Combfilter, Digital Noise Reduction, Dynamic
contrast enhancement, Progressive scan
• Visible screen diagonal (inch): 18.5 inch
Supported Display Resolution
•Computer formats
Resolution Refresh rate
640 x 480 60Hz
720 x 480 60Hz
800 x 600 60Hz
1024 x 768 60Hz
1280 x 768 60Hz
1360 x 768 60Hz
•Video formats
Resolution Refresh rate
480i 60Hz
480p 60Hz
720p 60Hz
1080i 60Hz
Sound
• Equalizer: 5-bands
• Output power (RMS): 2 x 3W
• Sound System: Dolby Digital (AC-3), Stereo, SAP
Loudspeakers
• Built-in speakers: 2
Convenience
• Child Protection: Child Lock+Parental Control
• Clock: Sleep Timer
• Ease of Installation: Autostore, PLL Digital Tuning
• Ease of Use: Auto Volume Leveller (AVL),
AutoPicture, AutoSound, Settings assistant Wizard,
Side Control
• Remote Control: TV
• Screen Format Adjustments: 4:3, Movie expand 16:9,
Widescreen
Tuner/Reception/Transmission
• Aerial Input: 75 ohm F-type
• TV system: ATSC, NTSC
• Video Playback: NTSC
• Cable: Unscrambled Digital Cable -QAM
• Tuner bands: Hyperband, S-Channel, UHF, VHF
Connectivity
• AV 1: Audio L/R in, YPbPr
• HDMI 1: HDMI v1.3, Analog audio L/R in
• Audio Output - Digital: Coaxial (cinch)
• Other connections: PC Audio in, PC-In VGA
•Front/Sideconnections:HDMI v1.3, S-video in,
CVBS in, Audio L/R in, Headphone out, USB
• EasyLink (HDMI-CEC): One touch play, Power
status, System info (menu language), System audio
control, System standby
Power
• Ambient temperature: 5 °C to 35 °C
• Mains power: 120V/60Hz
• Power consumption: 55 W
• Standby power consumption: < 0.5 W
Dimensions
• Set dimensions in inch (W x H x D):
19.0 x 13.2 x 3.1 inch
• VESA wall mount compatible: 100 x 100 mm
• Set dimensions with stand in inch (W x H x D):
19.0 x 14.7 x 7.1 inch
• Weight incl. Packaging (lb): 11.5
• Product weight (lb): 8.2
• Product weight (+stand) (lb): 9.1 lb
• Box dimensions in inch (W x H x D):
22.3 x 16.7 x 7.0 inch
Accessories
• Included accessories: Table top stand, Power cord,
Quick start guide, User Manual, Registration card,
Remote Control, Batteries for remote control
•
Issue date 2010-08-02
Version: 1.11.3
12 NC: 8670 000 48326
UPC: 6 09585 16380 5
© 2010 Koninklijke Philips Electronics N.V.
All Rights reserved.
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips
Electronics N.V. or their respective owners.
www.philips.com
