HQ6847
3
Important
◗Only use the HQ6000 Powerplug supplied to
charge the appliance.
◗The Powerplug transforms 110-240Volts to
12Volts.
C◗Make sure the HQ6000 Powerplug does not
get wet.
C◗The shaver runs at a safe low voltage of 12
Volts.It is watertight and can be cleaned
under the tap.Do not rinse with water hotter
than 80cC.
Charge indications
C◗Charging
As soon as you start charging the empty shaver,
the green pilot light will go on.
C◗Batteries fully charged
When the batteries have been fully charged,the
green pilot light will start blinking.
A fully charged shaver has a cordless shaving time
of up to 45 minutes.
C◗Batteries running low
When the batteries are running low,the lower
light becomes red.When you have switched off
the shaver,the red light will blink for 4 seconds.
ENGLISH4
Charging
Recharge and keep the appliance at a
temperature between 5cC and 35cC
The Powerplug is suitable for mains voltages
ranging from 100 to 240V.
Do not leave the shaver connected to the mains
continuously.
C1Insert the appliance plug into the shaver as
far as the line on the plug.
2Put the Powerplug in the socket.
Do not recharge the shaver in a closed pouch.
3When charging for the first time or after a
long period of disuse:leave the shaver to
charge continuously for 4 hours.
Charging normally takes approx.1 hour.
4Remove the Powerplug from the socket
and pull the appliance plug out of the
shaver when the batteries have been fully
charged.
With the special Philishave Car Cord (HQ6010),
you can also charge the appliance at 12Volts (e.g.
in a car).This cord is available from your Philishave
dealer.
Shaving
1Switch the appliance on by pressing the
on/off button once.
ENGLISH 5
C2Move the shaving heads quickly over the
skin,making both straight and circular
movements.
Shaving on a dry face gives the best results.
Your skin may need 2-3 weeks to get accustomed
to the Philishave system.
3Switch the appliance off by pressing the
on/off button once.
C4Put the protective cap on the shaver to
prevent damage.
Replace the shaving heads (type HQ6 Quadra
Action) every 2 years for optimal shaving results.
Trimmer
For grooming sideburns and moustache.
C1Open the trimmer by pushing the slide
upwards.
The trimmer can be activated while the motor is
running.
Cleaning
Regular cleaning guarantees better shaving
performance.
The easiest and most hygienic way to clean the
appliance is to rinse the shaving unit every week
with hot water (60cC-80cC).
When you clean the appliance,it is not necessary
to take the shaving heads (cutters and guards)
ENGLISH6
apart.If you want to take them apart,be sure not
to mix up the cutters and guards,since grinding of
the cutters in the guards only guarantees optimal
performance for each matching set.If you
accidentally mix up the sets,it could take several
weeks before optimal shaving is restored.
Every week:shaving unit
1Switch the appliance off,remove the
Powerplug from the socket and pull the
appliance plug out of the shaver.
C2Press the release button and open the
shaving unit.
C3Clean the shaving unit and the hair
chamber by rinsing them under a hot tap
(60cC-80cC) for some time.
C4Leave the shaving unit open to let the
appliance dry completely.
You can also clean the hair chamber without
water by using the brush supplied.
Every six months:trimmer
1Switch the appliance off,remove the
Powerplug from the socket and pull the
appliance plug out of the shaver.
C2Clean the trimmer with the brush.
ENGLISH 7
1
2
C3Lubricate the trimmer teeth with a drop
of sewing machine oil every six months.
Replacing the shaving heads
Replace the shaving heads every two years for
optimal shaving results.
1Switch the appliance off,remove the
powerplug from the socket and disconnect
the appliance plug from the shaver.
C2Press the release button to open the
shaving unit.
C3Turn the wheel anti-clockwise and remove
the retaining frame.
C4Remove the shaving heads and place the
new ones in the shaving unit in such a way
that the parts with the small holes point
towards the centre of the shaving unit.
Make sure that the projections of the shaving
heads fit exactly into the recesses.
C5Reassemble the shaving unit by pressing
the wheel and turning it clockwise.
If the shaving heads have been properly inserted,
ENGLISH8
1
2
1
2
1
2
a shiny circle is visible on top of the shaving unit.
Replace damaged or worn shaving heads with
Philishave HQ6 Quadra Action shaving heads
only.
Storing
C◗Put the protective cap on the shaver to
prevent damage.
◗Store the appliance in the luxury pouch.
Disposal of batteries
Remove the batteries when you discard the
appliance.Do not throw the batteries away with
the normal household waste,but hand them in at
an official collection point.You can also take the
batteries to a Philips Service Centre,which will
dispose of them in an environmentally safe way.
Only remove the batteries if they are completely
empty.
1Remove the Powerplug from the socket
and pull the appliance plug out of the
shaver.
C2Let the shaver run until it stops,undo the
screws and open the shaver.
3Remove the batteries.
ENGLISH 9
The shaver may not be connected to the mains
again after the batteries have been removed.
Troubleshooting
Reduced shaving performance:
BCause 1:The shaving heads are dirty.The shaver
has not been rinsed long enough or the water
used was not hot enough.
1Clean the shaver thoroughly before you
continue shaving (see 'Cleaning').
BCause 2:Long hairs are obstructing the shaving
heads.
C2Remove the retaining plate.
C3Clean the cutters and guards.
Do not clean more than one cutter and guard at
a time,since they are all matching sets.If you
accidentally mix up the cutters and guards,it
could take several weeks before optimal shaving
performance is restored.
4Remove the hairs.
5Put the retaining plate back into the
shaving unit.
BCause 3:Shaving heads are damaged or worn.
6Remove the retaining plate.
ENGLISH10
1
2
7Remove the old shaving heads from the
shaving unit and replace them with new
ones.
Damaged or worn shaving heads (cutters and
guards) must only be replaced by the original
Philishave HQ6 Quadra Action shaving heads!
8Put the retaining plate back into the
shaving unit.
Shaver does not work when the on/off button is
pressed:
BCause:The batteries are empty.
9Recharge the batteries.
Guarantee & service
If you need service or information or if you have
a problem,please consult the worldwide
guarantee leaflet or visit ourWeb site:
www.philips.com.
ENGLISH 11
Wichtig
◗Verwenden Sie zumAufladen des Geräts nur
das mitgelieferte Steckernetzgerät HQ 6000.
◗Das Steckernetzgerät wandelt 100 bis 240Volt
in eine Betriebsspannung von 12Volt um.
C◗Achten Sie darauf,dass das Steckernetzgerät
HQ 6000 nicht nass wird.
C◗Der Rasierer arbeitet mit einer ungefährlichen
Niedrigspannung von 12Volt.Er ist
wasserdicht und kann unter fließendem
Wasser gereinigt werden.Spülen Sie ihn aber
nicht mitWasser ab,das heißer als 80 cC ist.
Ladeanzeige
C◗Aufladen
Sobald Sie beginnen die Akkus aufzuladen,
leuchtet die grüne Kontroll-Lampe kontinuierlich
auf.
C◗Akkus voll aufgeladen
Sobald die Akkus aufgeladen sind,beginnt die
grüne Kontroll-Lampe zu blinken.
Mit voll aufgeladenen Akkus können Sie sich ca.
45 Minuten rasieren.
C◗Akkus zu schwach
Wenn dieAkkus zu schwach werden,beginnt die
untere Kontroll-Lampe rot zu leuchten.Wenn Sie
den Rasierer ausgeschaltet haben,blinkt die rote
Kontroll-Lampe 4 Sekunden lang.
DEUTSCH12
