Philips HQ6830/16 Manual de usuario

ENGLISH 4

DEUTSCH 12

FRANÇAIS 21

NEDERLANDS 30

ESPAÑOL 39

ITALIANO 48

PORTUGUÊS 56

TÜRKÇE 65

HQ6832,HQ6830

Important

◗Only use the HQ8000/ 6000 powerplug

supplied to charge the appliance.

◗The powerplug transforms 110-240 volts to

12 volts.

C◗Make sure the HQ8000/ 6000 powerplug

does not get wet.

C◗The shaver runs at a safe low voltage of 12

volts.It is watertight and can be cleaned

under the tap.Do not rinse with water hotter

than 80cC.

Charge indications

C◗Charging

As soon as you start charging the empty shaver,

the green pilot light will go on.

A fully charged shaver has a cordless shaving time

of up to 70 minutes.

Charging

Recharge and keep the appliance at a

temperature between 5cC and 35cC.

The powerplug is suitable for mains voltages

ranging from 110 to 240V.

You can also shave without charging by

connecting the shaver to the mains.

To extend the lifetime of the batteries,remove

the powerplug from the wall socket and pull the

appliance plug out of the shaver when the

batteries have been fully charged.

ENGLISH4

C1Insert the appliance plug into the shaver as

far as the line on the plug.

2Put the powerplug in the wall socket.

Do not recharge the shaver in a closed pouch.

3When charging for the first time or after a

long period of disuse:leave the shaver to

charge continuously for 4 hours.

Charging normally takes approx.1 hour.

4Remove the powerplug from the socket

and pull the appliance plug out of the

shaver when the batteries have been fully

charged.

With the special Philishave Car Cord (HQ6010),

you can also charge the appliance at 12 volts (e.g.

in a car).This cord is available from your Philishave

dealer.

Shaving

1Switch the shaver on by pressing the on/off

button once.

C2Move the shaving heads quickly over your

skin,making both straight and circular

movements.

Shaving on a dry face gives the best results.

Your skin may need 2 or 3 weeks to get

accustomed to the Philishave system.

3Switch the shaver off.

ENGLISH 5

C4Put the protection cap on the shaver to

prevent damage.

Replace the shaving heads (type HQ6 Quadra

Action) every 2 years for optimal shaving results.

Trimming

For grooming sideburns and moustache.

C1Open the trimmer by pushing the slide

upwards.

The trimmer can be activated while the motor is

running.

Cleaning

Regular cleaning guarantees better shaving

performance.

The easiest and most hygienic way to clean the

appliance is to rinse the shaving unit every week

with hot water (60cC-80cC).

When you clean the appliance,it is not necessary

to take the shaving heads (cutters and guards)

apart.If you want to take them apart,be sure not

to mix up the cutters and guards,since grinding of

the cutters in the guards only guarantees optimal

performance for each matching set.If you

accidentally mix up the sets,it could take several

weeks before optimal shaving performance is

restored.

ENGLISH6

Every week:shaving unit

1Switch the shaver off,remove the

powerplug from the wall socket and pull

the appliance plug out of the shaver.

C2Press the release button and open the

shaving unit.

C3Clean the shaving unit and the hair

chamber by rinsing them under a hot tap

for some time.

C4Leave the shaving unit open to let the

appliance dry completely.

You can also clean the hair chamber without

water by using the brush supplied.

Every six months:trimmer

1Switch the shaver off,remove the

powerplug from the wall socket and pull

the appliance plug out of the shaver.

C2Clean the trimmer every time you have

used it.

C3Lubricate the trimmer teeth with a drop

of sewing machine oil every six months.

ENGLISH 7

Replacing the shaving heads

Replace the shaving heads every two years for

optimal shaving results.

1Switch the shaver off,remove the

powerplug from the socket and pull the

appliance plug out of the shaver.

C2Press the release button to open the

shaving unit.

C3Turn the wheel anti-clockwise and remove

the retaining frame.

C4Remove the shaving heads and place the

new ones in the shaving unit in such a way

that the parts with the small holes point

towards the centre of the shaving unit.

Make sure that the projections of the shaving

heads fit exactly into the recesses.

C5Reassemble the shaving unit by replacing

the retaining frame.Press the wheel and

turn it clockwise.

If the shaving heads have been properly inserted,

a shiny circle is visible on top of the shaving unit.

Replace damaged or worn shaving heads with

Philishave HQ6 Quadra Action shaving heads

only.

ENGLISH8

Storing

C◗Put the protective cap on the shaver to

prevent damage.

◗Store the appliance in the luxury pouch.

Disposal of batteries

Remove the batteries when you discard the

shaver.Do not throw the batteries away with the

normal household waste,but hand them in at an

official collection point.You can also take the

batteries to a Philips Service Centre,which will

dispose of them in an environmentally safe way.

Only remove the batteries if they are completely

empty.

1Remove the powerplug from the socket

and pull the appliance plug out of the

shaver.

C2Let the shaver run until it stops,undo the

screws and open the shaver.

3Remove the batteries.

Do not connect the shaver to the mains again

after the batteries have been removed.

ENGLISH 9

Troubleshooting

1Reduced shaving performance

BCause 1:the shaving heads are dirty.

BThe shaver has not been rinsed long enough or

the water used was not hot enough.

◗Clean the shaver thoroughly before you

continue shaving (see 'Cleaning').

BCause 2:long hairs are obstructing the shaving

heads.

C◗Remove the retaining frame.

◗Remove the hairs with the brush supplied.

C◗Clean the cutters and guards.

Do not clean more than one cutter and guard at

a time,since they are all matching sets.If you

accidentally mix up the cutters and guards,it may

take several weeks before optimal shaving

performance is restored.

◗Put the retaining plate back onto the shaving

unit.

BCause 3:shaving heads are damaged or worn.

◗Remove the retaining frame.

◗Remove the old shaving heads from the

shaving unit and replace them with new ones

Damaged or worn shaving heads (cutters and

guards) must only be replaced with the original

Philishave HQ6 Quadra Action shaving heads.

ENGLISH10

◗Put the retaining plate back onto the shaving

unit.

2The shaver does not work when the

ON/OFF button is pressed

BCause:the batteries are empty.

3Recharge the batteries.

Guarantee & service

If you need information or if you have a problem,

please visit the PhilipsWeb site at

www.philips.com or contact the Philips Customer

Care Centre in your country (you will find its

phone number in the worldwide guarantee

leaflet).If there is no Customer Care Centre in

your country,turn to your local Philips dealer or

contact the Service Department of Philips

Domestic Appliances and Personal Care BV.

ENGLISH 11

Wichtig

◗Verwenden Sie zumAufladen desApparats

nur das mitgelieferte Steckernetzgerät

HQ8000/ 6000.

◗Das Steckernetzgerät wandelt 110 bis 240Volt

in 12Volt um.

C◗Achten Sie darauf,daß das Steckernetzgerät

HQ8000/ 6000 nicht nass wird.

C◗Das Gerät arbeitet mit einer ungefährlichen

Niedrigspannung von 12Volt.Es ist

wasserdicht und kann unter fließendem

Wasser gereinigt werden.Spülen Sie es nicht

mitWasser ab,das heißer ist als 80cC.

Ladeanzeige

C◗Aufladen

Sobald Sie den Akku aufzuladen beginnen,beginnt

die grüne Kontroll-Lampe kontinuierlich zu

leuchten

Mit voll aufgeladenen Akkus können Sie sich ca.

70 Minuten rasieren.

Aufladen

Laden Sie den Akku bei einerTemperatur

zwischen 5cC und 35cC,und bewahren Sie das

Gerät auch in diesemTemperaturbereich auf.

Das Steckernetzgerät ist für Netzspannungen

zwischen 110 und 240V geeignet.

Sie können sich auch bei leeren Akkus rasieren,

indem Sie den Rasierer an das Netz anschließen.

DEUTSCH12
