Philips HQ4819/16 Manual de usuario

HQ481

ENGLISH 4

 15

 28

 39

 50

 61

 72

 84

 95

 106

 118

 130

 142

 153

 164

 175

Introduction

Congratulations on your purchase and welcome

to Philips! To fully benet from the support that

Philips offers, register your product at www.philips.

com/welcome.

Important

Read this user manual carefully before you use the

appliance and save it for future reference.

Danger

Keep the shaver and the mains cord dry.

Warning

This appliance is not intended for use by persons

(including children) with reduced physical, sensory

or mental capabilities, or lack of experience

and knowledge, unless they have been given

supervision or instruction concerning use of the

appliance by a person responsible for their safety.

Children should be supervised to ensure that they

do not play with the appliance.

Do not use the shaver or the mains cord if it is

damaged.

If the mains cord is damaged, always have it

replaced with one of the original type in order to

avoid a hazard.

Caution

Always put the protection cap on the shaver

to protect the shaving heads when you are

travelling.

Only use the mains cord supplied.

Charge and store the shaver at a temperature

between 5°C and 35°C.

Do not recharge the shaver in a closed pouch.

ENGLISH

The appliance is equipped with an automatic

voltage selector and is suitable for mains

voltages from 100 to 240 volts.

Noise level: Lc = 60 dB(A)

Compliance with standards

This Philips appliance complies with all standards

regarding electromagnetic elds (EMF). If handled

properly and according to the instructions in this

user manual, the appliance is safe to use based on

scientic evidence available today.

Charging

Make sure the appliance is switched off before you

start charging it.

When you charge the shaver for the rst time

or after a long period of disuse, let it charge

continuously for 4 hours. Charging normally takes

approx. 90 minutes.

You can also shave without charging, simply connect

the shaver to the mains.

Do not leave the appliance connected to the mains

for more than 24 hours.

Charge indications

Charging

As soon as you start charging the empty shaver,

the green charging light goes on.

CHARGECHARGE

ENGLISH 5

Battery fully charged

When the battery is fully charged, the green

charging light starts ashing.

Charging the appliance

Charge the appliance when the motor stops or

starts running slower.

Do not recharge the shaver in a closed pouch.

1 Put the appliance plug in the shaver.

2 Put the mains plug in the wall socket.

3 Remove the mains plug from the wall socket

and pull the appliance plug out of the shaver

when the battery is fully charged.

Cordless shaving time

A fully charged shaver has a cordless shaving time of

up to 50 minutes.



Shaving

1 Press the switch lock (1) and push the on/off

slide upwards (2) to switch on the appliance.

Note:The switch lock prevents that the appliance

is switched on accidentally.

CHARGECHARGE

ENGLISH6

2 Move the shaving heads quickly over your skin,

making both straight and circular movements.

Shaving on a dry face gives the best results.

Your skin may need 2 or 3 weeks to get accustomed

to the Philips shaving system.

3 Push the on/off slide downwards to switch

off the shaver.

4 Put the protection cap on the shaver every

time you have used it, to prevent damage.



You can use the trimmer to trim your sideburns and

moustache.

1 Push the slide upwards to open the trimmer.

The trimmer can be activated while the motor is

running.

Cleaning and maintenance

Regular cleaning guarantees better shaving

performance.

For easy and optimal cleaning, the Philips Action

Clean (shaving head cleaner, type HQ100) is

available. Ask your Philips dealer for information.

Note:The Philips Action Clean may not be available in

all countries. Contact the Customer Care Centre in your

country about the availability of this accessory.

You can also clean the shaver in the following way:

ENGLISH 7

Every week: shaving unit and hair chamber

1 Switch off the shaver, remove the mains plug

from the wall socket and pull the appliance plug

out of the shaver.

2 Clean the top of the appliance rst. Use the

brush supplied.

3 Press the release button (1) and remove the

shaving unit (2).

4 Clean the inside of the shaving unit and the

hair chamber with the brush.

5 Put the shaving unit back onto the shaver.

Every two months: shaving heads

1 Switch off the shaver, remove the mains plug

from the wall socket and pull the appliance plug

out of the shaver.

ENGLISH8

2 Press the release button (1) and remove the

shaving unit (2).

3 To remove the retaining frame, push the sides

of the central spring towards each other (1).

Then lift the retaining frame out of the shaving

unit (2).

4 Slide the shaving heads out of the retaining

frame and clean them one by one.

Do not mix up the cutters and the guards.

This is essential since each cutter has been

ground with its corresponding guard for optimal

performance. If you accidentally mix up the sets, it

could take several weeks before optimal shaving

performance is restored.

5 Clean the cutter with the short-bristled side of

the brush.

Brush carefully in the direction of the arrow.

6 Brush the guard.

ENGLISH 9

7 Slide the shaving heads back into the retaining

frame and put the retaining frame back into the

shaving unit.

8 Put the shaving unit back onto the shaver.

For extra thorough cleaning, put the shaving heads in

a degreasing liquid (e.g. alcohol) every six months.

To remove the shaving heads, follow steps 1 to 4

described above.After cleaning, lubricate the central

point on the inside of the guards with a drop of

sewing machine oil to prevent wear of the shaving

heads.



Clean the trimmer every time you have used it.

1 Switch off the shaver, remove the mains plug

from the wall socket and pull the appliance plug

out of the shaver.

2 Clean the trimmer with the brush supplied.

3 Lubricate the trimmer teeth with a drop of

sewing machine oil every six months.

Storage

1 Put the protection cap on the shaver to

prevent damage.

2 Store the appliance in the luxury pouch

supplied.

ENGLISH10

Replacement

Replace the shaving heads every two years for

optimal shaving results.

Replace damaged or worn shaving heads with HQ4

ÇPhilips shaving heads only.

1 Switch off the shaver, remove the mains plug

from the wall socket and pull the appliance plug

out of the shaver.

2 Press the release button (1) and remove the

shaving unit (2).

3 To remove the retaining frame, push the sides

of the central spring towards each other (1).

Then lift the retaining frame out of the shaving

unit (2).

4 Slide the shaving heads out of the retaining

frame.

5 Slide the new shaving heads into the retaining

frame.

6 Put the retaining frame back into the shaving

unit.

7 Put the shaving unit back onto the shaver.

ENGLISH 11



The following accessories are available:

HQ4+ Philips shaving heads.

HQ100 Philips Action Clean (shaving head

cleaner).

HQ101 Philips Action Clean rell (shaving head

cleaning liquid).

HQ110 Philips shaving head cleaner (shaving head

cleaning spray).

Environment

Do not throw away the appliance with the normal

household waste at the end of its life, but hand

it in at an ofcial collection point for recycling. By

doing this, you help to preserve the environment.

The built-in rechargeable battery contains

substances that may pollute the environment.

Always remove the battery before you discard

and hand in the appliance at an ofcial collection

point. Dispose of the battery at an ofcial

collection point for batteries. If you have trouble

removing the battery, you can also take the

appliance to a Philips service centre.The staff of

this centre will remove the battery for you and

will dispose of it in an environmentally safe way.

Removing the battery

Only remove the rechargeable battery if it is

completely empty.

1 Remove the mains plug from the wall socket

and pull the appliance plug out of the shaver.

ENGLISH12
