Philips DC200/79 Manual de usuario

DC200Docking Entertainment System

www.philips.com/welcome

User Manual

DC200_79_CCR 2008.2.21 17:01 Page 1

DC200_79_CCR 2008.2.21 17:01 Page 2

P-01

AL1

840

T001

DC200_79_CCR 2008.2.21 17:01 Page 3

English

Congratulations on your purchase and welcome to Philips! To fully

benefit from the support that Philips offers, register your product at

www.philips.com/welcome.

SUPPLIED ACCESSORIES

–1Xcertified AC/DC 9V adaptor

(Brand name: PHILIPS, Model No.: AS140-090-Dw,

Input: 100-240V ~ 50/60Hz 0.7A, Output: 9.0V 1.56A)

– 4Xdock adaptors (for different iPod types)

– 1XAUX-IN cable

CONTROLS

(See 1)

1SOURCE

–selects TUNER/iPod/USB/NATURE/AUX mode

2POWER

–switches the system on or to standby mode

–stops active alarm for 24 hours

–deactivates the sleep function

3SLEEP

–activates/

deactivates

the sleep function

4iPod MENU

–

enters the iPod menu

5PROG / SET TIME

–activates/confirms clock time setting

3/ 4/1/ 2

for iPod . . . . . . . . . . . . . navigates in iPod menu

ALBUM/PRESET -/+

1/ 2

–

selects a preset radio station

–

selects albums in USB mode

–

selects time zone in clock mode

VOLUME

3/ 4

–

adjusts the sound level

DC200_79_CCR 2008.2.21 17:01 Page 4

for iPod

. . . . . . . . . . . . . .

confirms menu selection.

7Dock connector

–

connects iPod player

8USB jack

–

connects an external USB mass storage device

REPEAT

ALARM /

BRIGHTNESS CONTROL

–switches off the alarm for a 9 minute period

–changes the brightness of the display illumination

0TUNING

¡1 / 2™

–adjusts clock/alarm time

–tunes to radio stations

–selects previous/next tracks in the iPod/USB mode

–fast searches forward/backward in the iPod/USB mode

MODE

–

selects different play modes: e.g. REPEAT or SHUFFLE (random order).

–starts/pauses playback in the iPod/USB mode

–stops playback in the iPod/USB mode

ALM

2 ALM

–

activates/confirm alarm 1/alarm 2 time setting

–displays alarm 1/

alarm

2 time

–switches off alarm 1/

alarm

2 time

@DISPLAY

–

shows clock/alarm times and status of the set

#AUX IN jack (3.5 mm)

–

connects to external audio source

$POWER jack

–

socket for AC/DC 9V adaptor

Pigtail

–improves FM reception

DC200_79_CCR 2008.2.21 17:01 Page 5

POWER SUPPLY

Mains adaptor

Connect the mains adaptor to the set's DC 9V socket and to the power socket.

Helpful hints: To avoid damage to the set, use only the adaptor supplied!

The power rating is located on the bottom of the set.

SELF-POWERED BACK-UP

The self-powered back-up conveniently allows your alarm and clock time settings to be

stored for up to 10 minutes when there is a power interruption e.g. AC power failure.

The complete clock radio and backlight illumination will be switched off.

If power supply returns after 10 minutes and the display shows:

•clock time blinking - indicates you need to re-adjust the clock time.

BASIC OPERATION.

Switching on the system

•Press POWER.

™

The system will switch to the last selected source.

Switching the system to standby mode

•In any source mode, press POWER.

Illumination brightness

Press REPEAT

ALARM /

BRIGHTNESS CONTROL once or more.

•

The brightness of the display can be adjusted:

Bright ➟Low ➟Off ➟Bright

SETTING THE CLOCK

1In standby mode, press and hold PROG/SET TIME until clock digits flashes.

Hold down or press ¡1 /2™ repeatedly to set and adjust the hours.

3Press PROG/SET TIME

to confirm.

™

The clock digits for the minutes flash.

Hold down or press ¡1 /2™ repeatedly to set and adjust the minutes.

DC200_79_CCR 2008.2.21 17:01 Page 6

5Press PROG/SET TIME

to confirm.

In clock mode, press

ALBUM/PRESET -/+

1/2to set your time zone.

To zoom in/out the clock display, press

MODE

in clock mode.

TUNER

Press

SOURCE

repeatedly to switch on the radio (FM only).

™

Display shows the radio frequency of the last selected waveband. Your pre-

set station is also shown if you are listening to a preset.

(

See 2

)

Adjust the sound using VOLUME 3/4

3To select preset stations, press ALBUM/PRESET -/+

1/2

once or repeatedly.

TUNING TO RADIO STATIONS

1Press and hold

¡1 /2™

until the frequency in the display starts changing.

™After the system tunes to a station of sufficient reception, display shows its

frequency.

•To tune to a weak station, press

¡1 /2™

briefly and repeatedly until an

optimal reception is found.

To improve reception (FM):

Extend and position the pigtail fully to obtain optimum reception.

STORING AND USING PRESET STATIONS

You can store up to 20 FM radio stations in the memory.

1Tune to your desired station (see TUNING TO RADIO STATIONS).

Press

PROG to activate the programming, and then press ALBUM/PRESET -/+

/ 2

to select a desired preset number

Press

PROG again to confirm.

Press

ALBUM/PRESET -/+

1/ 2

to listen to a preset station.

AUTOSTORE: Automatic programming

Press and hold

PROG for more than two seconds.

™Available radio stations will be automatically stored.

DC200_79_CCR 2008.2.21 17:01 Page 7

USING THE ALARM

GENERAL

Two different alarm times can be set. This can be useful when you need to be

woken up at a different time e.g. during the week and at the weekend, and you

can set different wake-up modes:

•Tuner mode.

•iPod/USB mode.

•Nature sound mode.

•Buzzer mode. The gentle wake buzzer alarm increases its beep tone frequency

within seconds.

SETTING THE ALARM TIME AND MODE

(See 3)

1In any mode, press and hold 1 ALM or 2 ALM for two seconds.

™

AL1

AL2

icon and the hour digits flash.

Hold down or press ¡1 /2™ repeatedly to set and adjust the hours.

3Press 1 ALM or 2 ALM

to confirm.

™

AL1

AL2

icon and the minutes digits flash.

Hold down or press ¡1 /2™ repeatedly to set and adjust the mintues.

5Press 1 ALM or 2 ALM

to confirm.

™

The icon for the current alarm mode flashes.

6Press

¡1 2™

SOURCE repeatedly to select your desired alarm mode.

•For Nature sound mode, press ALBUM/PRESET -/+

1/ 2

to select your desired

nature sound track.

™

At the set alarm time, the selected sound source or buzzer will switch on

automatically.

Helpful hints:

–

If you have selected TUNER alarm mode,make sure you have properly tuned to a

station before turning off the set.

–

If you have selected iPod/USB alarm mode,make sure you have connected the com-

patible iPod player or USB device, or the buzzer mode will be selected automatically.

–

To check the alarm time setting for AL1 or AL2, press 1 ALM or 2 ALM.

DC200_79_CCR 2008.2.21 17:01 Page 8

SWITCHING OFF THE ALARM

There are three ways of switching off the alarm. Unless you cancel the alarm

completely, the 24-hour ALARM RESET will be automatically selected after 59

minutes from the time your alarm first goes off.

24 HOUR ALARM RESET

If you want the alarm mode to be stopped immediately but also wish to retain

the same alarm setting for the following day:

•

Press

POWER

or 1

ALM /

ALM

REPEAT ALARM

This repeats your alarm call at 9 minute intervals.

•

During the alarm call, press REPEAT

ALARM /

BRIGHTNESS CONTROL.

™

Display shows

AL1

AL2

flashing during a repeat alarm.

•

Repeat if desired (up to a maximum of 6 times).

CANCELING THE ALARM COMPLETELY

•

Press 1

ALM

or 2

ALM

button once or more until

AL1

AL2

disappears.

DOCK (See 4)

By connecting the iPod to your DC200, you can listen to the music stored in iPod

player through the powerful speakers of the set.

COMPATIBLE PORTABLE PLAYERS

•

Most Apple iPod models with 30-pin dock connector as follows:

iPod Touch 4GB/8GB, 20GB, 40GB, iPod Photo 20GB/30GB/40GB/60GB, iPod

Video 30GB/60GB/80GB, iPod Classic 80GB/160GB, Mini and Nano.

DOCK ADAPTORS

Before plugging your player in the dock, snap the suitable dock adaptor into the

dock to provide a snug fit for the player to be docked.

Selecting the correct dock adaptor

•For the iPod dock, 4 dock adaptors of different type, as indicated at the back

of the adaptor, are included to fit the following iPod:

iPod Touch 4GB/8GB, 20GB, 40GB, iPod Photo 20GB/30GB/40GB/60GB, iPod

Video 30GB/60GB/80GB, iPod Classic 80GB/160GB, Mini and Nano.

DC200_79_CCR 2008.2.21 17:01 Page 9

PLAYING iPod USING DC200

Remove the top cover of dock.

Snap the compatible iPod into the dock connector.

Press SOURCE repeatedly to switch on the iPod mode.

•

Make sure that you have powered on Apple iPod before selecting iPod source.

™

On the DC200’s display, “iPod” is displayed when iPod is connected.

he connected iPod player will play automatically.

Notes:

–

By using the buttons ( 2;, ¡1, 2™ and VOLUME ) on the DC200, the following

playback features are available: Play/Pause, selecting next/previous track, fast for-

warding/rewinding and changing volume.

–

The buttons ( 2;, ¡1, 2™ and VOLUME ) on the DC200 can work only with

playback of the audio contents stored on the docked player.

– To navigate the iPod menu, you may use iPod MENU, 34 and OK buttons on

the set.

– When you press iPod MENU in iPod mode, 1234 and OK buttons first per-

form the navigation function, and then restore the original functions.

– For iPod operations and features, refer to the user manual of your iPod player.

– This set does not support iPod video output.

Using USB connectivity

•DC200 is fitted with a USB port on the top panel, offering a plug and play feature

which allows you to play, from your DC200, digital music and audio contents stored

on a USB mass storage device.

•Using a USB mass storage device, you can also enjoy all the features offered by

DC200.

Compatible USB mass storage devices:

With the DC200, you can use

– USB flash memory (USB 2.0 or USB 1.1)

– USB flash player (USB 2.0 or USB 1.1)

•USB device which requires driver installation under Windows XP is not

supported.

DC200_79_CCR 2008.2.21 17:01 Page 10

Otros manuales para DC200/79

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Estación de acoplamiento de Philips

Philips

Philips DC190 Instrucciones de montaje

Philips

Philips DCM230/55 Manual de usuario

Philips

Philips DCD778 Manual de usuario

Philips

Philips DC910W/37 Manual de usuario

Philips

Philips AZD208/79 Manual de usuario

Philips

Philips DC200/05 Manual de usuario

Philips

Philips DCM109/93 Manual de usuario

Philips

Philips DC276 Manual de usuario

Philips

Philips MCM138D/79 Manual de usuario

Philips

Philips DCM580 Manual de usuario

Philips

Philips AJ5305D Manual de usuario

Philips

Philips ORD2105B/12 Manual de usuario

Philips

Philips DC190/79 Manual de usuario

Philips

Philips AS111/37 Manual de usuario

Philips

Philips AJ7040D Manual de usuario

Philips

Philips AJ300D - AJ Clock Radio Manual de usuario

Philips

Philips AJ5300DB Manual de usuario

Philips

Philips DC290/93 Manual de usuario

Philips

Philips ORD2100C/37 Manual de usuario

Philips

Philips DLA99901/10 Manual técnico

Philips

Philips AZ1330D/37B Manual de funcionamiento

Philips

Philips AJ300D Manual de usuario

Philips

Philips Fidelio DS3881W/37 Manual de usuario

Philips

Philips DC910/98 Manual de usuario

Manuales populares de Estación de acoplamiento de otras marcas

Sony

Sony Dream Machine XDR-DS12iP Manual de usuario

Acer

Acer USB Type-C Dock II Manual de usuario

ATEN

ATEN UC-2000 Manual de usuario

Xcellon

Xcellon HDD-202 Manual de usuario

Dok

Dok CR09 Manual de usuario

IOGear

IOGear Travel Pro GUD3C09 Manual de usuario

RKI

RKI SDM-E2 Manual de usuario

iHome

iHome iP15 Manual de usuario

VITURE ONE

VITURE ONE MOBILE DOCK Manual de usuario

Lindy

Lindy 42984 Manual de usuario

CipherLab

CipherLab 8001 Manual de usuario

Pyle

Pyle PIPDSP2 Manual de usuario

Avol

Avol AS2350 Manual de usuario

Datalogic

Datalogic JoyaTouch Manual de usuario

Targus

Targus DOCK315EUZ Manual de usuario

Akasa

Akasa DuoDockX3 AK-DK08U3-BK Manual de usuario

Sirius Satellite Radio

Sirius Satellite Radio SUBX2082808a Manual de usuario

OWC

OWC Thunderbolt Dock Manual de usuario
