Philips AZ1330D/05 Manual de funcionamiento

1 Choosing Power Supply

aConnect the AC power cord to the

AC~ Mains inlet and the wall socket.

-OR-

bOpen the battery door and insert 6

x D batteries (not included).

Quick Use

Guide

Quick Use

Guide

6 x R20 • UM-1 • D-CELLS

2 Listening to Radio

aPress SOURCE repeatedly to select

the tuner source.

bPress

PROGRAM

for more than two

seconds to program all available

stations in order of waveband.

cPress PRESET/ALBUM +- until the

desired preset station is displayed.

3 Playing a disc

This player plays Audio Discs including

CD-R/CD-RW, MP3-CD and WMA.

aPress SOURCE repeatedly to select

CD.

bOpen the disc door.

cInsert a disc with the printed side

facing up and close the door.

dPress 38 to start playback.

eTo stop disc playback, press 9.

AZ1330D

R-20,UM-1 or D-cells

(not included)

Tip:

Refer to the user manual supplied for detailed

descriptions of “Compatible portable player”,

“Selecting the correct dock adaptor”, “Installing

the dock adaptor”, and the important notes for

dock operation.

4 Playing Apple iPod using AZ1330D

aSelect a correct iPod adaptor, then snap it

to the dock to provide a snug fit for the

player to be docked.

• 8 dock adaptors of different type, as indi-

cated at the back of the adaptor, are

included to fit the following iPod: 20GB,

40GB, 20/30GB photo, 40/60GB photo,

30GB video, 60/80GB video, mini and nano.

bSnap a compatible iPod into the dock

connector.

• AZ1330D will auto switch to DOCK

source.

cThe connected player will play automatically.

• In the power-on and standby mode of

AZ1330D, you can charge the iPod when

docking.

•

The buttons ( 2;, ¡1, 2™ and VOLUME ) on

the AZ1330D and its remote control can

work only with playback of the audio

contents stored on the docked player.

AZ1330D_QSG_05_iPod 2007.3.12 4:11 PM Page 1

Removing the insulation plastic tab before use

1Telescopic antenna –improves FM

reception

2DOCK –

selects dock source

3Dock connector

–connects iPod

player

VOLUME

–

adjusts volume level

MODE – selects different play modes:

e.g. REPEAT or SHUFFLE (random order)

6PROG

RAM

For disc

–programs tracks and reviews the program

For Tuner

–auto searches and stores radio stations

7ALBUM/PRESET

+/-

For MP3-CD/ WMA play:

–select albums

For Tuner

–selects a preset radio station

8/– opens/closes the disc tray

SOURCE:

–

selects CD/MP3-CD, iPod mode,Tuner

or AUX

POWER

–

powers on/off the system

–

starts or pauses disc/iPod playback

∞§

For disc

/ iPod play:

–skips to the beginning of a current/

previous/ later track

–fast searches backwards and forwards within a

track

For Tuner:

–tunes to a radio station

–

stops disc playback;

–

erases a program

DBB –turns on/off bass enhancement

@p– 3.5 mm stereo headphone socket

Helpful hints: The speakers will be muted when head-

phones are connected to the set.

AUX jack

–

connects an external source (3.5 mm

socket)

$Battery door –opens to insert 6 x 1.5V

R-20/ -UM1/ D-cells

%Disc tray –loads a disc

^iR – infrared sensor for remote control

AZ1330D_QSG_05_iPod 2007.3.12 4:11 PM Page 2
