Philips AJ5300DB Manual de usuario

www.philips.com/welcome

Always there to help you

AJ5300DB

User manual

Question?

Contact

Philips

English

Contents

1 Important 2

Safety 2

2 Your Docking Entertainment System 3

Introduction 3

What's in the box 3

Overview of the main unit 3

3 Get started 5

Connect power 5

Turn on 5

Set time and date 6

4 Play 6

Play from iPod/iPhone 6

Listen to radio 7

Play from an external device 7

Adjust volume 8

5 Other features 8

Set alarm timer 8

Set sleep timer 9

Adjust display brightness 9

6 Product information 9

Specications 9

7 Troubleshooting 10

8 Notice 11

Contents

2EN

1 Important

Safety

• Heed all warnings, and follow all

instructions.

• Do not block any ventilation openings.

Install in accordance with the

manufacturer's instructions.

• Do not install near any heat sources such

as radiators, heat registers, stoves, or other

devices(includingampliers)thatproduce

heat.

• Protect the power cord from being

walked on or pinched, particularly at plugs,

convenience receptacles, and the point

where they exit from the device.

• Onlyuseattachments/accessoriesspecied

by the manufacturer.

• Unplug the device during lightning storms

or when unused for long periods of time.

• Referallservicingtoqualiedservice

personnel. Servicing is required when the

device has been damaged in any way, such

as power-supply cord or plug is damaged,

liquid has been spilled or objects have

fallen into the device, the device has been

exposed to rain or moisture, does not

operate normally, or has been dropped.

• The device shall not be exposed to

dripping or splashing.

• Do not place any sources of danger on

thedevice(e.g.liquidlledobjects,lighted

candles).

• Where the plug of the Direct Plug-in

Adapter is used as the disconnect device,

the disconnect device shall remain readily

operable.

Warning

•Never remove the casing of this device.

•Never place this device on other electrical equipment.

•Keep this device away from direct sunlight, naked

amesorheat.

•Toreducetheriskofreorelectricshock,donot

expose this device to rain or moisture.

•Make sure that you always have easy access to the

power cord, plug or adapter to disconnect this device

from the power.

English

2 Your Docking

Entertainment

System

Congratulations on your purchase, and

welcometoPhilips!Tofullybenetfromthe

support that Philips offers, register your product

at www.philips.com/welcome.

If you contact Philips, you will be asked for the

model and serial number of this apparatus.The

model number and serial number are on the

bottom of the apparatus.Write the numbers

here:

Model No. __________________________

Serial No. ___________________________

Introduction

With this clock radio, you can

• listen to FM radio;

• enjoy audio from iPod/iPhone or an

external device;

• set alarms to ring at different time;

• choose buzzer, radio, or audio in iPod/

iPhone as your alarm source;

• experience various features brought by

HomeStudio app.

What's in the box

Check and identify the contents of your

package:

• Main unit

• AC/DC power adaptor

• User manual

4EN

Overview of the main unit

a AL1/AL2

• Set alarm.

• View alarm settings.

• Activate/deactivate alarm timer.

b SOURCE

• Select source.

• Turn on/off the clock radio.

d DOCK

• Dock for iPod/iPhone.

e - VOLUME +

• Adjust volume.

f SNOOZE/BRIGHTNESS

• Snooze alarm.

• Adjust display brightness.

g TIME SET

• Set the time.

English

h TUNING

• Tune or scan to an FM radio station.

i DC IN

• Power supply socket.

j FM ANTENNA

• Improve FM reception.

k MP3-LINK

• Connect an external audio device.

l SLEEP

• Set sleep timer.

3 Get started

Always follow the instructions in this chapter in

sequence.

Connect power

Caution

•Risk of product damage! Make sure that the power

voltage corresponds to the voltage printed on the back

or underside of the unit.

•Risk of electric shock! When you unplug the power

adapter, always pull the plug from the socket. Never

pull the cord.

•Before connecting the power adapter, make sure that

you have completed all other connections.

•Use the supplied power adapter only.

Turn on

Press .

» The clock radio switches to the last

selected source.

Switch to standby mode

Press to switch the clock radio to standby

mode.

» Theclock(ifset)isdisplayed.

6EN

Set time and date

1 In standby mode, press and hold TIME SET

on the back of your clock radio for more

than two seconds.

» [12H] or [24H] begins to blink.

2 Press / repeatedly to select 12/24

hour format.

3 Press TIME SETtoconrm.

» The hour digits begin to blink.

4 Repeat steps 2-3 to set hour and minute.

Note

•If clock is not manually set, when iPod/iPhone is

connected, the unit synchronizes time from the iPod/

iPhone automatically.

Tip

•The accuracy of the transmitted time depends on the

docked iPod/iPhone that transmits the time signal.

4 Play

Play from iPod/iPhone

You can enjoy audio from iPod/iPhone through

this clock radio.

Compatible iPod/iPhone

The unit supports the following iPod, iPhone

models:

Made for.

• iPod classic

• iPod touch (1st, 2nd, 3rd, and 4th

generation)

• iPod nano (1st, 2nd, 3rd, 4th, 5th, and 6th

generation)

• iPhone 4S

• iPhone 4

• iPhone 3GS

• iPhone 3G

• iPhone

Install HomeStudio App

Philips HomeStudio app brings a suite of new

features to your clock radio, including FM radio

programming and a multi-function alarm clock.

To enjoy more features, you are recommended

to install this free HomeStudio app.

Note

•Make sure that your iPod/iPhone is connected to the

Internet.

1 Press SOURCE repeatedly to select

DOCK mode.

English

2 Insert your iPod/iPhone into the dock.

3 Fortherst-timeuse,youwillbeaskedto

install the HomeStudio app on your iPod/

iPhone.

4 Tap [Yes](yes)toaccepttheinstallation

request.

5 Follow the on-screen instructions to

complete the installation.

Philips HomeStudio app only can be installed in

the following iPod, iPhone models:

• iPod touch (1st, 2nd, 3rd, and 4th

generation)

• iPhone 4S

• iPhone 4

• iPhone 3GS

• iPhone 3G

• iPhone

Play music in the iPod/iPhone

Select a track from your iPod/iPhone playlist,

and then press .

» Music streams from your iPod/iPhone

to the clock radio.

SOURCE

Charge the iPod/iPhone

When your clock radio is connected to power,

the docked iPod/iPhone begins to charge

automatically.

Remove the iPod/iPhone

Pull the iPod/iPhone out of the dock.

Listen to radio

Note

•Keep the unit away from other electronic devices to

avoid radio interference.

•For better reception, do not place iPod/iPhone into

the dock when you listen to the radio. Fully extend and

adjust the position of the FM antenna.

Tune to FM radio stations

You also can tune to radio stations from your

clock radio.

1 Press SOURCE repeatedly to select FM

tuner.

2 Press and hold / on the back

of your clock radio for more than two

seconds.

» The radio tunes to a station with

strong reception automatically.

3 Repeat step 2 to tune to more stations.

To tune to a station manually:

Press / repeatedlyuntilyoundoptimal

reception.

Play from an external device

You can also listen to an external audio device

through this clock radio.

1 Press SOURCE to select the AUX source.

8EN

2 ConnecttheMP3linkcable(notsupplied)

to:

• the MP3-LINKsocket(3.5mm)atthe

back of your clock radio.

• the headphone socket of an external

device.

3 Start to play the device (see the user

manualofthedevice).

Adjust volume

VOLUME

5 Other features

Set alarm timer

Set alarm

You can set two alarms to ring at different time.

Buzzer, FM radio, or your last listened audio in

the iPod/iPhone can be selected as alarm sound.

Note

•Make sure that you have set the clock correctly.

1 Press and hold AL1/AL2 for more than

two seconds to activate alarm setting

mode.

» The hour digits and alarm icon begin

to blink.

2 Press / repeatedly set the hour.

3 press AL1/AL2toconrm.

» The minute digits begin to blink.

4 Repeat steps 2-3 to set the minute, select

an alarm source (buzzer, FM radio, or

dock),andadjustvolume.

Tip

•If iPod/iPhone is selected as alarm source, but no iPod/

iPhone is connected, the clock radio switches to buzzer

source instead.

•Forthealarm(s)setthroughtheclockradio,you

can also select the nature sounds stored in the

HomeStudio app as alarm sound.
