Philips DCP750 Manual de usuario

Connecting and

using your iPod

player

1Pull out the iPod

connector.

2Dock your iPod player

with the top

entering first as

shown.

3Push in the iPod

connector.

This portable DVD player is designed with

a built-in lithium battery to supply power

to the player when you are on travel.

1Slide the POWER switch to the OFF

position (charging of the DVD player only

possible in the power-off mode).

2Connect the supplied power adaptor cord

(or the car adaptor) to the player and AC

mains (or the car cigarette lighter outlet)

to start charging.

➜The CHG indicator turns green.

➜When the battery is fully charged, the

indicator turns off.

3Disconnect the power adaptor cord (or

the car adaptor) when the CHG indicator

turns off.

Notes:

– You can also connect the supplied power

adaptor cord (or the car adaptor) to the player

and AC mains (or the car cigarette lighter outlet)

directly wherever possible.

Charge your battery

Quick start guide

Docking Entertainment System

DVD Portable with dock for iPod

3OPEN HERE

DCP750/850

Prepare your remote

control

Remove the protective plastic

tab (first time users only).

➜Your remote control is

now ready for use.

SOURCE

4Switch on your iPod player and set:

1) "TV Out" to "On";

2) "TV Signal" to "NTSC";

3) "Widescreen" to "Off".

(See your iPod user’s manual for details.)

3Enjoy (iPod with video)

Notes:

– This DVD player only supports 30G, 60G and

80G iPod player with video.

– Please take out the tab marked “for 30G iPod” in

the dock if you want to dock a 60G or 80G iPod

player.

– You need to press 2; on your iPod player in

order to start photo playback through this DVD

player.

REMOVE

VIDEO

5Press the SOURCE key

repeatedly (or iPod on the

remote) for dock input.

6Play files in your iPod player.

●To r echarge your iPod player, you

must connect your DVD player to AC mains (or

the car cigarette lighter outlet) and ensure:

Your DVD player is in the power-off mode.

The DVD player is in the power-on mode and

the current source is “iPod”.

To r emove the iPod player

1Pull out the iPod connector.

2Lift up the handle marked 2/ EJECT to

SOURCE

CHGCHG

iPod

Music

Photos

Videos

Extras

Settings

Shuffle Songs

Videos

Video Playlists

Movies

Music Videos

Video Podcasts

Video Settings

Settings

TV Out On

TV Signal NTSC

Widescreen Off

DCP750/850 QSG-37.qxd 2007.3.5 14:47 Page 1

Connecting headphones (not

included)

●To enjoy your portable DVD player

without disturbing others, you can connect

one or more headphones to the n1or

(and) n2jack on the set.

Connecting an SD/MMC card

1Insert an SD/MMC card into the

SD/MMC CARD slot with the metal

contact facing down.

2On the DVD player panel, press the

source key repeatedly (or SD/MMC

CARD on the remote) to select the

SD/MMC source.

3Play video or audio files stored in the card

by selecting the desired file with 3 4 and

OK.

Connecting additional equipment

(TV for example)

1Connect the AV OUT socket on the set to

the video and audio sockets on a TV as

shown directly.

2Switch on the TV and set to the correct

video-in channel.

➜You can consult the owner's manual of

your TV. (If your TV does not have Audio

and Video inputs, you will need to

purchase a RF modulator. Please consult

your dealer.)

Note:

– When connecting a device to the AV IN socket

on the DVD player, you need to press the source

key repeatedly on the front panel (or AV on the

remote) to select AV IN (AUX).

White

Red

Yellow

White

Red

Yellow

OUT

AV OUT

AV IN

Headphone

SD/MMC

Printed in China WK652

Max.1800

1Open the lid of the player and adjust the

swivel screen clockwise to your preferred

viewing angle.

2Slide the POWER switch to ON to

switch on the DVD player.

➜The POWER indicator turns on.

3Press OPEN to open the disc door.

4Remove the protective card (if any) and

load a disc with the label side facing up.

5Close the disc door. Playback will start

automatically. If not, press 2;.

6To stop playback, press 9on the remote

control.

3Enjoy (Disc operation) 3Enjoy (Other options)

Note:

– Once the battery is running low (the power

indicator will flash as a prior warning),

immediately recharge it (regardless of whether

you plan to use the battery or not) in order to

maximize the battery life.

DCP750/850 QSG-37.qxd 2007.3.5 14:47 Page 2
