Quick start guide
CD181/CD186
Important safety instructions
Use only the power supply listed in the technical data.•
Do not allow the product to come into contact with liquids.•
Risk of explosion if battery is replaced by an incorrect type.•
Dispose of used batteries according to the instructions. (Refer to the user manual online)•
Overview
CD186
CD181
Loudspeaker
Find handsets.•
Register additional•
handsets.
Adjust the speaker volume.
Play the previous message.•
Replay the current message.•
Turn the answering machine on/off.
Skip to next message.
Delete the currrent messages.•
Delete all messages (press and hold).•
Start/stop listening to the recorded messages.
In call In idle mode In menu
MENU/OK Enter the option
menu
Enter the option
menu
Conrmselection
REDIAL/C Enter the redial list Enter the redial list Cancel operation
Increase the volume Enter the
phonebook
Scroll up
Decrease the
volume
Enter the call log Scroll down
Recall key*
*network dependent
Make and receive
calls
End calls Turn handset on/off
(press and hold)
Exit menu/operation
Mute/unmute the
microphone
Turn the speaker
on/off
Make and receive
calls
Speaker
Earpiece
Microphone
It displays the connection between
the handset and the base.The more
the bars are shown, the better the
connection is.
It indicates a received call in the call log.
It indicates an outgoing call in the
redial list.
Itasheswhenthereisanewmissed
call.
It remains steadily on when browsing
the missed calls in call log.
Itasheswhenreceivingincomingcall.
It remains steadily on during a call.
The speaker is on.
The ringer is off.
Answeringmachine:itasheswhen
there is a new message. It remains
steadily on when the telephone
answering machine is turned on.
If you are using a voice mailbox from
yourprovider,thisiconasheswhen
there is a new message.
It remains steadily on when the voice
messages are already viewed in the
call log.
The icon is not shown when there is
no voice message.
* This is network dependent
It displays when you scroll up/down
a list or increase and decrease the
volume.
There are more digits on the right.
Press REDIAL/C to read.
Connect the base station
Telephone
socket
Power
socket
Power
adapter
Power
socket
Extra
handset
charger
Telephone
base station
2 1 3
Connect each end of the power adapter to:1
the DC input jack at the bottom of the base station;•
the power socket on the wall.•
Connect each end of the line cord to:2
the telephone socket at the bottom of the base station;•
the telephone socket on the wall.•
For multi-handset version only:
Connect each end of the power adapter to:3
the DC input jack at the bottom of the extra handset charger.•
the power socket on the wall.•
1Connect
2Get started
Congure your phone
The batteries are pre-installed in the handset. Pull the battery tape off1
from the battery door before charging.
Whenusingyourphoneforthersttime,youseeawelcome2
message (country dependent).
After the welcome message, press MENU/OK.
Please set the country and language if prompted.3
Set the date and time.4
If the time is in 12-hour format, press• / key to select [AM] or
[PM].
Charge your phone
Charge 8 hours
Place the handset on the base station to charge the handset.When
the handset is placed correctly on the base station, you hear a docking
sound.
The handset starts charging.»
NoteChargethebatteriesfor8hoursbeforerstuse.
Check the battery level
When the handset is off the base station/charger, the bars
indicate the battery level (full, medium and low).
When the handset is on the base station/charger, the bars
ashuntilchargingcompletes.
Theemptybatteryiconashesandyouhearanalerttone.
The battery is low and needs recharging.
3Enjoy
Call
To make a call, press• and dial the
phone number.
To answer a call, press• when the
phone rings.
To end a call, press• .
Earpiece volume
Press or to adjust the volume
during a call.
Phonebook
Add record
Press1 MENU/OK, then select
[PHONEBOOK] > [ADD NEW],
then press MENU/OKtoconrm.
Enter the name, then press
2
MENU/OKtoconrm.
Enter the number, then press
3
MENU/OKtoconrm.
Call from the phonebook
Press1 or, press MENU/OK >
[PHONEBOOK] > [VIEW] to
access the phonebook list.
Select a contact.
2
Press3 to make the call.
Direct access memory
You have 2 direct access memories
(Keys 1 and 2).To dial the saved phone
number automatically, press and hold
on the keys in idle mode.
Depending on your country, Keys 1
and 2 are preset to [1_VOICEMAIL]
(voice mail number) and [2_INFO
SVC] (information service number)
of your network operator respectively
(network dependent).
Call log
Press1 and select a record.
To make a call
Press2 .
To view more details
Press2 MENU/OK.
Select
3 [VIEW].
To save a call record to the
phonebook
Press2 MENU/OK.
Select
3 [SAVE NUMBER].
Press
4 MENU/OKtoconrm.
Enter the name.
5
Press6 MENU/OKtoconrm.
Press
7 MENU/OK to save.
To delete a call record
Press2 MENU/OK.
Select
3
[DELETE]
or
[DELETE ALL]
.
Press4 MENU/OKtoconrm.
Redial list
Press1 REDIAL/C and select a record.
To make a call
Press2 .
To save a call record to the
phonebook
Press2 MENU/OK.
Select
3 [SAVE NUMBER].
Press
4 MENU/OKtoconrm.
Enter the name.
5
Press6 MENU/OKtoconrm.
Press
7 MENU/OK to save.
To delete a call record
Press2 MENU/OK.
Select
3 [DELETE] or [DELETE
ALL].
Press
4 MENU/OKtoconrm.
Record an
announcement
(for CD186 only)
Press1 MENU/OK > [ANSW
MACHINE] >
[ANNOUNCEMENT], then press
MENU/OKtoconrm.
Select
2 [ANSWER ONLY] or
[RECORD ALSO], then press
MENU/OKtoconrm.
Select
3 [RECORD NEW], then press
MENU/OKtoconrm.
Start recording close to the
4
microphone after the beep.
Press
5 MENU/OK to stop recording.
You can listen to the newly»
recorded announcement on the
handset.
Register the handsets
You can register additional handsets
to the base station.The base station
can register up to 4 handsets.
Press
1 MENU/OK on the
handset.
Select2 [SERVICES] >
[REGISTER], then press
MENU/OKtoconrm.
Press and hold3 on the base
station for 5 seconds.
Enter the system PIN (0000).
4
Press
5 MENU/OKtoconrm
the PIN.
Registration is completed in»
less than 2 minutes.
Restore default
settings
You can reset your phone settings
to the original factory settings.
Press
1 MENU/OK.
Select
2 [SERVICES] >
[RESET], then press
MENU/OKtoconrm.
The handset displays a»
conrmationrequest.
Press
3 MENU/OKtoconrm.
All settings are reset»
The welcome screen displays.»
Technical data
Battery
GP: PH50AAAHC: 2 x AAA NiMH 1.2V•
Rechargeable 500mAh batteries
BYD: H-AAA500A-Z: 2 x AAA NiMH•
1.2V Rechargeable 500mAh batteries
Adapter
Base and charger:
Philips:•
SSW-1920EU-2/SSW-1920UK-2/
S003PV0600050/S003PB0600050:
Input: 100-240V 50/60Hz 0.2A;
Output: 6V 500mA
