Philips SE1701B/51 Manual de usuario

Quick start guide

SE170/SE175

Note

*In multi-handset packs, there

are additional handsets,

chargers and power adapters.

** In some countries, you have

to connect the line adapter to

the line cord, then plug the line

cord to the telephone socket.

Caution

Use only the supplied batteries•

and power adapter.

What’s in the box

Handset*

Base station (SE175) Base station (SE170)

Charger*Power adapter*Line cord**

User manual

Quick start guide

Guarantee

Connect the base station

Telephone

socket

Power

socket

Power

adapter

Power

socket

Extra handset

charger

Telephone

base station

3 1 2

Connect each end of the power adapter to:

the DC input jack at the bottom of the base station;•

the power socket on the wall.•

Connect each end of the power adapter to (for multi-handset

packs):

the DC input jack at the bottom of the extra handset charger.•

the power socket on the wall.•

Connect each end of the line cord to:

the telephone socket at the bottom of the base station;•

the telephone socket on the wall.•

1Connect

2Install

Install the handset

Charge 16 hours

The batteries are pre-installed in the handset. Pull the battery

tape off from the battery door before charging.

Place the handset on the base station to charge the handset.

When the handset is placed correctly on the base station, you

hear the docking sound.

The handset starts charging.»

NoteChargethebatteriesfor16hoursbeforerstuse.

Congure your phone (if necessary)

When you see the welcome message, press

OK.

Select your country, press

OKtoconrm.

Set the date and time.

If the time is in 12-hour format, press»/ key to select

[AM]

[PM]

The phone is now ready to use.»

Check the battery level

When the handset is off the base station/charger, the

bars indicate the battery level (full, medium and low).

When the handset is on the base station/charger, the

bars keep scrolling until charging completes.

Theemptybatteryiconashesandyouhearanalert

tone.

The battery is low and needs recharging.

3Enjoy

Call

To make a call, press• and dial the phone number.

To answer a call, press• when the phone rings.

To end a call, press• .

Adjust the earpiece volume

Press or to adjust the volume during a call.

Add a contact in the phonebook

Press

MENU.

Select

2 [PHONEBOOK]

[NEW ENTRY]

, then

press OKtoconrm.

Enter the name then press

OKtoconrm.

Enter the number, then press

OKtoconrm.

Record an announcement

(for SE175 only)

Press

MENU.

Select

2 [ANSW MACHINE]

[ANNOUNCEMENT]

then press OKtoconrm.

Select

3 [ANSW.&RECORD]

[ANSWER ONLY]

then press OKtoconrm.

Select

4 [RECORD]

, then press OKtoconrm.

When

5 [RECORDING]

displays, start recording close

to the microphone.

Press

OK to stop recording.

You can listen to the newly recorded»

announcement on the handset.

Listen to messages recorded on the answering machine (for SE175 only)

Switch on/off the answering machine: Pressa .

Start/Stop listening to the recorded messages: Press

b 29.

Adjust the volume: Press

c + / –.

Skip backward:d

When you listen to the messages, press ¡to listen to the

message from the beginning.

Duringtherstsecondofthecurrentmessage,press¡ to listen

to the previous message.

Skip forward: Presse ™to skip to the next message.

Delete the current message: Pressf

Note For more information, see the Telephone answering machine

section in the user manual.

Need help?

User Manual

Refer to the user manual that came with your new phone.

Online help

www.philips.com/support

Welcome to Philips

Reproduction in whole or in part is prohibited

without the written consent of the copyright owner.

Trademarks are the property of Koninklijke Philips

Electronics N.V. or their respective owners.

Printed in China

QSG_SE170-175_05_EN_V3.4

WK9482

0168
