Philips Cucina HD7502 Instrucciones de montaje

Domestic Appliances and Personal Care

Published by Philips Domestic Appliances and Personal Care Printed in The Netherlands Copyright reserved Subject to modification

PRODUCT INFORMATION

Voltage

Frequency

Power consumption

HD 7502

Coloursetting

100, 120, 220-240V

50-60Hz

1000 watt

1200 cc On/Off switch

various

SERVICE INFORMATION

Thermostat

Thermal fuse

REPAIR INSTRUCTIONS

Electrical circuit

When the appliance does not work, check the electrical

circuit. If the thermal fuse or thermostat prove defective,

the complete pump unit has to be replaced.

De-scaling

If the water system is nearly or less clogged by scale

then operate the coffeemaker a few times with vinegar

or with a 10-15% solution of either vinegar-acid, citric

acid or tartar-acid, into cold tap water.

Do not use other de-scaling agents as these may harm

the appliance.

If this procedure does not restore the function, then switch

off the coffeemaker when the acid has passed through

during appr. 3 min. Keep the appliance in this condition

overnight and continue/repeat the cleaning operation.

After the de-scaling procedure, operate the coffeemaker

twice with tap water in order to rinse away any residual

substances.

: 140°C

: 228°C

switch-off temp

cut-off temp

Pump unit removal

To seperate the pump unit (item 16) from the hotplate

unit (item 13), the two plastic snaps at place A have to

be loosened. Then the pump unit can be lifted out easily.

Base removal

Besides two screws, two plastic snap connections have

to be detached by means of using a simple screwdriver,

as indicated on the base of the appliance.

HD 7502

MSH Coding

8827 502 00000

HD 7502/E

Coffeemaker ”Café Cucino”

99/10

4322 277 00063

PCS 101 549

Service Manual 4822 729 22072 is herewith cancelled.

Service

TWO SMALL

DETENT PIECES A

HD 7502/E

PCS 101 549

51 52

1 4822 442 01433 Tank lid yellow

- 4822 442 01432 ” ” ivory

2 4822 442 01437 Cover yellow

- 4222 247 58010 ” ivory

3 4822 442 01438 Spout aubergine

4 4822 462 40374 Stud

5 4822 256 10529 Filter with cap 1) yellow/aqua blue

- 4822 256 10531 ” ” 1) ivory/green

- 4222 259 33840 ” ” 1) ivory/ivory

6 4822 492 11676 Spring bracket

7 4822 276 13996 Switch 100-120V aqua blue

- 4822 276 13993 Switch 220-250V aqua blue

- 4822 276 13997 Switch 100-120V orange

- 4822 276 13994 Switch 220-250V orange

- 4822 246 25510 Switch 220-250V pearl blue

8 4822 360 10427 Drip stop unit aubergine

9 4822 360 10406 Drip stop unit aubergine

10 4822 442 01442 Jug lid blue

- 4822 442 01441 ” ” green

- 4222 247 58690 ” ” pearl blue

11 4822 418 10345 Jug 2) orange transp.

- 4822 418 10346 ” 2) blue transp.

- 4222 259 33810 ” 2) pearl blue

12 4822 462 11094 Jug buffer aqua blue

- 4822 441 12298 ” ” orange transp.

- 4222 247 58710 ” ” zinc brown

17 4822 492 71174 Wire spring

51 4222 247 06440 Hose piece

52 4222 259 20460 Valve + hose piece assy

53 4222 247 58680 Connection piece

54 4222 247 06800 Hose piece

55 4222 259 33950 Basic pump module III

56 4222 246 25640 Wire assy

57 4222 245 71630 Spring bpm III

58 4222 259 19960 Thermostat

59 4222 246 25650 Wire assy

60 4222 259 34210 Fuse assy

61 4222 240 06290 Leaf spring

62 4222 259 00751 Hotplate assy

63 4222 248 25620 Speednut

Notes:

1) Filter is changed in week 838. Look to the dripstop unit item 8 or 9.

Optional part for use as an insert in item 5:

4822 480 50479 Permanent filter nylon

4822 480 50402 Permanent filter gold coated

2) Commercial trade number: HD 7942 (jug included lid 10 aqua blue)

2) Commercial trade number: HD 7941 (jug included lid 10 green)

Commercial trade number: HD 7954 (jug included lid 10 pearl blue)

General: Not all colours have been listed;

customer has to make a selection.

If colours are no more avialable,

choose an other colour.

5. Replacing switch in HD 7502

6. Colour identification

- Firstly determine your type of appliance (Column A)

- Secondly determine the colourcode, which is printed on

the typeplate of the appliance:

HD 7502

/A /. /. is the colourcode

- Determine also the coloursetting of the jug handle

(Column B)

- In the next columns you can read the original coloursetting

of the other service parts.

A A1 B C D E F G H I

Type of Type Jug handle Jug lid Jug cap Housing Filterholder Tank lid Cover Switch

appliance (item 11) (item 10) (item 12) (item 3A) + (item 1) (item 2) (item 7)

colour- + Cap

code spring (item 5)

HD 7502 /3 Cucina orange green green ivory ivory/ ivory green orange

green transparant

HD 7502 /9 Cucina blue aqua blue aqua blue yellow yellow/ yellow yellow aqua blue

aqua blue transpar.

HD 7502 /6 pearl blue pearl blue pearl blue pearl blue ivory ivory/ivory ivory ivory pearl blue

PRESS

IN THIS

DIRECTION

MOVE THE

SWITCH IN

THIS DIRECTION

END

POSITION

PRESS

MID

POSITION

SWITCH HOLE IN

HOUSING PART

25MM.

HOUSING PART

SMALL

DETENT

PIECE A

START

POSITION

Service
