Philips AJL305 Manual de usuario

Clock Radio

AJL305

www.philips.com/welcome

User manual

AJL305_79_CCR.indd 1AJL305_79_CCR.indd 1 2008-01-25 9:43:51 AM2008-01-25 9:43:51 AM

DC IN 9V

ANT.

VOL

ALARM

CLOCK RADIO AJL305

CLOCK TUNER PHOTO

REC MIC

Design by Philips, Holland

RESET

AJL305_79_CCR.indd 2AJL305_79_CCR.indd 2 2008-01-25 9:43:59 AM2008-01-25 9:43:59 AM

English Controls / Power supply

Controls (See 1)

1Alarm

activates, or deactivates alarm

2REPEAT ALARM/BRIGHTNESS

CONTROL

repeats alarm in 9-minute interval

adjusts brightness of LCD display

3CLOCK

switches to clock mode

4TUNER

switches to tuner mode

5PHOTO

switches to photo mode

6Mini USB port

connects to a USB port on PC

7REC

switches to voice memo recording

8MIC

records voice memos

9VOL

adjusts volume level

0DC IN

socket for DC 9 V adapter

!Pigtail

FM antenna to improve reception

@RESET

press if the set does not react to

operation of any button

–

Power supply

1 Connect the supplied power adapter to the

set's DC IN 9V socket and to the power

socket.

2 Disconnect the power adapter if you want

to switch off the set completely.

Helpful hints:

To avoid damage to the set, use only the

adapter supplied!

The type plate is located on the rear of the set.

–

AJL305_79_CCR.indd 3AJL305_79_CCR.indd 3 2008-01-25 9:44:00 AM2008-01-25 9:44:00 AM

Environment Information

All unnecessary packaging material has

been omitted. The packaging can be easily

separated into three materials: cardboard,

polystyrene and plastic.

Your set consists of materials which

can be recycled if disassembled by a

specialized company. Please observe the

local regulations regarding the disposal of

packaging, dead batteries and old equipment.

Disposal of your old product

Your product is designed and

manufactured with high quality

materials and components, which

can be recycled and reused.

When this crossed-out wheeled

bin symbol is attached to a

product it means the product is covered

by the European Directive 2002/96/EC.

Please inform yourself about the local

separate collection system for electrical and

electronic products.

Please act according to your local rules and

do not dispose of your old products with

your normal household waste. The correct

disposal of your old product will help

prevent potential negative consequences for

the environment and human health.

Congratulations on your purchase and

welcome to Philips!

To fully beneﬁt from the support that

Philips offers, register your product at

www.philips.com/welcome

Supplied accessory

1 X certiﬁed power adapter (Model: DSA-

9W-09 FAU 090100 Input: 100-240V

~50/60Hz 0.3A, Output: +9V 1A)

Restoring the set

You can restore factory settings if the set

does not react to any operation or you want

to restore all settings.

Reset

Press and hold RESET with a ballpoint or

other thin sticks.

Master reset

Press and hold PHOTO and TUNER at

the same time and press and hold RESET

with a ballpoint or other thin sticks.

Besides restoring settings, master reset

deletes all preset radio stations, photos, and

voice memos.

You can use master reset to delete

everything easily.

–

General Information

AJL305_79_CCR.indd 4AJL305_79_CCR.indd 4 2008-01-25 9:44:01 AM2008-01-25 9:44:01 AM

Setup - Clock

In clock mode, you can set clock time, alarm

time, auto dim, and slideshow, make the set

automatically scan FM stations, and view

memory status in the setup menu.

Setting Clock

Setting time

1Press CLOCK.

2Press SETUP to enter setup menu.

3Press SELECT.

The set enters clock setup mode.

4Press SELECT.

The set enters time setup mode.

5Press HOUR+ or UP, DOWN repeatedly

or hold them until the desired hour is

displayed.

6Press MIN+ or UP, DOWN repeatedly

or hold them until the desired minute is

displayed.

7Press BACK to exit setting.

The set returns to clock setup mode.

Helpful hints:

You can enter time setting quickly by pressing

and holding CLOCK on the set.

➜

–

Setting date

1Press DOWN to highlight Set Date.

The set enters date setup mode.

2Press SELECT.

3Press DAY+, or DOWN repeatedly or

hold them until the desired day is displayed.

4Press MONTH+, or DOWN repeatedly

or hold them until the desired month is

displayed.

5Press YEAR+ or DOWN repeatedly or

hold them until the desired year is displayed.

6Press BACK to exit setting.

Setting 12/24 format

1Press DOWN to highlight 12/24 Format.

2Press SELECT.

3Press UP or DOWN to select 12H or 24H.

4Press SELECT to save setting and exit

➜

AJL305_79_CCR.indd 5AJL305_79_CCR.indd 5 2008-01-25 9:44:02 AM2008-01-25 9:44:02 AM

Setting Alarm

You can set the alarm time and select the

alarm sound between Tuner and Buzzer.

1Press CLOCK.

2Press SETUP.

Set Alarm is highlighted.

3Press SELECT.

The set enters alarm setup mode.

4Press DOWN to highlight Alarm Time.

5Press SELECT.

The set enters alarm setup mode.

6Press HOUR+ or UP, DOWN repeatedly

or hold them until the desired hour is

displayed.

7Press MIN+, or UP, DOWN repeatedly

or hold them until the desired minute is

displayed.

8Press BACK to exit alarm time setup.

9Press DOWN to highlight Wake to….

10 Press SELECT.

Tuner and Buzzer are displayed on the

second display.

11 Press UP or DOWN repeatedly or hold

them to select the desired alarm sound.

12 Press SELECT to save setting and exit.

Helpful hints:

You can enter alarm setting quickly by pressing

and holding ALARM on the set.

➜

–

Setting radio tuner

1Press CLOCK.

2Press SETUP.

3Press DOWN repeatedly to highlight Radio

Tuner.

4Press SELECT.

The set automatically scans FM stations

and stores up to 15 preset stations.

5Press BACK to stop scanning.

➜

Setup - Alarm Setup-Tuner

AJL305_79_CCR.indd 6AJL305_79_CCR.indd 6 2008-01-25 9:44:02 AM2008-01-25 9:44:02 AM

Setup-Slideshow Setup - Auto Brightness

Setting Slideshow

You can toggle slideshow on or off, and set

the frequency of slideshow.

1Press UP or DOWN repeatedly to

highlight Slideshow.

2Press SELECT.

The set enters slideshow setup mode.

On/Off is highlighted.

3Press SELECT.

On, Off are displayed on the second

display.

4Press UP or DOWN repeatedly to switch

slideshow on or off.

5Press BACK to return.

6Press DOWN to highlight Frequency.

7Press SELECT.

8Press UP or DOWN to switch between

the following intervals:

5 sec->30 sec->1 min->10 min->30 min.

9Press BACK to exit setting.

➜

Setting Auto Brightness

The set can automatically dim at the start

time and light up at the end time.

1Press CLOCK.

2Press SETUP.

3Press DOWN repeatedly to highlight Auto

Brightness.

4Press SELECT.

5Press SELECT.

6Press UP or DOWN repeatedly to switch

Auto Brightness function on or off.

7Press BACK to return.

8Press DOWN repeatedly to highlight

Timer Settings.

9Press SELECT.

10 Press or hold HOUR+ below the second

display or DOWN to select the desired

start time.

11 Press or hold HOUR+ below the second

display or DOWN to select the desired end

time.

12 Press BACK to exit setting.

Helpful hints:

You can set the timer to start at night and end

in the morning so that AJL305 automatically

dims at night and lights up in the morning.

–

AJL305_79_CCR.indd 7AJL305_79_CCR.indd 7 2008-01-25 9:44:03 AM2008-01-25 9:44:03 AM

Setup-Clock Display/Memory Status Clock/Alarm

Setup-Clock Display

You can set whether to display clock or not

in photo mode.

1 Press CLOCK.

2 Press SETUP.

3 Press UP or DOWN repeatedly to

highlight Clock Display.

4 Press SELECT.

5 Press UP or DOWN to select ON or

OFF.

6 Press SELECT to save setting and exit.

Viewing Memory Status

You can check the occupied memory and

how much capacity is left.

1Press CLOCK.

2Press SETUP.

3Press DOWN repeatedly to highlight

Memory Status.

The memory occupation status of photo

and voice memo is displayed respectively.

4Press UP to enter other settings.

5Press BACK to exit setting.

Helpful hints:

During setting the set, if no button is pressed

within 10 seconds, the set returns to SETUP

mode automatically.

➜

–

Displaying clock

1Press CLOCK.

To activate or deactivate

alarm

1Press ALARM repeatedly.

is displayed when alarm is activated.

disappears when alarm is deactivated.

Repeating alarm

You can repeat the alarm call at 9-minute

intervals.

During the alarm call, press REPEAT

ALARM / BRIGHTNESS CONTROL.

ﬂashes.

Helpful hints:

During alarm call, if no button is pressed, alarm

call will last 30 minutes.

Note:

For instructions on setting the clock and alarm,

please refer to chapter Setup - Clock and

Setup - Alarm.

➜

–

AJL305_79_CCR.indd 8AJL305_79_CCR.indd 8 2008-01-25 9:44:04 AM2008-01-25 9:44:04 AM

Tuner

Tuning to radio station

1Press TUNER to switch on radio (FM only).

2Press and hold , for about 2 seconds,

then release.

The radio automatically tunes to a station

of sufﬁcient reception.

3Repeat step 2 if necessary until you ﬁnd the

desired station.

To tune to a weak station, press ,

brieﬂy and repeatedly until you have found

optimal reception.

Manual programming radio

stations

You can store up to a total of 15 FM radio

stations in the memory manually.

1Press MANUAL TUNE.

2Tune to your desired station (See “Tuning

to radio station”).

3Press PRESET+ or PRESET- once or

more to allocate a number from 1 to 15.

4Press SAVE to conﬁrm.

5Repeat step 2-4 to store other stations.

Note:

You can erase a preset station by storing

another frequency in its place.

➜

•

–

To listen to a preset or preset

station

Press PRESET+ or PRESET- once or

more until the desired preset station is

displayed.

To pause radio

Press TUNER.

OFF is displayed.

Helpful hints:

To improve FM reception:

Extend and adjust the pigtail for optimum

reception.

•

➜

–

AJL305_79_CCR.indd 9AJL305_79_CCR.indd 9 2008-01-25 9:44:05 AM2008-01-25 9:44:05 AM

Photo Voice Memo

Manual browsing

To browse all photos in albums

Press the button below a certain person’s

album.

Slide show

The set can display all photos automatically

at a set frequency.

1Switch slide show on.

2Set a desired time interval between slides.

For slide show setting, please refer to

chapter Setup - Slideshow.

Recording messages

1Press PHOTO or REC.

Photos are displayed.

2Press SELECT button below one to ﬁve

displays to select or deselect users to whom

you want to leave a message.

3Press REC again.

Recording begins.

4Speak near the MIC.

5Press REC to end recording.

•

➜

Helpful hints:

1Each message can last up to 20 seconds.

2After you ﬁnish recording, the set switches

to PHOTO mode automatically.

3is displayed in the photo and indicates

the number of messages left to the user.

Playing and deleting messages

To listen to a message

1Press the button below the photo with .

Playback starts automatically from the

ﬁrst message.

To listen to a message again

1Press UP or DOWN to move the cursor

to the desired message.

2Press REPLAY.

To delete a message

1Press UP or DOWN to move the cursor

to the desired message.

2Press DELETE.

3Press OK to conﬁrm.

4Press BACK to return.

➜

AJL305_79_CCR.indd 10AJL305_79_CCR.indd 10 2008-01-25 9:44:06 AM2008-01-25 9:44:06 AM

Otros manuales para AJL305

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Radio reloj de Philips

Philips

Philips AJ3340/00 Manual de usuario

Philips

Philips AJ3225 Manual de usuario

Philips

Philips AJB4700 Manual de usuario

Philips

Philips DCB242 Manual de usuario

Philips

Philips AJ 3010 Manual de usuario

Philips

Philips AJ 3740 Manual de usuario

Philips

Philips DC200/93 Manual de usuario

Philips

Philips AJL305 Manual de usuario

Philips

Philips AJ3925 - Cd Clock Radio Manual de usuario

Philips

Philips 3000 series Manual de usuario

Philips

Philips AJ3925 - Cd Clock Radio Manual de usuario

Philips

Philips AJ3400/79 Manual de usuario

Philips

Philips AJ100/12 Manual de usuario

Philips

Philips CLOCK/TIMER AJ1000 Manual de usuario

Philips

Philips AJL308 Manual de usuario

Philips

Philips AJT5300 Manual de usuario

Philips

Philips AJ3115 Manual de usuario

Philips

Philips AJ3012 Manual de usuario

Philips

Philips AJ3231 Manual de usuario

Philips

Philips AJ3925 - Cd Clock Radio Manual de usuario

Philips

Philips AJ3970 Manual de usuario

Philips

Philips AJ3132/00 Manual de usuario

Philips

Philips AJ 3140 FAMILY Manual de usuario

Philips

Philips AJ3138/12 Manual de usuario

Manuales populares de Radio reloj de otras marcas

Denver

Denver CRQ-105 Manual de usuario

Audiovox

Audiovox CE90 Manual de usuario

Sony

Sony Dream Machine ICF-C763L Manual de usuario

Sanyo

Sanyo DMP-P6 Manual de usuario

RCA

RCA RPC100 Manual de usuario

Yamaha

Yamaha ISX-80 Manual de usuario

Pyle

Pyle PLMR20W Manual de usuario

Blaupunkt

Blaupunkt CR7BK Manual de usuario

HoMedics

HoMedics SS-5500-2EU Manual de usuario

RCA

RCA RC66i Manual de usuario

Versaudio

Versaudio Vers Manual de usuario

SOUNDMASTER

SOUNDMASTER UR8100 Manual de usuario

Audiovox

Audiovox CE90 Manual de usuario

Jensen Audio

Jensen Audio JCR-222 - AM/FM Projection Alarm Clock Radio Manual de usuario

Roberts

Roberts ChronoDAB Manual de usuario

AEG

AEG MRC 4132 BT Manual de usuario

Tokai

Tokai TC-155 Manual de usuario

Timex

Timex T300 Manual de usuario
