Philips AJB3552/12 Manual de usuario

AJB3552

www.philips.com/welcome

EN User manual

English

7 Product information 16

Specications 16

8 Troubleshooting 17

9 Notice 18

Recycling 18

Contents

1 Important 4

2 Your DAB+ clock radio 5

Introduction 5

What’s in the box 5

Overview of the main unit 6

3 Get started 8

Prepare FM/DAB+ antenna 8

Connect power 8

Set clock 8

Turn radio on/off 8

4 Listen to Digital Audio Broadcasts

(DAB+) 9

Tune to DAB+ radio stations 9

Store DAB+ radio stations automatically 9

Store DAB+ radio stations manually 9

Search for DAB+ radio station manually 9

Listen to a preset DAB+ radio station 10

Show DAB+ information 10

Remove invalid DAB+ station 10

Select DRC setting 10

5 Listen to FM radio 11

Tune to FM radio stations 11

Store FM radio stations automatically 11

Store FM radio stations manually 11

Listen to a preset FM radio station 11

Display RDS information 11

Select FM radio searching scope 11

6 Other features 12

Adjust system settings 12

Set date and time format 12

Select backlight settings 12

Update software (if available) 13

Set alarm timer 13

Set the sleep timer 14

Enhance bass 15

1 Important

The apparatus shall not be exposed •

to dripping or splashing.

Do not place any sources of danger •

on the apparatus (e.g. liquid lled

objects, lighted candles).

Never insert objects into the •

ventilation slots or other openings on

the apparatus.

Protect the power cord from being •

walked on or pinched, particularly at

plugs, convenience receptacles, and

the point where they exit from the

apparatus.

Unplug this apparatus during lightning •

storms or when unused for long

periods of time.

Refer all servicing to qualied service •

personnel. Servicing is required

when the apparatus has been

damaged in any way, such as power-

supply cord or plug is damaged,

liquid has been spilled or objects

have fallen into the apparatus, the

apparatus has been exposed to

rain or moisture, does not operate

normally, or has been dropped.

Where the plug of the Direct Plug-in •

Adapter is used as the disconnect

device, the disconnect device shall

remain readily operable.

English

2 Your DAB+

clock radio

Congratulations on your purchase, and

welcome to Philips! To fully benet from the

support that Philips offers, register your product

at www.philips.com/welcome.

Introduction

With this unit, you can:

listen to FM or DAB+ (Digital Audio •

Broadcasting) radio

know the time•

be waken up by DAB+/FM radio or •

buzzer alarm.

The unit offers Dynamic Bass Boost (DBB) to

enrich sound.

What’s in the box

Check and identify the contents of your

package:

Main unit•

Power adaptor•

User manual•

Overview of the main unit

English

oAUTOSCAN

Scan radio stations.•

Store favorite radio stations in •

memory.

pDC IN

Connect power.•

qFOR SOFTWARE UPDATE ONLY

Update software via USB connector •

(if available).

aBACK

Return to previous menu. •

Cancel a selection. •

bINFO/MENU

Access DAB+/FM menu.•

Display DAB+/RDS information. •

cDBB

Turn on/off dynamic bass •

enhancement.

dSLEEP

Set sleep timer.•

Navigate through the DAB+/FM •

menu.

Select a preset radio station.•

Scan for previous/next radio station. •

fDisplay panel

Show status.•

gLight sensor

For backlight brightness adjustment.•

hMINUTE/VOLUME

Set minute.•

Adjust volume.•

iHOUR/TUNING +/-

Set hour.•

Tune to a radio station.•

jSET ALARM/CLOCK/SET TIME

Set alarm/time.•

Switch to clock screen. •

k REPEATALARM•SELECT

Repeat alarm.•

Conrm selection.•

lALARM ON/OFF

Turn on/off alarm timer.•

mRADIO ON/OFF

Turn on/off radio.•

nSOURCE

Select DAB+/FM source. •

Set clock

1 In standby mode, rotate SET ALARM/

CLOCK/SET TIME to the SET TIME

position.

The hour and minute digits begin to »

blink.

2 Rotate HOUR to set the hour.

3 Rotate MINUTE to set the minute.

4 Rotate the SET ALARM/CLOCK/SET

TIME to the CLOCK position to conrm.

Turn radio on/off

In standby mode, press RADIO ON/OFF to

turn on the radio.

The last listened DAB+ or FM station »

broadcasts automatically.

Tip

You can also turn on the radio by pressing •

SOURCE repeatedly.

To turn off the radio, press

•RADIO ON/OFF

again.

3 Get started

If you contact Philips, you will be asked for the

model and serial number of this apparatus. The

model number and serial number are on the

bottom of the apparatus. Write the numbers

here:

Model No. __________________________

Serial No. ___________________________

Prepare FM/DAB+ antenna

For better reception, fully extend and adjust the

position of the FM/DAB+ antenna.

Note

To prevent interference, position the antenna •

as far as possible from TV, VCR, or other

radiation source.

Connect power

Caution

Risk of product damage! Ensure that the power •

voltage corresponds to the voltage printed on

the back or underside of the apparatus.

Risk of electric shock! When you unplug the

•

AC adaptor, always pull the plug from the

socket. Never pull the cord.

Before connecting the AC adaptor, ensure that

•

you have completed all other connections.

Note

The type plate is located on the bottom of the •

main unit.

English

Store DAB+ radio stations

automatically

Tip

New stations and services will be added in •

the DAB+ broadcast. To make new DAB+

stations and services available, perform full

scan regularly.

In DAB+ mode, press and hold AUTO SCAN

for 3 seconds.

The unit scans all the available DAB+ »

radio stations and broadcasts the rst

available station.

Store DAB+ radio stations

manually

You can store up to 20 DAB+ radio stations in

preset channel.

1 Tune to a DAB+ radio station.

2 Press AUTO SCAN.

The preset channel number is »

displayed.

3 Press / repeatedly to select a

number: 1- 20.

4 Press SELECT to conrm.

5 Repeat steps 1-4 to store other stations.

Note

To remove a pre-stored DAB+ radio station, •

store another station in its place.

Search for DAB+ radio

station manually

1 In DAB+ mode, press and hold MENU

for 3 seconds.

2 Press / to select [Manual tune],

then press SELECT.

3 Rotate TUNING +/- to navigate DAB+

radio frequency.

4 Listen to

Digital Audio

Broadcasts

(DAB+)

Digital Audio Broadcasting (DAB+) is a way

of broadcasting radio digitally through a

network of transmitters. It provides you with

more choice, better sound quality, and more

information.

Tune to DAB+ radio stations

Note

Make sure that the antenna is fulled extended.•

1 Press SOURCE repeatedly to select DAB

mode.

»[FULL SCAN] (full scan) is displayed.

2 Press SELECT to start full scan.

The unit stores all the available DAB+ »

radio stations and then broadcasts the

rst available station.

The station list is memorized in the »

unit. When you turn on the unit next

time, the station scan does not take

place.

If no DAB+ service is available, »[No

DAB Station] (no DAB+ station)

appears, then [FULL SCAN] (full scan)

is displayed.

To tune to a station from the available station

list:

1 In DAB+ mode, rotate TUNING +/- to

navigate the available DAB+ stations.

2 Press SELECT to conrm.

Select DRC setting

While listening to DAB+ radio, you can change

DRC (Dynamic Range Control) settings to add/

remove a degree of compensation for audio

performance.

1 In DAB+ mode, press and hold MENU

for over 3 seconds.

2 Press / until [DRC] is displayed.

3 Press SELECT to conrm.

4 Press / repeatedly to select an

option:

• [DRC off]: DRC is switched off.

• [DRC high]: DRC is switched on.

Recommend using this setting in

noisy environment.

• [DRC low]: DRC is set to half

normal level.

5 Press SELECT to conrm the selection.

4 Press SELECT to conrm.

Searching starts.»

5 When searching is complete, press

SELECT again to start playing.

Listen to a preset DAB+

radio station

1 Press / to select a preset DAB+

radio channel.

2 Press SELECT to conrm.

Show DAB+ information

While listening to DAB+ radio, press INFO

repeatedly to scroll through the following

information (if available):

Dynamic Label Segment (DLS)»

Signal strength»

Program type (PTY)»

Ensemble Name»

Channel and frequency»

Signal error rate»

Bit rate and audio status»

Date»

Remove invalid DAB+ station

You can remove all invalid stations from the

available DAB+ station list.

1 In DAB+ mode, press and hold MENU

for 3 seconds.

2 Press / repeatedly until [Prune] is

displayed.

3 Press SELECT to conrm.

»[No][Yes] is displayed.

4 Press / to select [Yes].

5 Press SELECT.

All invalid stations are removed.»

English

Note

To remove a pre-stored FM radio station, •

store another station in its place.

Listen to a preset FM radio

station

Press / to select a preset number.

The station starts broadcast in a few »

seconds.

Display RDS information

Radio Data System (RDS) is a service that

sends additional broadcast information along

with FM stations. If you listen to an FM station

with RDS signal, “RDS” is displayed.

Press INFO/MENU to display RDS information

such as PTY (program type) and station name.

Select FM radio searching

scope

Before you start to search for FM radio stations,

you can select searching scope.

1 Press INFO/MENU for over 3 seconds.

2 Press or until [Scan setting] is

displayed, then press SELECT.

3 Press or to select an option:

• [Strong stations only]: Only stations

with strong signals can be searched.

• [All stations]: Stations with both

strong and weak signals can be

searched.

4 Press SELECT to conrm.

5 Listen to FM

radio

Tune to FM radio stations

Tip

Position the antenna as far as possible from •

TV, VCR, or other radiation source.

For optimal reception, fully extend and adjust

•

the position of the antenna.

1 Press SOURCE repeatedly to select FM

tuner.

2 Press and hold or .

The radio tunes to a station with »

strong reception automatically.

To tune to a weak station, rotate »

TUNING +/- until you nd optimal

reception.

Store FM radio stations

automatically

1 In FM radio mode, press and hold AUTO

SCAN for 3 seconds.

Up to 20 FM stations with strong signal »

are stored in channel 1 - 20.

The station stored in channel 1 starts »

broadcasting.

Store FM radio stations

manually

1 Tune to an FM radio station.

2 Press AUTO SCAN.

The preset channel number is »

displayed.

3 Press / to select a channel: 1-20.

4 Press SELECT.

The selected FM radio station is saved »

in the channel.

5 Repeat steps 1-4 to store other stations.

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Radio reloj de Philips

Philips

Philips AJ130 Manual de usuario

Philips

Philips AJL308 Manual de usuario

Philips

Philips AJL308/17 Manual de usuario

Philips

Philips AJ6200D/12 Hoja de información del producto

Philips

Philips AJ260/93 Manual de usuario

Philips

Philips AJ 3710 Manual de usuario

Philips

Philips 3000 series Manual de usuario

Philips

Philips AJ3220 Manual de usuario

Philips

Philips AJ3915 Manual de usuario

Philips

Philips AJ3320/00 Manual de usuario

Philips

Philips AJ3540/05 Manual de usuario

Philips

Philips AJ3275D Manual de usuario

Philips

Philips R7606 Manual de usuario

Philips

Philips AJ3080 Manual de usuario

Philips

Philips AJ3123/02 Manual de usuario

Philips

Philips AJ2000/05 Manual de usuario

Philips

Philips DC6210 Manual de usuario

Philips

Philips AJ3940 - annexe 2 Manual de usuario

Philips

Philips AJ3226/93 Manual de usuario

Philips

Philips AJ34901798 Manual de usuario

Philips

Philips J3540 Manual de usuario

Philips

Philips AJ1000B Manual de usuario

Philips

Philips AJ3000/14 Manual de usuario

Philips

Philips AJ3122 Manual de usuario

Manuales populares de Radio reloj de otras marcas

Denver

Denver CRQ-105 Manual de usuario

Audiovox

Audiovox CE90 Manual de usuario

Sony

Sony Dream Machine ICF-C763L Manual de usuario

Sanyo

Sanyo DMP-P6 Manual de usuario

RCA

RCA RPC100 Manual de usuario

Yamaha

Yamaha ISX-80 Manual de usuario

Pyle

Pyle PLMR20W Manual de usuario

Blaupunkt

Blaupunkt CR7BK Manual de usuario

HoMedics

HoMedics SS-5500-2EU Manual de usuario

RCA

RCA RC66i Manual de usuario

Versaudio

Versaudio Vers Manual de usuario

SOUNDMASTER

SOUNDMASTER UR8100 Manual de usuario

Audiovox

Audiovox CE90 Manual de usuario

Jensen Audio

Jensen Audio JCR-222 - AM/FM Projection Alarm Clock Radio Manual de usuario

Roberts

Roberts ChronoDAB Manual de usuario

AEG

AEG MRC 4132 BT Manual de usuario

Tokai

Tokai TC-155 Manual de usuario

Timex

Timex T300 Manual de usuario
