Philips AJ3226/93 Manual de usuario

EN User manual

ZH-CN 用户手册

MHz

KHz

x10

ALARM 2

ALARM 1

SLEEP

UP DOWN

ALARM RESET

REP

•SLEEP OFF•

EA T ALARM

CLOCK

SETAL 1

SET AL2

SETTIME

AL 1

OFF

BUZZ

RADIO

TUNING

BAND

VOL

AUX

RADIO

OFF

CLOCK RADIO AJ 3226

AL 2

OFF

BUZZ

RADIO

Congratulations on your purchase, and welcome to Philips!

To fully benet from the support that Philips offers, register your

product at www.philips.com/welcome.

Controls (see g. 1)

aSLEEP

• activates the radio for sleep function

• adjusts the sleep period

bClock control

• SET TIME: sets the clock time

• SET AL 1: sets the alarm time for alarm 1

• SET AL 2: sets the alarm time for alarm 2

• CLOCK: to run on clock time

cUP / DOWN

• adjusts the hours/ minutes for the clock and alarm times

dREPEAT ALARM / SLEEP OFF

• switches off the active alarm for a 6-7 minute period

• switches off the sleep function

eFrequency indicator

• shows the radio frequency of your selected waveband

fTUNING

• tunes to radio stations

gBAND

• select FM/MW waveband

hVOLUME

• adjusts the sound level

iALARM RESET

• stops the active alarm for 24 hours

jDISPL AY

• show the clock/ alarm times and status of the set

k OFF • RADIO • AUX

• switches off the set or selects the radio/AUX mode.

l AL 1, AL 2

• OFF switches off the alarm 1 or alarm 2

• RADIO activates the radio for alarm 1 or alarm 2

• BUZZ activates the buzzer for alarm 1 or alarm 2

mBattery door

• opens to store a 9 volt 6F22 type battery (not included) for

clock memory backup

nMains lead

• for AC mains supply

o Pigtail aerial

• improves FM reception

p AUX

• connects external audio source.

Installation

Power supply

1Check if the mains supply, as shown on the type plate located

on the bottom of the set, corresponds to your local mains

supply. If it does not, consult your dealer or service centre.

2Connect the mains lead to the wall socket.

3To disconnect the set from the mains supply completely,

remove the plug from the wall socket.

Note

•The type plate is located on the bottom of the set.

Clock memory backup

The clock memory backup allows your alarm and clock time settings

to be stored for up to a day when there is a power interruption e.g.

mains failure. The complete clock radio and display illumination will

be switched off. As soon as the mains supply returns, the display will

indicate the correct time.

1Remove the battery door to insert a 9 volt 6F22 type battery

(not included) for backup.

2Replace the battery door.

Note

•If no backup battery is installed or the power interruption is

prolonged, you will need to set the clock and alarm times again.

•Batteries contain chemical substances so should be disposed of

properly.

Radio

You can use this set solely as a radio!

1Adjust OFF • RADIO • AUX to RADIO to switch on the radio.

2Select your waveband by adjusting the BAND switch.

3Adjust TUNING to tune to your desired station.

4Turn the VOLUME control to adjust the volume level.

5Adjust OFF • RADIO • AUX to OFF to switch off the radio.

To improve reception:

FM: extend and position the pigtail for optimum reception.

MW: uses a built-in aerial inside the set. Direct the aerial by adjusting

the position of your set.

Setting the clock and alarm time

The time is displayed using the 24-hour clock

Note

•To adjust the clock and alarm times accurately, always make sure you

press UP / DOWN separately and not simultaneously.

1Turn the clock control to SET TIME or SET AL 1 or SET AL 2

to set the clock or alarm time respectively.

2Press UP/DOWN repeatedly or hold down on the respective

button to adjust the hours and minutes.

3Release UP/DOWN when you reach the correct setting.

4After you have set both the hour and minutes, turn the clock

control to CLOCK to run on clock time.

Selecting the alarm mode

GENERAL

If you wish to use the alarm, you must rst set the alarm time rst.

You can choose from two different alarm modes to wake you up: by

radio or buzzer.

• Select your choice of alarm mode by adjusting AL 1 or AL 2 to

RADIO or BUZZ.

»The buzzers are at a set volume and cannot be adjusted. BUZZ

on AL 1 is a low tone buzzer while BUZZ on AL 2 is a high

tone.

Switching off the alarm

There are three ways of switching off the alarm. Unless you cancel

the alarm completely, the 24 hour alarm reset option will be

automatically selected after 59 minutes, from the time your alarm

time rst goes off.

24 HOUR ALARM RESET

If you want the alarm mode to be stopped immediately but also wish

to retain the same alarm setting for the following day:

• Press ALARM RESET during the alarm call.

Canceling the alarm completely

To cancel the set alarm time before it goes off, or during the alarm

call:

• Adjust AL 1 or AL 2 to OFF position.

Repeat alarm

This repeats your alarm call at 6-7-minute intervals.

1During the alarm call, press REPEAT ALARM/SLEEP OFF.

SLEEP

About Sleep

This set has a built-in timer which enables the set to be automatically

switched off during radio playback after a set period of time. This

allows you to lie back, listen and fall asleep. The maximum sleep time

is 59 minutes.

Setting SLEEP

1Check that the clock control is in CLOCK position.

2Set OFF • RADIO • AUX to OFF position.

3To set the sleep function, do one of the following:

• Press and hold SLEEP.

»The display will begin to count down from 0:59 to 0:00

minutes.

• Hold down SLEEP, and press UP/DOWN repeatedly to adjust

sleep time from 59 minutes downward.

»To cancel sleep, press REPEAT ALARM/SLEEP OFF.

Connecting an external device

You can listen to your favorite music of the connected external

device through your AJ3226’s speakers.

1Adjust OFF • RADIO • AUX to select AUX.

2Connect the AUX-IN cable of the set to an AUDIO OUT or

headphone jack on an external device (such as MP3 player, or

CD player).

Safety information

• Install the unit near the AC outlet and where the AC plug can be

easily reached.

• Where the MAINS plug is used as the disconnect device, the

disconnect device shall remain readily operable.

• Place the set on a hard and at surface so that the system does

not tilt.

• If you do not intend to use the set for a long time, withdraw the

power plug from the wall outlet. In addition to this, it is advisable

to remove the battery from the clock radio. This will prevent any

danger of leakage and the clock radio will not be damaged.

• Do not expose the set, batteries to humidity, rain, sand or

excessive heat caused by heating equipment or direct sunlight.

• The apparatus shall not be exposed to dripping or splashing.

• Adequate ventilation with a minimum gap of 15cm between

the ventilation holes and surrounding surfaces is necessary to

prevent heat build-up.

• The ventilation should not be impeded by covering the

ventilation openings with items, such as newspapers, table-

cloths, curtains, etc..

• No objects lled with liquids, such as vases, shall be placed on

the apparatus.

• No naked ame sources, such as lighted candles, should be

placed on the apparatus.

• To clean the set, use a soft, slightly dampened chamois leather.

Do not use any cleaning agents containing alcohol, ammonia,

benzene or abrasives as these may harm the housing.

• Battery shall not be exposed to excessive heat such as sunshine,

re or the like.

Caution

•Use of controls or adjustments or performance of procedures other

than herein may result in unsafe operation.

Troubleshooting

If a fault occurs, rst check the points listed below before taking the

set for repair.

If you are unable to remedy a problem by following these hints,

consult your dealer or service center.

Warning

•Under no circumstances should you try to repair the set yourself, as

this will invalidate the warranty. Do not open the set as there is a risk

of electric shock.

Problem

– Possible Cause

• Remedy

No sound/power

– Volume not adjusted

• Adjust the volume

Occasional crackling sound during FM broadcast

– Weak signal

• Adjust the position of the Pigtail
