Philips AJ3112/37 Manual de usuario

Clock Radio

www.philips.com/welcome

AJ3112/37

AJ3112_37_UM_EN 4/16/10 15:55 Page 1

#%^ $

678

AJ3112_37_UM_EN 4/16/10 15:55 Page 2

AJ3112_37_UM_EN 4/16/10 15:55 Page 3

AJ3112_37_UM_EN 4/16/10 15:55 Page 4

IMPORTANT SAFETY INSTRUCTIONS

Class II equipment symbol

This symbol indicates that the unit has

a double insulation system

Clean only with dry cloth.

Where the MAINS plug or an appliance

coupler is used as the disconnet device,

the disconnet device shall remain

readily operable.

materials

AJ3112_37_UM_EN 4/16/10 15:55 Page 5

Notice of compliance

The set complies with the FCC-Rules, Part 15 and with RSS-210 of

Industry Canada. Operation is subject to the following two conditions:

1.This device may not cause harmful interference, and

2.This device must accept any interference received, including interfer-

ence that may cause undesired operation.

English

CONTROLS (see fig. 1 )

1DISPLAY - shows the clock/ alarm time and status of the set

2ALARM indicator -

lights up when alarm is activated

3Frequency indicator - shows the radio frequency of your selected waveband

4REPEAT ALARM /

SLEEP

OFF

- switches off the active alarm for a 8-9 minute period

- switches off the sleep function

5CLOCK - sets the clock time

6SLEEP

- activates the radio for sleep function

- adjusts the sleep period

7ALARM RESET - stops the active alarm for 12 hours

8ALARM - sets the alarm function

Congratulations on your purchase and welcome to Philips!

To fully benefit from the support that Philips offers, register your

product at www.philips.com/welcome.

AJ3112_37_UM_EN 4/16/10 15:55 Page 6

9RADIO / ALARM

RADIO ON: switches on the radio

RADIO OFF: switches off the radio/alarm

ALARM - RADIO: activates the radio for alarm

ALARM - BUZ: activates the buzzer for alarm

0SET TIME HR / MIN

- adjusts the hours / minutes for clock / alarm / sleep time

!Power cord -

connects to wall outlet

@Pigtail - improve FM reception

#VOLUME - adjusts the sound level

$Battery door - opens to store a 9 volts 6F22 battery (not included) for clock

memory backup.

%FM/AM (MW) - selects FM/AM (MW) waveband

^TUNING - tunes to radio stations

Specifications

AC Power........................................................120 V / 60 Hz

Power Consumption

Active.......................................................................... 5 W

Standby.................................................................... 2.8 W

Dimensions (w x d x h)...............130.4 x 130 x 46.8 (mm)

.............................................................5.1 x 5.1 x 1.8 (inch)

Weight............................................0.395 kg / 0.87 pounds

AJ3112_37_UM_EN 4/16/10 15:55 Page 7

INSTALLATION

POWER SUPPLY

Check if the power supply, as shown on the type plate located on the bot-

tom of the set, corresponds to your local power supply. If it does not, consult

your dealer or service center.

Connect the plug to the wall outlet.

To disconnect the set from the power supply completely, remove the

plug from the wall outlet.

For users in the U.K.: please follow the instructions on the lower left

handed corner of the sheet.

CLOCK MEMORY BACKUP

The clock memory backup allows your alarm and clock time settings to be stored

for up to a day when there is a power interruption e.g. power failure. The com-

plete clock radio and display illumination will be switched off. As soon as the

power supply returns, the display will indicate the correct time.

Remove the battery door to insert a 9 volts 6F22 type battery (not included)

for backup.

Replace the battery door.

NOTE:

If no backup battery is installed or the power interruption is prolonged,

you will need to set the clock and alarm times again.

Batteries contain chemical substances so they should be disposed of

properly.

Perchlorate Material - special handling may apply. See

www.dtsc.ca.gov/hazardouswaste/perchlorate.

AJ3112_37_UM_EN 4/16/10 15:55 Page 8

RADIO

You can use this set solely as a radio!

Adjust

RADIO / ALARM

RADIO ON

to switch on the radio.

Select your waveband by adjusting the

FM/AM (MW)

switch

Adjust TUNING to tune to your desired station

Turn the VOLUME control to adjust the volume level

Adjust

RADIO / ALARM

to OFF to switch off the radio.

To improve reception:

FM:

Extend and position the pigtail fully to obtain optimal reception.

AM (MW):

uses a built-in antenna inside the set. Direct the antenna

by adjusting the position of your set

SETTING THE CLOCK / ALARM TIME

The time is displayed using the 12-hour clock.

Hold down CLOCK or ALARM.

Press

MIN

repeatedly, or hold down

MIN

to adjust minute

and/or hour.

Release CLOCK or ALARM and

MIN

when you reach the correct setting.

™The set clock time will show on the display and start to run.

SELECTING THE ALARM MODE

To use the alarm, you must set the alarm time first. You can choose from two dif-

ferent alarm modes to wake you up: by radio or buzzer.

Select your choice of alarm mode by adjusting

RADIO / ALARM

RADIO

BUZ

™

The alarm indicator (AL) will light up.

AJ3112_37_UM_EN 4/16/10 15:55 Page 9

Helpful Hint:

•

If you have selected the radio mode, make sure you have adjusted the vol-

ume loud enough to wake you.

•

The buzzer is set at a fixed volume and cannot be adjusted.

SWITCHING OFF THE ALARM

There are three ways of switching off the alarm. Unless you cancel the alarm

completely, the 12 hour alarm reset option will be automatically selected after

1 hour and 59 minutes, from the time your alarm time first goes off.

12 HOUR ALARM RESET

If you want the alarm mode to be stopped immediately but also wish to retain

the same alarm setting for the following day:

•

Press ALARM RESET during the alarm call.

™

The alarm indicator (AL) will remain on.

CANCELING THE ALARM COMPLETELY

To cancel the set alarm time before it goes off, or during the alarm call:

•

Adjust

RADIO / ALARM

to OFF position.

™

The alarm indicator (AL) will light off.

REPEAT ALARM

This repeats your alarm call at 9-minute intervals.

During the alarm call, press REPEAT ALARM

SLEEP

OFF

™

The alarm indicator (AL) will remain on.

AJ3112_37_UM_EN 4/16/10 15:55 Page 10
