Philips SE735 Manual de usuario

3%?)&5?%.BOOK0AGE&RIDAY$ECEMBER0-

8VHUPDQXDO

ΣΕ435_ΙΦΥ_ΕΝ.βοοκ Παγε 3 Φριδαψ, ∆εχεµβερ 16, 2005 1:15 ΠΜ

4 Important Information

4 For your safety

4 Installation requirements

4 Need Help?

5 What’s in the box?

6YourSE735

6 Overview of the handset

9 Overview of the base station

10 Main features of your SE735

12 Connect

13 Install

17 USB Connection

21 Call

26 Phonebook

31 Call log

33 SMS

41 Clock & Alarm

43 Personal Settings

49 Advanced Settings

55 Network Services

58 Games

59 Telephone Answering Machine (TAM)

66 Troubleshooting

69 Information

70 Index

Contents

EN Important Information

For your safety

This equipment is not designed to make emergency calls in the event of a power failure. Alternative

arrangements should be made for access to emergency calls.

To avoid damage or malfunction:

- Do not allow the product to come into contact with liquid.

- Do not open it as you could be exposed to high voltages.

- Never use any battery type other than the one supplied.

- Do not hold the handset too close to your ear when the phone is ringing or when activating the

loudspeaker as it may damage your hearing.

- Do not expose the phone to excessive heat caused by heating equipment or direct sunlight.

- Do not drop your phone or allow objects to fall on your phone.

- Do not use any cleaning agents containing alcohol, ammonia, benzene, or abrasives as these may harm the set.

- Active mobile phones in the vicinity may cause interference.

About operating and storage temperatures

- Operate in a place where temperature is always between 0 and 35º C (32 to 95º F).

- Store in a place where temperature is always between -20 and 45º C (-4 to 113º F).

- Battery life may be shortened in low temperature conditions.

Installation requirements

This product requires an electrical supply of 220-240 volts, alternating monophased power, excluding IT

installations defined in standard EN 60-950. In case of power failure, the communication can be lost.

The electrical network is classified as hazardous according to criteria in the standard EN 60-950. The only way

to power down this product is to unplug the power supply unit from the electrical outlet. Ensure the electrical

outlet is located close to the apparatus and is always easily accessible.

The voltage on the network is classified as TNV-3 (Telecommunication Network Voltages), as defined in the

standard EN 60-950.

Need Help?

For more information on troubleshooting:

Troubleshooting: page 66

Please refer to the following website for more information on Philips web support:

Online Support

www.philips.com/support

What’s in the box?

The following accessories are included with your SE735:

Power supply for

base station

Belt clip Battery door

Line cord

User Guide

Warranty card

The line adaptor may not be attached to the line cord. In this case, you have to connect the line adaptor

to the line cord first before plugging the line cord to the line socket.

In multihandset packs, you will find one or more additional handsets, chargers with power supply units

and additional rechargeable batteries.

Handset Base station

Quick Start

Guide

2 AAA

rechargeable

batteries

Installation CD

Headset USB cable

EN Your SE735

Overview of the handset

headset

jack

LCD Screen

Left Soft key

Talk key

Keypad lock

key

Up/Down Navigation keys

Earpiece

Right Soft key

Hang-up key

Alphanumeric keypad

Case key / Pause key /

Ringer off key

Intercom key

Loudspeaker

key

Microphone

Event LED

USB socketUSB socket

Your SE735

Handset keys

Soft key

Press To

mEnter the main menu from stand-by mode.

Select the function displayed on the handset screen directly above it.

Activate mute function during a call.

Switch on the backlight.

>Go to redial list from stand-by mode.

Select the function displayed on the handset screen directly above it.

Initiate a second call, call transfer or consult the phonebook during a call.

Switch on the backlight.

rAnswer an incoming external or internal call.

Insert R for operator services when on the line.

eHang up a call.

Return to stand-by mode.

Long press in stand-by mode to switch off the handset, short press to switch on the

handset again.

uAccess call log from stand-by mode.

Scroll up a menu list or go to the previous phonebook or call log record.

Increase earpiece volume during a call.

Go to the previous character in editing mode.

dAccess phonebook from stand-by mode.

Scroll down a menu list or go to the next phonebook or call log record.

Decrease earpiece volume during a call.

Go to the next character in editing mode.

cInitiate an internal call.

vAnswer an incoming call in handsfree mode.

Activate and deactivate the loudspeaker* during a call.

#Dial # in stand-by mode.

Long press to mute the ringer in stand-by mode.

Long press to insert a pause in dialling mode.

Long press to switch between upper and lower case in editing mode.

*Dial * in stand-by mode.

Long press to activate and deactivate keypad lock.

BACK Short press from menu browsing to return to the previous menu.

*WARNING Handsfree activation can suddenly increase the volume in the earpiece to a very high

level. Make sure the handset is not too close to your ear.

(Right soft key)

(Left soft key)

EN Your SE735

Display icons & symbols

In stand-by mode, several icons & symbols may be displayed on the handset.

When there are new events, such as new missed calls, new SMS, voicemail or answering machine messages

received, the following icons, together with the number of occurrences are displayed in the middle of the

handset screen.

The handset is registered and within range of the base station. It blinks when the handset is

out of range or is searching for a base.

Battery symbol indicating 3 different battery levels.

The ringer volume is set to zero.

The keypad is locked.

There is an external incoming call, an external call is connected or an external call is held.

There is an internal incoming call, an internal call is connected or an internal call is held.

The loudspeaker is ON.

Alarm clock is activated.

SMS reception is activated. It blinks when the memory for SMS is full.

Telephone answering machine (TAM) is activated. It blinks when the memory for answer-

ing machine messages is full.

Do not Disturb mode is activated.

There are new SMS messages received. The number of new SMS messages received is

also displayed on the left of the icon.

There are new missed calls. The number of new missed calls is also displayed on the left of

the icon.

There are new voicemail messages received. The number of new voicemail messages

received is also displayed on the left of the icon.

There are new answering machine messages received. The number of new messages

received is also displayed on the left of the icon.

If you have not subscribed to Caller Line Identification service, there will not be any alerts for the

new events except for new messages recorded on the answering machine. Hence, no missed call,

SMS, or voicemail event icons will appear in the middle of the handset screen.

Your SE735

Overview of the base station

Base station keys

cPage handset.

Long press to start registration procedure.

oShort press to turn the answering machine On/Off.

vIncrease speaker volume during message playback.

Reduce speaker volume during message playback.

xDelete current message during message playback.

Long press to delete all messages when TAM is in stand-by mode

(unread messages will not be deleted).

pPlay phone messages (the first recorded will be played first).

Stop message playback.

lGo to previous message if pressed within 1 second of current

message playback.

Replay current message if pressed after 1 second of current

message playback.

rSkip to the next message during message playback.

Paging key

Volume keys

Time

Message number

Delete key

Next message key

SIM card tray

Answer Machine

On/Off key

Previous message/

Replay message key

Play/Stop key

EN Your SE735

Main features of your SE735

The following is an overview of the menu options that are available in your SE735. For detailed explanation of

the menu options, please refer to the corresponding sections in this User Guide.

LCD Message counter Displays current time when the answering machine is switched off

or in stand-by mode.

Displays date & time of recording and message number during

playback.

Blinking: Indicates number of new messages.

Steady: Indicates number of old messages.

2 bars flashing: Indicates that there is no more memory left.

Indicates the volume level (L0 - L9) when vis pressed.

Indicates the current message number during playback.

Menu To Page

SMS Setup, write/read SMS, etc. 33

PHONEBOOK Add, edit, manage phonebook entries and copy phonebook

entries from SIM card.

CLOCK &

ALARM

Set date and time, alarm, alarm tone and Do not Disturb

mode.

PERSONAL SET Set Handset tone, Wallpaper, View Foto Pic, Contrast, Handset

name, Auto Pick-up/Hang-up, Languages, Babysit mode,

Backlight time and Theme Colour.

ADVANCED

SET

Set Recall time, Dial mode, Call barring, Baby call mode,

phone, Auto prefix, Conference mode and Demo mode.

NET. SERVICE Set Call forwarding, Voice mail, Call back and Caller ID. 55

GAMES Play games 58

ANSWER

MACHINE

Setup, play, delete phone messages, record memo, etc. 59
