EN Quick Start Guide

www.philips.com/welcome

183 mm

53.5mm

5mm

English

Install the car audio

These instructions are for a typical installation.

However, if your car has different requirements,

make the corresponding adjustment. If you have

any questions regarding installation kits, consult

your Philips car audio dealer.

Connect wires 1

1Pull out the ISO connectors from the car

dashboard and connect them to the bigger

end of the supplied standard connector. a

2Connect the other end of supplied

standard connector to the unit. b

If necessary, connect the following:• c

Connector Connect to/with

1 Blue cable Sub woofer out

2 Green/white

wire

Parking (see ‘Connect

parking brake wire’ on

page 16) switch (see

‘Connect parking brake

wire’)

3 White cable Left front line out

4 Red cable Right front line out

5 White cable Left rear line out

6 Red cable Right rear line out

7 Pink wire Camera

8 Yellow cable Camera in

9 Yellow cable Video in

10 Yellow cable Video out 2

11 Yellow cable Video out 1

12 White cable Left audio in

13 Red cable Right audio in

Mount in the dashboard 2

1If the car does not have an on-board drive

or navigation computer, disconnect the

negative terminal of the car attery.

2Ensure that car dashboard opening is within

these measurements: a

3Remove the two transport screws on the

top of the unit. b

4Remove the mounting sleeve with the

removal keys. c

5Install the sleeve into the dashboard and

bendthetabsoutwardtoxthesleeve. d

6Place the rubber cushion over the end of

the bolt. e

7Slide the unit into the dashboard until a

click sound is heard. f

8Reconnect the negative terminal of the car

battery.

Turn on

1Press to turn on the unit.

The available OSD (On-Screen Display)»

languages display.

2Touch a language to select.

The OSD language changes to the»

selected language immediately.

To turn off the unit, press and hold• for

more than 2 seconds.

Set clock

1Touch to display main menu.

2Touch [Setting] to display setting menu.

3Touch [Time].

4Touch [Clock Mode] to switch between

clock mode options.

5Touch [Set Time].

6Touch / to adjust each setting.

7Touch toexittimesettingmenu.

Listen to Radio

1Touch to display main menu.

2Touch [Radio].

3Touch [FM] repeatedly at the right-lower

corner to switch among the band options.

4Touch / to tune to a radio station

manually.

To tune to a radio station automatically,•

touch and hold / more than 1 second.

Play disc 3

You can play video, audio or images stored on the

following discs:

DVD video, DVD-R, DVD-RW•

VCD•

Audio CD, CD-R, CD-RW•

1Press to open the front panel.

2Insert the disc into the disc slot with label

side facing up.

3Close the front panel.

To remove the disc, press the• button.

Play USB device 4

1Slide the USB socket cover to the left.

2Insert the USB device into the USB socket.

Remove the USB device

1Press to turn off the unit.

2Remove the USB device.

Insert SDHC card 5

1Press to open the front panel.

2Insert the SDHC card into the card slot.

The unit starts playing from the SDHC»

card automatically.

Remove the SDHC card

1Press to turn off the unit.

2Press the card until you hear a click sound.

The card is now disengaged.»

3Remove the card.

Play with Bluetooth device

Pair the Bluetooth-enabled devices

ThersttimeyouconnectyourBuetoothdevice

to the unit, you need to pair the device to the

unit. Pairing needs only to be done once.You can

pair up to eight devices.

1Turn on the Bluetooth function on your

device.

2Search for Bluetooth device with your

device.

3Select “CED370” in the pairing list.

4Enter default password “0000”.

Make a call

1Pair the phone with the unit.

2Touch > [Media] > [BT] to access phone

call menu.

3Touch /to navigate through the options

under this menu.

4Touch on an option to access all the calls or

numbers under this option.

5Touch on a call.

• Or touch to enter number directly, then

touch green to dial.

Receive call

By default, all incoming calls are received

automatically.

1If there is incoming call, [Incoming call...]

ashesonthescreen.Speakintothe

Bluetooth microphone.

2When conversation ends, touch (red)

to terminate the call.
