Philips SE658 Manual de usuario

SE658

Quick start guide

1Connect

2Install

3Enjoy

www.philips.com/welcome

What’s in the box

Handset with belt clip Base station Battery door

Bracket for wall

mounting

2 AAA rechargeable

batteries

Power supply Line cord

User manual Guarantee Do Not Return

leaflet

Quick Start Guide

In multihandset packs, you will find one or more additional handsets, battery doors,

chargers with power supply units and additional rechargeable batteries.

WARNING: Always use the line cord, power supply and batteries that came with your

phone.

1Connect

Connect the base station

2Install

Insert rechargeable batteries and charge

1. Place the base station in a central location near the telephone line socket and

electricity socket.

2. Connect the line cord and the power cable to their corresponding connectors at the

back of the base station.

3. Connect the other end of the line cord and power cable to their respective sockets.

Insert batteries Charge handset for 24 hours

3Enjoy

Make a call

Dial the number (maximum 24 digits) and press tor l.

Press tor lto take the line, and dial the number.

Answer a call

When the phone rings, press tor l.

End a call

To end a conversation, press h.

Adjust earpiece or speaker volume

During a call, scroll nto select from level 1 to level 5.

The descriptions above are available from the handset. With this model, making and

answering a call are also available from the base station. Refer to chapter 6 “Conventions

Used in this manual” and chapter 8 “Using your phone” in the User Manual that came

with this phone for details.

Note

Setting the ring tones

Follow the procedure below to set ring tones on the handset or base station.

1. Press min idle mode, scroll nto Personal Set, and press oSelect.

2. Scroll nto Handset Tones on the handset or Base Tones on the base and press

oSelect. Then scroll nto Ring Tones and press oSelect.

3. Scroll nto your desired melody. The melodies will play as you scroll them.

4. Press oSelect to set the ring tone.

• A validation tone is emitted and the screen returns to the previous menu.

Refer to the key chart in Chapter 6 “Conventions Used in this Manual” of the User

Manual for base station keys that correspond to the handset keys appearing in the

procedure above.

Note

Store a contact in the phonebook

1. Press m. Phonebook is highlighted; press oSelect.

2. New Entry is highlighted; press oSelect.

3. Enter Name is displayed. Enter the name of the contact (maximum 14 characters)

and press oOK.

4. Enter Number is displayed. Enter the number (maximum 24 digits) and press

oOK.

• A validation tone is emitted.

Access phonebook

1. Press dand scroll nto browse the phonebook.

2. To view the details, press oView.

Call from the phonebook

1. Press din idle mode.

2. Scroll nto a phonebook entry.

3. Press tor l.

• The call is initiated.

The descriptions above are available from the handset. With this model, using the

phonebook is also available from the base station. Refer to chapter 6 “Conventions Used

in this Manual” and chapter 10 “Using your Phonebook” in the User Manual that came

with this phone for details.

Note

Listen to messages recorded on the answering machine

Press eto turn on the answering machine (the information display is turned on). The

outgoing message is played.

Press pto play phone messages (the first recorded message will be played first).

Press cSkip to skip the current message and play the next message.

Press cPrev. to go back to the previous message (if pressed within 1 second of

current message playback).

Press cPrev. to replay current message (if pressed after 1 second of current message

playback).

Press -or +to adjust speaker volume during message playback.

Press xto delete the current message.

Long press xto delete all old messages.

Press eagain to turn off the answering machine (the information display is turned off).

Refer to your SE658 User Manual for details about the answering machine functions.

Welcome to Philips!

www.philips.com/welcome

Need help?

User Manual

Refer to the User Manual that came with your SE658.

Online Help

www.philips.com/support

Troubleshooting

For more information, please refer to the User Manual that came with your phone.

Problem

• There’s no dialling tone!

Solution

• No power: Check the connections.

• Batteries are empty: Charge the batteries.

• Move closer to the base station.

• Wrong line cord used: Use the line cord provided.

• Caller does not hear me

clearly!

• Move closer to the base station.

• Move the base station at least one metre (yard) away

from any electronic appliances.

•Searching... is displayed

on handset and icon is

blinking!

• Move closer to the base station.

• Make sure that your base station is on.

• Reset your unit and restart handset registration.

• Caller number is not

displayed!

• Service is not activated: Check your subscription

with your network operator.

3111 285 47091 (US-EN)

UCZZ69939UZ(0)

Reproduction in whole or in part is prohibited without

the written consent of the copyright owner
