DATA SHEET

Product speciﬁcation

Supersedes data of 1998 Apr 28

File under Integrated Circuits, IC01

2002 Jan 17

INTEGRATED CIRCUITS

TDA1517; TDA1517P

2×6 W stereo power amplifier

2002 Jan 17 2

Philips Semiconductors Product speciﬁcation

2×6 W stereo power ampliﬁer TDA1517; TDA1517P

FEATURES

•Requires very few external components

•High output power

•Fixed gain

•Good ripple rejection

•Mute/standby switch

•AC and DC short-circuit safe to ground and VP

•Thermally protected

•Reverse polarity safe

•Capability to handle high energy on outputs (VP=0V)

•No switch-on/switch-off plop

•Electrostatic discharge protection.

GENERAL DESCRIPTION

The TDA1517 is an integrated class-B dual output

amplifier in a plastic single in-line medium power package

with fin (SIL9MPF) and a plastic heat-dissipating dual

in-line package (HDIP18). The device is primarily

developed for multi-media applications.

QUICK REFERENCE DATA

ORDERING INFORMATION

SYMBOL PARAMETER CONDITIONS MIN. TYP. MAX. UNIT

VPsupply voltage 6.0 14.4 18.0 V

IORM repetitive peak output current −−2.5 A

Iq(tot) total quiescent current −40 80 mA

Isb standby current −0.1 100 µA

Isw switch-on current −−40 µA

|ZI|input impedance 50 −−kΩ

ooutput power RL=4Ω; THD = 0.5% −5−W

RL=4Ω; THD = 10% −6−W

SVRR supply voltage ripple rejection fi= 100 Hz to 10 kHz 48 −−dB

αcs channel separation 40 −−dB

Gvclosed loop voltage gain 19 20 21 dB

Vno(rms) noise output voltage (RMS value) −50 −µV

ccrystal temperature −−150 °C

TYPE

NUMBER PACKAGE

NAME DESCRIPTION VERSION

TDA1517 SIL9MPF plastic single in-line medium power package with ﬁn; 9 leads SOT110-1

TDA1517P HDIP18 plastic heat-dissipating dual in-line package; 18 leads SOT398-1

2002 Jan 17 3

Philips Semiconductors Product speciﬁcation

2×6 W stereo power ampliﬁer TDA1517; TDA1517P

BLOCK DIAGRAM

Fig.1 Block diagram.

handbook, full pagewidth

mute/stand-by

switch input

MLC351

output 1

15 kΩ

x 1

stand-by

switch

mute

switch

stand-by

reference

voltage

18 kΩ

kΩ

mute switch Cm

power stage

mute switch

kΩ

power stage

275

SGND

signal

ground

PGND

output 2

non-inverting

input 1

non-inverting

input 2 9

supply voltage

ripple rejection

output

TDA1517

mute

reference

voltage

input

reference

voltage

power

ground

(substrate)

2002 Jan 17 4

Philips Semiconductors Product speciﬁcation

2×6 W stereo power ampliﬁer TDA1517; TDA1517P

PINNING

SYMBOL PIN DESCRIPTION

−INV1 1 non-inverting input 1

SGND 2 signal ground

SVRR 3 supply voltage ripple rejection output

OUT1 4 output 1

PGND 5 power ground

OUT2 6 output 2

VP7 supply voltage

M/SS 8 mute/standby switch input

−INV2 9 non-inverting input 2

Fig.2 Pin configuration for SOT110-1.

dbook, halfpage

MLC352

OUT2

SGND

INV1

INV2

TDA1517

OUT1

M/SS

SVRR

PGND

Fig.3 Pin configuration for SOT398-1.

Pins 10 to 18 should be connected to GND or floating.

dbook, halfpage

MLC353

OUT2

SGND

INV1

INV2

TDA1517P

OUT1

M/SS

SVRR

PGND

FUNCTIONAL DESCRIPTION

The TDA1517 contains two identical amplifiers with

differential input stages. The gain of each amplifier is fixed

at 20 dB. A special feature of the device is the

mute/standby switch which has the following features:

•Low standby current (<100 µA)

•Low mute/standby switching current

(low cost supply switch)

•Mute condition.

2002 Jan 17 5

Philips Semiconductors Product speciﬁcation

2×6 W stereo power ampliﬁer TDA1517; TDA1517P

LIMITING VALUES

In accordance with the Absolute Maximum Rating System (IEC 60134).

THERMAL RESISTANCE

SYMBOL PARAMETER CONDITIONS MIN. MAX. UNIT

VPsupply voltage operating −18 V

no signal −20 V

VP(sc) AC and DC short-circuit safe voltage −18 V

VP(r) reverse polarity −6V

ERGOenergy handling capability at outputs VP=0V −200 mJ

IOSM non-repetitive peak output current −4A

ORM repetitive peak output current −2.5 A

Ptot total power dissipation see Fig.4 −15 W

Tstg storage temperature −55 +150 °C

Tamb operating ambient temperature −40 +85 °C

Tccrystal temperature −150 °C

SYMBOL TYPE NUMBER PARAMETER VALUE UNIT

Rth j-c TDA1517 thermal resistance from junction to case 8 K/W

Rth j-p TDA1517P thermal resistance from junction to pins 15 K/W

Rth j-a TDA1517; TDA1517P thermal resistance from junction to ambient 50 K/W

Fig.4 Power derating curve.

(1) Rth j-c = 8 K/W.

(2) Rth j-p = 15 K/W.

handbook, halfpage

25 0 50 150

MLC354

100

T ( C)

amb

(W)

(1)

(2)

2002 Jan 17 6

Philips Semiconductors Product speciﬁcation

2×6 W stereo power ampliﬁer TDA1517; TDA1517P

DC CHARACTERISTICS

VP= 14.4 V; Tamb =25°C; measured in Fig.6; unless otherwise speciﬁed.

Note

1. The circuit is DC adjusted at VP= 6 to 18 V and AC operating at VP= 8.5 to 18 V.

SYMBOL PARAMETER CONDITIONS MIN. TYP. MAX. UNIT

Supply

VPsupply voltage note 1 6.0 14.4 18.0 V

Iq(tot) total quiescent current −40 80 mA

VODC output voltage −6.95 −V

Mute/standby switch

V8switch-on voltage level see Fig.5 8.5 −−V

Mute condition

VOoutput signal in mute position VI(max) =1V;f

i=20Hzto15kHz −−2mV

Standby condition

Isb DC current in standby condition −−100 µA

Vsw switch-on current −12 40 µA

2002 Jan 17 7

Philips Semiconductors Product speciﬁcation

2×6 W stereo power ampliﬁer TDA1517; TDA1517P

AC CHARACTERISTICS

VP= 14.4 V; RL=4Ω; f = 1 kHz; Tamb =25°C; measured in Fig.6; unless otherwise speciﬁed.

Notes

1. Output power is measured directly at the output pins of the IC.

2. Frequency response externally fixed.

3. Ripple rejection measured at the output with a source impedance of 0 Ω, maximum ripple amplitude of 2 V (p-p) and

a frequency between 100 Hz and 10 kHz.

4. Noise voltage measured in a bandwidth of 20 Hz to 20 kHz.

5. Noise output voltage independent of Rs(VI= 0 V).

SYMBOL PARAMETER CONDITIONS MIN. TYP. MAX. UNIT

Pooutput power THD = 0.5%; note 1 4 5 −W

THD = 10%; note 1 5.5 6.0 −W

THD total harmonic distortion Po=1W −0.1 −%

flr low frequency roll-off at −3 dB; note 2 −45 −Hz

fhr high frequency roll-off at −1dB 20 −−kHz

Gvclosed loop voltage gain 19 20 21 dB

SVRR supply voltage ripple rejection note 3

on 48 −−dB

mute 48 −−dB

standby 80 −−dB

|Zi|input impedance 50 60 75 kΩ

Vno noise output voltage

on Rs=0Ω; note 4 −50 −µV

on Rs=10Ω; note 4 −70 100 µV

mute note 5 −50 −µV

cs channel separation Rs=10Ω40 −−dB

|∆Gv|channel unbalance −0.1 1 dB

2002 Jan 17 8

Philips Semiconductors Product speciﬁcation

2×6 W stereo power ampliﬁer TDA1517; TDA1517P

Fig.5 Standby, mute and on conditions.

handbook, halfpage

8.5

MLC355

6.4

3.3

(V)

,,,,,,,

,,,,,

,,,,,,,

ON (I = 40 mA)

mute (I = 40 mA)

standby (I 100 µA)

APPLICATION INFORMATION

Fig.6 Application circuit diagram.

handbook, full pagewidth

MLC356

100 nF

TDA1517

standby switch

220 nF

input 1

1000 µF 1000 µF

input

reference

voltage

2 5

signal

ground power

ground

1 9 220 nF input 2

2200

µF

internal

1/2 VP

100

µF

60 kΩ60 kΩ20 dB 20 dB

2002 Jan 17 9

Philips Semiconductors Product speciﬁcation

2×6 W stereo power ampliﬁer TDA1517; TDA1517P

PACKAGE OUTLINES

UNIT AA

max.

2A3b1D1

bcD

(1) E(1) Z

max.

(1)

eLPP

REFERENCES

OUTLINE

VERSION EUROPEAN

PROJECTION ISSUE DATE

IEC JEDEC EIAJ

mm 18.5

17.8 3.7 8.7

8.0

15.8

15.4 1.40

1.14 0.67

0.50 1.40

1.14 0.48

0.38 21.8

21.4 21.4

20.7 6.48

6.20 3.4

3.2

2.54 1.0

5.9

5.7

4.4

4.2

3.9

3.4 15.1

14.9

1.75

1.55

DIMENSIONS (mm are the original dimensions)

Note

1. Plastic or metal protrusions of 0.25 mm maximum per side are not included.

2.75

2.50

SOT110-1 92-11-17

95-02-25

0 5 10 mm

scale

0.25

q1q2

seating plane

pin 1 index

SIL9MPF: plastic single in-line medium power package with fin; 9 leads SOT110-1

2002 Jan 17 10

Philips Semiconductors Product speciﬁcation

2×6 W stereo power ampliﬁer TDA1517; TDA1517P

UNIT A

max. 12 b

1(1) (1) (1)

b2cD E e M Z

REFERENCES

OUTLINE

VERSION EUROPEAN

PROJECTION ISSUE DATE

IEC JEDEC EIAJ

DIMENSIONS (inch dimensions are derived from the original mm dimensions)

SOT398-1 94-04-13

95-01-25

min. A

max. bmax.

1.40

1.14 0.67

0.50 0.47

0.38 21.85

21.35 6.5

6.2 3.9

3.1 0.252.54 7.62 8.32

8.02 8.7

7.7 1.04.7 0.51 3.7

inches 0.06

0.04 0.03

0.02 0.02

0.01

1.05

0.75

0.04

0.03 0.87

0.84 0.26

0.24 0.15

0.12 0.010.10 0.30 0.33

0.32 0.34

0.30 0.040.19 0.02 0.15

(e )

seating plane

pin 1 index

0 5 10 mm

scale

Note

1. Plastic or metal protrusions of 0.25 mm maximum per side are not included.

HDIP18: plastic heat-dissipating dual in-line package; 18 leads SOT398-1
