Phanteks AMP GH Series Manual de usuario

INSTALLATION GUIDE SUPPORTS

PH-P650GH_01

PH-P750GH_01

PH-P850GH_01

PH-P1000GH_01

PH-P1200GH_01

PH-P1300GH_01

SUPPORT

US & Canada

[email protected]

International

[email protected]

SOCIAL MEDIA

Instagram

Phanteks

Facebook

Phanteks

YouTube

Phanteks

Twitter

@phanteks

Cable Type Connectors per Cable Length per Cable (mm)

Motherboard 24-PIN 1 610

CPU EPS 4+4-PIN 1 650

PCIe 6+2-PIN 1 750

12VHPWR 12+4-PIN 1 720

SATA 4 450 -150 |150 |150

SATA |Molex 2 |2 450 -150 |150 |150

C13 Power Cable 1 1500

Accessories Included

User Manual

Installation Guide

PSU Bag

Cable Bag

Ziptie Bag

Screw Pack

CPU

4+4-PIN

SATA |MOLEX

C13 POWER CABLE

SATA

PCIe

6+2-PIN

12VHPWR

12+4-PIN

ACCESSORIES INCLUDED

CABLES INCLUDED

POWER SUPPLY

AMP GH

MANUAL

WARRANTY CABLE BAG

SCREW PACKZIP TIE BAG

MOTHERBOARD

24-PIN

* The amount of cables may vary depending on model.

INSTALL PSU INTO CHASSIS

01 CONNECT CABLES TO PSU

INSTALLATION GUIDE

Secure the power supply with the 4x included PSU screws. Check the PC

chassis manual for more installation details.

Connect all needed cables to the power supply according to the overview

below. The exact connector lay-out and quantity may be different depending

on the model.

* Connectors may vary depending on model.

* The amount of cables may vary depending on model.

12VHPWR GPU CONNECTOR

CONNECT POWER CABLE

HYBRID FAN MODE

BE SAFE!

CONNECT CABLES TO SYSTEM COMPONENTS

The AMP GH is equipped with the 12VHPWR PCIe Gen5 GPU connector and

cable. Note that a compatible GPU is required.

The maximum power output depends on your AMP GH model:

Connect the power cable to the power supply and a

grounded power outlet respectively. Make sure the power

supply is turned off ‘O’ before connecting it to a power outlet.

Use the Hybrid Fan Mode to unlock the 0RPM fan speed when under 30%

load. This will make the power supply absolutely silent under low load and

temperature levels.

Hybrid Fan Mode is turned on when the button is pressed in, and off when

pressed again.

Switch the power button to the ‘I’ position to turn on your system.

When making any changes to the hardware, be sure that the power button

is switched from the ‘I’ to the ‘O’ position so the power supply is turned off.

Only use Phanteks cables that are provided with the power supply. If there

are any questions, please don’t hesitate to visit www.phanteks.com/FAQ for

more details.

Phanteks will not take responsibility for any damages incurred due to incorrect installation or usage

of this product.

Connect all power cables to the corresponding system components, please

follow the manufacturers instructions for additional information.

Pre-connect all needed cables to the

PSU before installing it into the chassis.

See step 2

PRO TIP

AMP Model Output Watts

GH 1200 Up to 600

GH 1000 Up to 600

GH 850 Up to 450

GH 750 Up to 450

GH 650 Not available

12VHPWR

12+4-PIN CABLE

12VHPWR

12+4-PIN

MOLEXSATAPCIe

6+2-PIN

CPU

4+4-PIN

MOTHERBOARD

24-PIN

PSU

PSU SCREW

INSTALL

MOTHERBOARD

10+18-PIN

CPU |PCIe

8-PIN

12VHPWR

12+4-PIN

SATA |MOLEX

6-PIN
