PEUGEOT 206 Manual de usuario

YOUR 206 AT A GLANCE

17-06-2002

YOUR 206 AT A GLANCE

1Side window demisting vents

2Adjustable side vent

3Passenger air bag

4Windscreen demisting vents

5Multifunction display

6Central locking switch

7Hazard warning lights switch

8Instrument dials lighting

rheostat

9Lights and direction

indicators stalk

10 Steering wheel height

adjustment control

11 Steering lock

12 Windscreen wiper stalk

13 Driver's air bag

Horn

14 Audio equipment remote

control

15 Headlamp height adjustment

16 Passenger air bag disarming

switch*

17 Rear window locking switch

18 Storage compartment

19 Fuse box

20 Gear lever

21 Lighter

22 Alarm button

23 Front electric window

switches

24 Electric mirrors switch

25 Handbrake

26 Front ashtray

27 Controls for heating,

ventilation, air conditioning

and heated rear screen

and mirrors

28 Audio equipment

29 Adjustable centre vents

30 Glove box

31 Bonnet opening control

* According to destination.

17-06-2002

YOUR 206 AT A GLANCE

KEYS

The keys enable you to switch on

the ignition, independently ope-

rate the locks on the front doors

and the tailgate (saloon) as well

as operating the passenger air

bag disarming switch and the

fuel filler flap.

Central locking

From the driver's door, you can

lock and unlock the doors and

the boot.

If one of the doors, the boot

(206 SW) or the rear screen

(206 SW) is open, the central

locking will not work.

Remote control

Pressing button Ato remotely

lock the vehicle.

This is confirmed by fixed lighting

of the direction indicators for

approximately two seconds.

Pressing button Bto remotely

unlock the vehicle.

This is confirmed by rapid fla-

shing of the direction indicators

for approximately two seconds.

206 SW : press and hold button

Bto unlock the vehicle and open

the rear screen.

Leaving the ignition key in

If you leave the key in the igni-

tion, a buzzer reminds you of this

when opening the driver's door.

Locating the vehicle

To locate your vehicle, when you

have left it locked in a car park:

☞press button A, the courtesy

lights will switch on and the

indicator lights flash for a few

seconds.

STARTING

The 4 positions of the key in

the ignition:

STOP position: The ignition is

off.

1st notch, Accessories posi-

tion: The ignition is off but the

accessories can be used.

2nd notch, Running position:

The ignition is on.

Starting position: Operates the

starter.

Steering lock

Before starting, unlock the stee-

ring if necessary, by gently tur-

ning the steering wheel at the

same time as you turn the key.

It is advisable to press the clutch

pedal while operating the starter

to make starting easier.

17-06-2002

YOUR 206 AT A GLANCE

KEYS

The keys enable you to switch on

the ignition, independently ope-

rate the locks on the front doors

and the tailgate (saloon) as well

as operating the passenger air

bag disarming switch and the

fuel filler flap.

Central locking

From the driver's door, you can

lock and unlock the doors and

the boot.

If one of the doors, the boot

(206 SW) or the rear screen

(206 SW) is open, the central

locking will not work.

Remote control

Pressing button Ato remotely

lock the vehicle.

This is confirmed by fixed lighting

of the direction indicators for

approximately two seconds.

Pressing button Bto remotely

unlock the vehicle.

This is confirmed by rapid fla-

shing of the direction indicators

for approximately two seconds.

206 SW : press and hold button

Bto unlock the vehicle and open

the rear screen.

Leaving the ignition key in

If you leave the key in the igni-

tion, a buzzer reminds you of this

when opening the driver's door.

Locating the vehicle

To locate your vehicle, when you

have left it locked in a car park:

☞press button A, the courtesy

lights will switch on and the

indicator lights flash for a few

seconds.

STARTING

The 4 positions of the key in

the ignition:

STOP position: The ignition is

off.

1st notch, Accessories posi-

tion: The ignition is off but the

accessories can be used.

2nd notch, Running position:

The ignition is on.

Starting position: Operates the

starter.

Steering lock

Before starting, unlock the stee-

ring if necessary, by gently tur-

ning the steering wheel at the

same time as you turn the key.

It is advisable to press the clutch

pedal while operating the starter

to make starting easier.

17-06-2002

107

YOUR 206 AT A GLANCE

Never race a cold

engine.

Never run the engine

in a confined space.

Do not make any modifications

to the steering lock.

Starting a petrol engine

Do not press the accelerator.

Operate the starter, without

releasing the key, until the engi-

ne turns.

Starting a diesel

engine

Do not press the acce-

lerator.

Turn the key to the ''Running''

position.

If the engine is warm enough,

the pre-heat light does not come

on and you can start immediately.

If the pre-heat light comes on,

wait for it to go out before opera-

ting the starter.

If the engine stalls, it is necessa-

ry to return the key to the

''STOP'' position before restar-

ting.

FRONT AIR BAGS

Precautions regarding the

passenger air bag

For a vehicle fitted with a disar-

ming switch : – disarm the

air bag if

you install a

rear-facing

child seat,

– arm the air

bag for an

adult pas-

senger.

For a vehicle not fitted with a

disarming switch:

– do not ins-

tall a rear-

facing child

seat on the

front pas-

senger seat.

In no circumstances should you

place your feet or any other

object on the fascia.

Operating check

* According to destination.

Disarming the passenger

air bag*

Insert the ignition key in the switch

1and turn it to:

– the ''ON'' position, the passen-

ger air bag is armed,

– the ''OFF'' position, the pas-

senger air bag is disarmed.

With the ignition on (2nd notch

of the ignition), illumination of

this warning light, accompanied

by an audible signal and the

message "Passenger air bag

disarmed" on the multi-function

display, indicates that the

passenger air bag is disarmed

(switch in the "OFF" position).

The warning light remains on

throughout the disarming process.

17-06-2002

89 91

YOUR 206 AT A GLANCE

STEERING WHEEL

CONTROLS

Lights

Front and rear lights (ring A)

Lights off

Side lights

Dipped / main

beam

headlamps

Automatic

switching on

of lights

Automatic switching on of lights

To activate or deactivate the

function, place the key in the

accessories position, with the

lights stalk in position 0and

press the end of the stalk for

more than four seconds.

Rear fog lamp (ring B)

Rear fog lamp

(rotation of the ring

forwards)

Front fog lamps / Rear fog lamp

(ring C)

Front fog lamps

(1st rotation of the ring

forwards)

Front fog lamps

and rear fog lamp

(2nd rotation of the

ring forwards)

Windscreen wipers

Front

2Fast wipe

1Normal wipe

IIntermittent wipe

AUTO Automatic wipe

0Off

Single wipe

Wash-wipe: pull the stalk

towards you.

Rear

Off Intermittent

wipe

Automatic wipe

In the AUTO position,

the windscreen wiper

operates automatically

and adjusts its speed

to the intensity of the

rainfall.

Wash-

wipe

17-06-2002

YOUR 206 AT A GLANCE

SEATS

Fold-down seat back

(all models)

– Remove the head restraint,

– Tilt the modifiable seat,

– Push one of the handles 1

towards the rear to fold down

the seat back until it is in a hori-

zontal position.

Modifiable passenger seat

Storage compartment

– Push the seat as far back as

possible,

– Raise then pull the front of the

seat to unlock it, then tilt the

modifiable seat.

3-door version

only.

17-06-2002

7675

YOUR 206 AT A GLANCE

Rear seats

➜Lift the front of the seat cushion 1,

➜Tilt the seat cushion 1against the front seats,

➜Position the seat belt under the belt holder 2,

➜Pull control 3to unlock the seat back 4,

➜Remove or lower the head restraint,

➜Tilt the seat back 4.

When refitting, take care not to trap the seat belts.

Removing the modifiable

front passenger seat

➜Push the seat as far back as

possible,

➜Raise then pull the front of the

seat to unlock it,

➜Tilt the seat,

➜By pulling upwards, tilt the

seat from left to right to make

it easier to remove.

17-06-2002

7675

YOUR 206 AT A GLANCE

Rear seats

➜Lift the front of the seat cushion 1,

➜Tilt the seat cushion 1against the front seats,

➜Position the seat belt under the belt holder 2,

➜Pull control 3to unlock the seat back 4,

➜Remove or lower the head restraint,

➜Tilt the seat back 4.

When refitting, take care not to trap the seat belts.

Removing the modifiable

front passenger seat

➜Push the seat as far back as

possible,

➜Raise then pull the front of the

seat to unlock it,

➜Tilt the seat,

➜By pulling upwards, tilt the

seat from left to right to make

it easier to remove.

17-06-2002

107

YOUR 206 AT A GLANCE

Never race a cold

engine.

Never run the engine

in a confined space.

Do not make any modifications

to the steering lock.

Starting a petrol engine

Do not press the accelerator.

Operate the starter, without

releasing the key, until the engi-

ne turns.

Starting a diesel

engine

Do not press the acce-

lerator.

Turn the key to the ''Running''

position.

If the engine is warm enough,

the pre-heat light does not come

on and you can start immediately.

If the pre-heat light comes on,

wait for it to go out before opera-

ting the starter.

If the engine stalls, it is necessa-

ry to return the key to the

''STOP'' position before restar-

ting.

FRONT AIR BAGS

Precautions regarding the

passenger air bag

For a vehicle fitted with a disar-

ming switch : – disarm the

air bag if

you install a

rear-facing

child seat,

– arm the air

bag for an

adult pas-

senger.

For a vehicle not fitted with a

disarming switch:

– do not ins-

tall a rear-

facing child

seat on the

front pas-

senger seat.

In no circumstances should you

place your feet or any other

object on the fascia.

Operating check

* According to destination.

Disarming the passenger

air bag*

Insert the ignition key in the switch

1and turn it to:

– the ''ON'' position, the passen-

ger air bag is armed,

– the ''OFF'' position, the pas-

senger air bag is disarmed.

With the ignition on (2nd notch

of the ignition), illumination of

this warning light, accompanied

by an audible signal and the

message "Passenger air bag

disarmed" on the multi-function

display, indicates that the

passenger air bag is disarmed

(switch in the "OFF" position).

The warning light remains on

throughout the disarming process.

17-06-2002

Otros manuales para 206

Tabla de contenidos

Otros manuales de Automóvil de PEUGEOT

PEUGEOT

PEUGEOT 308 2008 Manual de usuario

PEUGEOT

PEUGEOT 508 Manual de usuario

PEUGEOT

PEUGEOT Facelift 2008 Manual de usuario

PEUGEOT

PEUGEOT RCZ Manual de usuario

PEUGEOT

PEUGEOT traveller Manual de usuario

PEUGEOT

PEUGEOT RCZ Manual de usuario

PEUGEOT

PEUGEOT 508 Manual de usuario

PEUGEOT

PEUGEOT 407 Manual de usuario

PEUGEOT

PEUGEOT 207 CC 2014 Manual de usuario

PEUGEOT

PEUGEOT 207 CC Manual de usuario

PEUGEOT

PEUGEOT 206 Guía de inicio rápido

PEUGEOT

PEUGEOT 2008 Manual de usuario

PEUGEOT

PEUGEOT 3008 HYbrif4 Manual de usuario

PEUGEOT

PEUGEOT 308 SW Manual de usuario

PEUGEOT

PEUGEOT 308 CC Manual de usuario

PEUGEOT

PEUGEOT 508 Manual de usuario

PEUGEOT

PEUGEOT 3008 2017 Manual de usuario

PEUGEOT

PEUGEOT Expert Manual de usuario

PEUGEOT

PEUGEOT 307 SW 2004 Manual de usuario

PEUGEOT

PEUGEOT 206 Manual de usuario

PEUGEOT

PEUGEOT 3008 2015 Manual de usuario

PEUGEOT

PEUGEOT 407 2009 Manual de usuario

PEUGEOT

PEUGEOT 3008 2024 Manual de usuario

PEUGEOT

PEUGEOT 807 Manual de usuario

Manuales populares de Automóvil de otras marcas

Toyota

Toyota 2000 Tundra Manual de usuario

CITROËN

CITROËN DS4 DSign Manual de usuario

Lexus

Lexus 2015 CT 200h Manual de usuario

Cadillac

Cadillac CTS 2008 Manual de usuario

Mercedes-Benz

Mercedes-Benz M-class ML 55 AMG Manual de usuario

Porsche

Porsche Boxster S Manual de usuario

GMC

GMC 2010 Savana 1500 Cargo Manual de usuario

KIAM

KIAM SPORTAGE 2014 Manual de lista de piezas

GMC

GMC 2013 Terrain Instrucciones de montaje

GMC

GMC T-Series 1999 Manual de usuario

Mercury

Mercury 1998 Mystique Manual de usuario

Mercury

Mercury 2007 Mariner Manual de usuario

Mazda

Mazda 2007 Mazdaspeed 3 Guía

Mazda

Mazda 2014 CX-5 Manual de usuario

GMC

GMC Chevrolet Express 2022 Manual de usuario

GMC

GMC 1997 Jimmy Manual de usuario

Chevrolet

Chevrolet 2012 Malibu Manual de usuario

Cadillac

Cadillac 2010 Escalade Manual de usuario
