PEUGEOT 207 CC Manual de usuario
Handbook
AP_207_CC_01_2010_anglais_cag_pdcouv1 couv1
AP_207_CC_01_2010_anglais_cag_pdcouv1 couv1
03/02/2010 07:34:06
03/02/2010 07:34:06
4
FAMILIARISATION
EXTERIOR
Retractable roof
This system enables you to change the
vehicle from "coupé" to "cabriolet" con-
¿guration and vice versa with a single
action.
6
Static directional lighting
This additional lighting automatically
provides extended visibility when
turning.
80
Visual and audible rear parking
sensors
This system provides a warning when
reversing by detecting obstacles locat-
ed behind the vehicle.
111
Under-inflation detection
This system monitors the pressure in
each tyre and warns you of a punc-
ture or drop in pressure.
92
Turbulence prevention net
(Windstop)
In "cabriolet" con¿guration, this
system reduces the wind turbu-
lence in the front seats.
60
Temporary tyre repair kit
This kit is a complete system, con-
sisting of a compressor and an inte-
gral sealant, for the temporary repair
of a tyre.
120
AP_207_CC_01_2010_anglais_cag_pd4 4
AP_207_CC_01_2010_anglais_cag_pd4 4
03/02/2010 07:34:18
03/02/2010 07:34:18
ii
5
FAMILIARISATION
OPENING
Remote control key
A. Unfolding/Folding the key.
B. Unlocking the vehicle.
C. Unlocking and partially opening the
boot.
63
Also...
D. Normal locking
or
Deadlocking of the vehicle.
Fuel tank
1. Opening the fuel ¿ller Àap.
2. Opening and hooking the fuel ¿ller
cap.
Capacity of the tank : approximately
50 litres (petrol) or 48 litres (Diesel).
75
Boot
From outside
From inside
1. Unlocking the complete vehicle or
unlocking the boot and the vehicle.
2. Opening the boot lid.
1. Key in the ignition switch.
2. Unlocking using the manual cen-
tralised control or the door opening
control.
74
On Diesel vehicles, the fuel tank
opening incorporates a misfuel
prevention device which prevents
¿lling with petrol.
76
AP_207_CC_01_2010_anglais_cag_pd5 5
AP_207_CC_01_2010_anglais_cag_pd5 5
03/02/2010 07:34:20
03/02/2010 07:34:20
!! i
6
FAMILIARISATION
OPENING
Retractable roof
When washing your vehicle:
- lock the vehicle,
- avoid spraying the upper part
of the windows,
- keep the end of the high-pres-
sure nozzle at least 1 metre
from the windows and door
seals.
After washing the vehicle or fol-
lowing rain, wait until the roof has
dried before opening it.
The roof is operated under the
sole responsibility of the driver.
During operation of the roof, to
avoid the risk of injury, ensure that
no one is in the vicinity of the mov-
ing parts.
You are strongly advised not to op-
erate the roof in strong winds.
It is preferable to operate the roof
with the engine running.
The roof can be operated at
speeds below 6 mph (10 km/h).
It is only possible to carry out the
operation twice with the engine off,
to avoid discharging the battery.
Preliminary conditions
)Switch on the ignition.
)Ensure that:
- the vehicle is not in energy econo-
my mode (refer to the correspond-
ing section),
- the battery voltage is suf¿cient
(switching on of the indicator lamp
on the roof control),
- the roof fuse is in good condition (re-
fer to the corresponding section),
- the electric windows are initialised
(refer to the corresponding section),
- the ambient temperature is above
-15 °C.
Precautions to be taken before
operating the roof
)Park the vehicle on level ground.
)Check that no object could hinder
the operation of the roof:
- nothing should be placed on the
moving rear shelf 1or on the net 2.
- if luggage is being carried in the
boot, it must not raise the net,
)Ensure that the net 2is secure.
)Close the boot correctly.
Maintenance
Carry out a complete opening
and closing operation of the roof
at least once a month to keep it in
good working order.
AP_207_CC_01_2010_anglais_cag_pd6 6
AP_207_CC_01_2010_anglais_cag_pd6 6
03/02/2010 07:34:22
03/02/2010 07:34:22
!i
!
7
FAMILIARISATION
OPENING
Retractable roof operation
Opening the roof
)Pull this control until the roof
is fully open.
Closing the roof
)Press this control until the
roof is fully closed.
The end of the operation is con-
¿rmed by an audible signal and
a message on the multifunction
screen.
Do not release the roof control
during operation of the roof.
However, in the event of danger,
release the control, the roof stops;
then, when the danger is no lon-
ger present, complete the required
operation.
If the operation has not completely
¿nished, you will be warned by an
audible signal and a message on
the multifunction screen. These
will be repeated as the vehicle
passes a number of speed thresh-
olds.
Changing to "cabriolet"
con¿guration:
- the four windows lower,
- the boot opens,
- the roof folds into the boot,
- the boot closes.
If you continue to pull or press this
control after the end of the opera-
tion, the four windows rise.
The electric window controls and
the control for the four windows
are deactivated during operation
of the roof.
Theroofelectroniccontrolunitmay
interrupt the operation in progress
as a precaution (for example: door
movement and roof operation in
quick succession). In this case,
release the control then operate
it again to complete the required
operation.
Operating fault
If a malfunction of the roof occurs,
apply the parking brake, switch
off the ignition, restart the engine,
then start the required operation
again.
If the problem persists, contact a
PEUGEOT dealer.
Changing to "coupé" con¿guration:
- the four windows lower,
- the boot opens,
- the roof opens out and locks auto-
matically,
- the boot closes.
The end of the operation is con¿rmed
by an audible signal and a message on
the multifunction screen.
AP_207_CC_01_2010_anglais_cag_pd7 7
AP_207_CC_01_2010_anglais_cag_pd7 7
03/02/2010 07:34:24
03/02/2010 07:34:24
8
FAMILIARISATION
INTERIOR
Dual-zone digital air
conditioning
This system allows different levels of
comfort to be set for the driver and the
front passenger. It then automatically
controls these levels according to the
ambient conditions.
48
Automatic gearbox
This system provides perfect driving
pleasure by combining a fully automatic
mode, associated with two special pro-
grammes, and a manual mode.
104
Audio and communication
systems
These systems bene¿t from the latest
technology: MP3 compatible Peugeot
Connect Sound, Peugeot Connect USB,
Bluetooth hands-free system, Peugeot
Connect Navigation with 16/9 colour
screen, JBL audio system, auxiliary
sockets.
Peugeot Connect Navigation
149
Peugeot Connect Sound
179
Peugeot Connect USB
186
Electric windows
On the driver's side, control of the
electricwindowisautomaticwhen
opening and when closing.
69
AP_207_CC_01_2010_anglais_cag_pd8 8
AP_207_CC_01_2010_anglais_cag_pd8 8
03/02/2010 07:34:26
03/02/2010 07:34:26
9
FAMILIARISATION
INSTRUMENTS AND CONTROLS
1. Cruise control/speed limiter switches.
2. Steering wheel adjustment control.
3. Lighting anddirection indicator control
stalk.
4. Instrument panel.
5. Driver's airbag.
Horn.
6. Gear lever.
7. Parking brake.
8. Retractable roof control.
Control for the four windows.
9. Bonnet release lever.
10.Door mirror controls.
Electric window controls.
11. Fusebox.
12.Headlamp height adjustment.
13.Side adjustable air vent.
14.Door window demisting vent.
15.Speaker (medium tweeter).
16.Windscreen demisting vent.
AP_207_CC_01_2010_anglais_cag_pd9 9
AP_207_CC_01_2010_anglais_cag_pd9 9
03/02/2010 07:34:28
03/02/2010 07:34:28
10
FAMILIARISATION
INSTRUMENTS AND CONTROLS
1. Steering lock and ignition.
2. Audio equipment steering mounted
controls.
3. Wiper/wash-wipe/trip computer control
stalk.
4. Hazard warning lamps switch.
5. Multifunction screen.
Seat belt fastening status warning
lamps.
6. Sunshine sensor.
7. Passenger's airbag.
8. Glove box/Passenger's airbag de-
activation/Audio/video sockets.
9. Heated seat control.
10.12 V accessories socket.
11. USB port.
12.Dynamicstabilitycontrol (ESP/ASR)
button.
Central locking button.
Alarm button.
13.Heating/air conditioning controls.
14.Storage compartment.
15.Audio and telematics system.
16.Central adjustable air vents.
AP_207_CC_01_2010_anglais_cag_pd10 10
AP_207_CC_01_2010_anglais_cag_pd10 10
03/02/2010 07:34:30
03/02/2010 07:34:30
i
!
11
FAMILIARISATION
SITTING COMFORTABLY
Also...
5. Access to the rear seats.
6. Heated seat.
Front seat adjustment Steering wheel adjustment
1. Forwards-backwards adjustment.
2. Height adjustment.
3. Seat back angle adjustment.
4. Head restraint height adjustment.
50
1. Unlocking the control.
2. Adjustment for height and reach.
3. Locking the control.
As a safety precaution, these op-
erations must only be carried out
while stationary.
52
AP_207_CC_01_2010_anglais_cag_pd11 11
AP_207_CC_01_2010_anglais_cag_pd11 11
03/02/2010 07:34:32
03/02/2010 07:34:32
i
12
FAMILIARISATION
SITTING COMFORTABLY
Door mirror adjustment
A. Selecting the mirror.
B. Adjusting the position of the mirror.
C. De-selecting the mirror.
53
Also...
D. Folding/Unfolding.
Rear view mirror adjustment
1. Selecting the "day" position of the
mirror.
2. Adjusting the mirror.
54
Front seat belts
A. Installing the strap.
B. Fastening the buckle.
C. Checking the fastening by pulling
the strap.
95
AP_207_CC_01_2010_anglais_cag_pd12 12
AP_207_CC_01_2010_anglais_cag_pd12 12
03/02/2010 07:34:33
03/02/2010 07:34:33
