Perreaux 6160/P Manual de usuario

6160/P

6160/P6160/P

6160/P

160Wx6 Multi-Channel Power

Amplifier

Owners Manual

Perreaux Industries Limited makes no warranty for the use of its products, other than those

expressly contained in the warranty detailed herein. The Company assumes no responsibility for

any errors which may appear in this document, reserves the right to change products or

specifications detailed herein at any time without notice, and does not make any commitment to

update the information contained herein. No licenses to patents or other intellectual property of

Perreaux are granted by the Company in connection with the sale of Perreaux products, expressly or

by implication.

PERREAUX®is a registered trademark of Perreaux Industries Ltd.

Terms and product names in this document may be trademarks of others.

This page has intentionally been left blank.

iiiIntroducing the Perreaux

6160 Power Amplifier

Congratulations on your Perreaux 6160 purchase. To realise the full potential o

your unit you need to appreciate all aspects of its operation.

Before installing the 6160 into your system, read the entire manual carefully.

Endeavor to understand every detail by familiarising yourself with the controls

and features as you read. You will find it easier to install using the relevan

sections of this manual as a reference.

We have attempted to explain every feature and operational facet clearly an

concisely. Your Perreaux dealer will be happy to assist if you encounter an

unforeseen problems.

Read this manual, install your unit correctly and realise the sonic significance o

your investment in Perreaux.

Perreaux products are designed to provide the utmost in sonic realism an

electronic reliability with a functional yet elegant appearance that reflects th

care and craftsmanship applied during all stages of construction.

Features at a

Glance

àRugged build quality

àUltra-stiff power supply

àSoft-Start circuit

àHybrid Class A/AB output stages

àMOSFET output devices

àHighly powered

àClipping indicators

àBridgeable outputs

àRemote trigger input and output

àMultiple protection systems

àAdvanced PCB design and earthing techniques

àEarth isolation switch

To maintain the consistently high quality that you expect from us, and we expec

from ourselves, Perreaux products are essentially handcrafted.

We maintain the human-link throughout, from design and construction, throug

to the ultimate test, your music, your system, your ears.

Because we too listen to our products, we know that with your Perreaux you wil

discover many more of the musical secrets we strive to reveal.

Note: All references to the 6160 Classic series are also applicable to the 6160

P-Series product.

From all of us at Perreaux Industries Limited, thank you for choosing th

Perreaux Reference Series 6160 power amplifier.

iiii

ii Important Safety Instructions

Note: All safety and operating instructions should be read carefully before th

6160 is used. Keep the Owners Manual in a safe place for futur

reference.

àThe 6160 should not be used near water, for example near a bathtub,

kitchen sink, in a wet basement, near a swimming pool, etc.

àThe 6160 should be rack mounted only in a heavy-duty rack or stand

that is recommended for audio equipment use.

àMounting to a wall or ceiling should be via a heavy-duty bracket or shelf

designed for audio equipment use.

àThe 6160 should be situated away from heat sources such as radiators,

stoves, or other appliances that produce excessive amounts of heat.

àAlways ensure the 6160 heat sinks have adequate ventilation enabling

air circulation both above and below.

àDO NOT place the 6160 directly onto carpeted surfaces.

àAvoid exposing the 6160 to extremely high or low temperatures.

àThe 6160 should be connected to a mains power supply only of the type

described in the operating instructions, or as marked on the rear of the

unit.

àDO NOT disconnect the mains earth from the system.

àThe mains power supply cord should be routed so that it is not likely to

be walked on or pinched by items placed on or against it.

àThe power cord of the 6160 should be unplugged from the mains outlet

when the unit is to be left unused for long periods or when attempting to

connect or disconnect cables and before cleaning your unit.

àCare should be taken so that objects and/or liquids do not accidentally

fall inside the 6160.

àPlease keep electrical equipment out of reach of children.

àPlease unplug sensitive electronic equipment during electrical storms.

àPlease replace any fuse with the value and type specified.

àAvoid operating the 6160 with the cover removed.

àDO NOT bypass any fuse.

àDO NOT attempt to repair the 6160. In the event of a problem, please

contact your Perreaux dealer.

àDO NOT operate this product in an explosive atmosphere.

Caution! The 6160 is an extremely high powered, convection cooled amplifier.

The finned outer heat sinks may become very hot when delivering high

volume levels – to avoid injury; care should be taken not to touch th

heat sinks during operation.

iii

iiiiii

iii Table of Contents

iIntroducing the Perreaux 6160 Power Amplifier .................................................. 3

iiii

ii Important Safety Instructions.................................................................................... 4

iii

iiiiii

iii Table of Contents......................................................................................................... 6

1Unpacking and Placement......................................................................................... 7

2Instant Install................................................................................................................9

3Front Panel Functions............................................................................................... 11

4Rear Panel Functions ................................................................................................ 13

5Bridging Channels..................................................................................................... 17

6Special Design Philosophies .................................................................................... 19

7Special Design Features............................................................................................ 21

8Maximising System Potential................................................................................... 23

9The Power MOSFET................................................................................................... 25

1010

10 Care and Maintainance ............................................................................................ 28

1111

11 Warranty Information and Obtaining Service ..................................................... 29

1212

12 Extended Warranty Registration Form ................................................................. 30

1313

13 Faultfinding Your System ......................................................................................... 31

1414

14 Specifications.............................................................................................................. 36

1515

15 Physical Dimensions.................................................................................................. 39

1616

16 Contact Details........................................................................................................... 40

1Unpacking and Placement

The 6160 is packaged for maximum protection. Please carefully read th

instructions below before proceeding to unpack the unit. Be extremely careful.

Unpacking

Procedure

à Inspect both ends of the cardboard box and open at the end without the

central staple by slitting the reinforced tape at either side.

à Fold back the flaps and tip the package on end and the inner box will

slide out.

à Lay the inner box down flat and upright, open it conventionally by

separating the top tray from the bottom.

à The product can now be removed from the bottom packaging. This will

be easier if you have someone to help you by holding the base of the

box.

à Alternately, the bottom tray and amplifier could be tipped upside down

and the bottom packaging removed. If opened in this manner, please

ensure that you turn the contents over again.

Note: Be very careful to secure the unit if you are planning to flip the packag

upside down.

à Remove the two white polystyrene protectors off either side of the

amplifier, leaving the black material covering.

à Pull back the material and remove the protective black tissue from the

front panel.

The amplifier is now unpacked and ready for further installation.

Note: Please retain all packaging material for future transport.

Box

Contents

1 x 6160 Power amplifier

1 x 6160 Product manual

1 x Detachable AC power cord

Placing

Your 6160

The 6160 should generally be placed close to your preamplifier, keeping th

interconnect cabling short.

We strongly recommend keeping the 6160 on it’s own separate shelf to allow fo

proper ventilation.

Ventilation

Requirements

The 6160 is a high-powered amplifier. For optimal performance, the unit MUS

receive adequate ventilation.

à Please do not install in a sealed cabinet.

à Please do not stack products directly on top of the unit.

à Please do not cover the product with a cloth or similar.

à Please do not mount the 6160 directly onto carpeted surfaces.

à As a “rule of thumb”, allow 80-100mm (3-4 inches) around all sides of

the product and mount the 6160 on a flat surface, ensuring that the unit

has adequate access to free flowing air.

à In the event that the 6160 is to be incorporated into custom cabinetry,

please refer to Chapter 15 “Physical Dimensions”.

Note: Please take all necessary steps to ensure that the unit receives adequat

ventilation

2Instant Install

If you are like us, the first thing you will want to do is to play your favourit

piece of music through your new 6160. The following instructions are written to

enable you to achieve this as quickly as possible. These are not comprehensiv

instructions, but are designed to enable you to play music now!

Note: Please take the time to read the 6160 manual thoroughly as i

incorporates many features, which will enhance its operation.

Placement

The 6160 is a high-power amplifier and best results will be achieved whe

placed on a solid surface with adequate ventilation. DO NOT place on

carpeted floor or cover the amplifier!

Turn off associated components

This minimises the potential to damage any other components when connectin

your 6160 into the system.

Connect preamplifier to 6160

Connect the output of your preamplifier/processor to the inputs at the rear of th

6160 and ensure that the three toggle switches are all set to NORMAL.

Note: Try to keep all interconnect cables as far from loudspeaker cables as

possible and well away from all AC mains leads.

Connect speaker cables to the left and right speaker terminals

We recommend using high quality connectors for your speaker cables, spad

lugs are the preferable option as they combine a larger surface area with th

possibility of a strong mechanical connection; however, high quality banan

terminals are also acceptable.

Note: Be careful to maintain channel integrity, i.e. left to left, right to right, and

phase integrity, positive (+) to positive (+), negative (-) to negative (-).

Switch on preamplifier

Turn on the preamplifier/processor and set the volume to the minimum level.

Select the respective input to which your source component is connected.

Switch on 6160

After checking the supply voltage compatibility with the voltage rating on th

6160 rear panel, insert the power cord-set supplied into the rear of the unit an

into the wall. Switch on the socket at the wall and power up the 6160 using th

switch on the rear panel.

Tabla de contenidos

Otros manuales de Amplificador de Perreaux

Perreaux

Perreaux SP100A Manual de usuario

Perreaux

Perreaux SA80B Manual de usuario

Perreaux

Perreaux PMF2000 Manual de usuario

Perreaux

Perreaux PMF1100 Manual de usuario

Perreaux

Perreaux SX25 Manual de usuario

Perreaux

Perreaux Power amplifier E160 Manual de usuario

Perreaux

Perreaux Model II Manual de usuario

Perreaux

Perreaux 200 MkII Manual de usuario

Perreaux

Perreaux Audiant VP3 Manual de usuario

Perreaux

Perreaux Radiance R200i Manual de usuario

Perreaux

Perreaux Silhouette SXH2 Manual de usuario

Perreaux

Perreaux SX25 Manual de usuario

Perreaux

Perreaux SM6/P Manual de usuario

Perreaux

Perreaux SILHOUETTE SXD2 Manual de usuario

Perreaux

Perreaux SP10 Manual de usuario

Perreaux

Perreaux PMF5550 Manual de usuario

Perreaux

Perreaux Audiant DP32 Manual de usuario

Perreaux

Perreaux SILHOUETTE SXV1 Manual de usuario

Perreaux

Perreaux EP3 Manual de usuario

Perreaux

Perreaux Radiance R200i Manual de usuario

Perreaux

Perreaux SM4 Manual de usuario

Perreaux

Perreaux Prisma 350 Manual de usuario

Perreaux

Perreaux PMF 2150 B Manual de usuario

Perreaux

Perreaux Silhouette SXH2 Manual de usuario

Manuales populares de Amplificador de otras marcas

ASTRO

ASTRO HVO V40 P Manual de usuario

Marantz

Marantz SUPERSCOPE BLA-545 Instrucciones de montaje

NAD

NAD CI980 Manual de usuario

Technics

Technics SE-CH770 Manual de usuario

Harman Kardon

Harman Kardon HK6300 Manual de usuario

NAD

NAD T975 Manual de usuario

McIntosh

McIntosh MA6850 Manual de usuario

Electro-Harmonix

Electro-Harmonix ENGLISH MUFF’N Manual de usuario

Viatron

Viatron Autrix Manual de usuario

GME

GME GA9800 Manual de usuario

Atlas

Atlas CP700 Manual de usuario

Roland

Roland KC-1000 Manual de usuario

Pyle

Pyle PFMRA350BW Manual de usuario

Advantage

Advantage S-250 Manual de usuario

IRT Electronics

IRT Electronics DVA-3007 Manual de usuario

Dimavery

Dimavery BA-100 Series Manual de usuario

Sony

Sony XM-S400D Manual de usuario

Schertler

Schertler ROY X Manual de usuario
