Perfect Prime TC0309 Manual de usuario
Datalogger Thermometer
TC0309
Instruction Manual
CONTENTS
P. 1
................................................................................................ 2
......................................................................................... 2 - 4
.............................................. 5 - 6
........................................................................ 7 - 11
....................................................... 7
.............................................................. 7
............................................................. 7
............................................................................... 7
...................................................................................... 7
..................................................... 8
............................................................................................. 8
......................................................................... 9
........................................................................ 9 - 10
................................................................................... 10
....................................................................... 10
................................................................................. 10
..................................................................................... 11
............................... 12
........................................... 13
1. Introduction
2. Specifications
3. Symbol Definition and Button Location
4. Operation Instructions
4.1 Power-Up & turn ON/OFF backlight
4.2 Connecting the Thermocouples
4.3 Selecting the Temperature Scale
4.4 Data-Hold Operation
4.5 T1-T2 Operation
4.6 Record and Erase memory Operation
4.7 Clock Setup
4.8 Recording Interval Setup
4.9 MAX/MIN Operation
4.10 Auto Power O
4.11 Low Battery Condition
4.12 Calibration Point
4.13 Digital Output
5. Setup TestLink SE-309—RS232 interface software
Appendix: Thermocouple probe specication
1. INTRODUCTION/
2. SPECIFICATIONS
P. 2
TC0309 is a 4-channel digital thermometer for use with K-type thermo-
couple as temperature sensor. Temperature indication follows National
Bureau of Standards and IEC584 temperature/voltage table for K-type
thermocouples. It internal memory can keep up to 16,000 records per
channel. (note1.) It uses RS232 interface to perform bi-directional
communication with PC.
NUMERICAL DISPLAY:
4 digital Liquid Crystal Display per channel.
MEASUREMENT RANGE:
-200°C ~ 1370°C -328°F ~ 2498°F
RESOLUTION:
-200°C~ 200°C 0.1°C; 200°C ~1370°C 1°C
-200°F~ 200°F 0.1°F; else 1°F
INPUT PROTECTION AT THERMOCOUPLE INPUT:
60V DC, or 24Vrms AC
ENVIRONMENTAL:
• Operating Temperature and Humidity: 0°C ~50°C (32°F ~ 122°F) ;
0 ~ 80% RH
• Storage Temperature and Humidity: : -10°C to 60°C (14°F ~
140°F); 0 ~ 80% RH
• Altitude up to 2000 meters.
SPECIFICATIONS
INTRODUCTION
2. SPECIFICATIONS
P. 3
Range
-200°C ~ 200°C
200°C ~ 400°C
400°C~1370°C
-328°F ~ -200°F
-200°F ~ 200°F
200°F ~ 2498°F
Accuracy
±(0.2% reading + 1°C)
±(0.5% reading + 1°C)
±(0.2% reading + 1°C)
±(0.5% reading + 2°F)
±(0.2% reading + 2°F)
±(0.3% reading + 2°F)
ACCURACY: AT 23 ± 5°C
TEMPERATURE COEFFICIENT:
For ambient temperatures from 0°C ~ 18°C and 28°C ~ 50°C, for each
°C ambient below 18°C or above 28°C add the following tolerance
into the accuracy spec.
0.01% of reading + 0.03°C
( 0.01% of reading + 0.06°F )
NOTE:
The basic accuracy Specication does not include the error of the
probe. Please refer to the probe accuracy specication for additional
details.
ELECTROMAGNETIC COMPATIBILITY:
Total accuracy = specied accuracy ±2°C(3.6°F)
SAMPLE RATE:
3 seconds per period
DIMENSION:
184×64×30mm
WEIGHT:
250g Approx
ACCESSORY:
K Type Bead Probe×2, Battery, Carrying Case, Instruction Menu,
Software program, RS-232 Connection Cable.
POWER REQUIREMENT:
9 Volt Battery
BATTERY LIFE:
Approx. 100hrs with alkaline battery
AC ADAPTER:
9VDC ±15% 100mA
PLUG DIAMETER:
3.5mm×1.35mm
OPTION:
AC Adapter, USB Cable.
NOTE:
Every time you press "REC" button to start recording data and press
"REC" button again to stop recording, there will be a data set in
memory, you can store as many data sets as you want until memory
is full.
P. 4
2. SPECIFICATIONS
3. SYMBOL DEFINITION AND BUTTON
LOCATION
P. 5
: This indicates that the minus temperature is sensed.
: Centigrade and Fahrenheit indication.
: Thermocouple Type Indication.
: The Maximum value is now being displayed.
: The Minimum value is now being displayed.
: This indicates auto power o is enabled.
: This indicates that the display data is being held.
: The Battery is not sucient for proper operation.
: It indicates the value below is T1, T2, T3, T4 Temperaturesensor.
: It indicates the value below is T1-T2 sensor.
: This indicates that the tester is recording. If it blinks,
it indicates the memory is full.
°C °F
T1,T2
T3,T4
T2
24V
MAX
60V
T1
T4 T3
3
4
5
2
1
OUTPUT
DC9V
6
7
8
CAL
9
MANUAL FOR SAFETY
OPEN
NEDA 1604 6F22 006P
PLEASE READ
9V BATTERY
HOLD
CF
T1-T2
SETUP
INTV
CLOCK
2498
1370
RANGE
REC
200
328
POWER-UP OPTIONS
F
C
F
C
REC
3. SYMBOL DEFINITION AND BUTTON
LOCATION
P. 6
2
3
4
5
6
7
1
1
2
3
4
5
6
9
12
13
10
11
7
8
K type temperature sensor T1
to T4 input connector
LCD display
ON/OFF & Backlight button
Hold button
Record button
T1-T2 button
MAX MIN function control
button
9
10
11
12
13
8°C, °F control button
Oset calibration screw
Digital output connector
AC power adapter connector
Tripod connector
Battery cabinet cover
4.1 POWERUP & TURN ON/OFF BACKLIGHT
The key turns the Thermometer ON or OFF and backlight ON & OFF.
Press it once to turn on the Thermometer.
Press it again for moment to turn ON or OFF backlight.
Press and hold this button 3 second to turn OFF the power.
4.2 CONNECTING THE THERMOCOUPLES
For measurement, plug the thermocouple into the input connectors.
4.3 SELECTING THE TEMPERATURE SCALE
When the meter was powered on, the user may change it to
Fahrenheit (°F) by pressing“ °C/°F ” button and vice versa to Celsius
4.4 DATAHOLD OPERATION
The user may hold the present reading and keep it on the display by
pressing the“HOLD”button. When the held data is no longer needed,
one may release the data-hold operation by pressing “HOLD” button
again.
When the meter is under Data Hold operation, the“MAX MIN”, “ T1-T2”
and “°C/°F” button are disabled. (when you press“ °C/°F ”, “ T1-T2” and
“MAX MIN” button in HOLD mode, there will be two continuous
beeps).
4.5 T1T2 OPERATION
When this button is pushed,“1 – 2 ” will
be shown on the upper right hand side
LCD display to indicate that the tester is
under T1 minus T2 mode. The tempera-
ture dierence is shown on the right
hand side display as shown in Fig.
4. OPERATION INSTRUCTIONS
P. 7
4.6 RECORD AND ERASE MEMORY OPERATION
When one presses the "REC" button,
the meter will start recording, and
pressing the "REC" button again will
stop recording, If you want to clear the
memory, power o the meter, then
press and hold “REC” button and then
press power button and hold at least 5
seconds, then LCD will show "CLR"
“SURE 5”, then release all buttons to
clear the memory.
4.7 RELATIVE OPERATION
1: press and hold “T1-T2” button and then
power on the meter:
2: press “HOLD”(clock):
3: press "REC" ▲or "°C/°F" ▼ to increase or
decrease number, press “HOLD”(clock) to
adjust next item. The adjusting order is year
→month→day→hour→minute, then press
“HOLD” (clock) to nish adjusting. If you want
abort during a setup process, press power
button to cancel.
4. OPERATION INSTRUCTIONS
P. 8
4.8 RECORDING INTERVAL SETUP
1: press and hold “T1-T2” button and then
power on the meter:
2: press “MAXMIN"(INTV)
3: press "REC" ▲or "°C/°F" ▼to increase or
decrease number, press “MAXMIN " (INTV) to
adjust next item, then press “MAXMIN” (INTV)
to nish. If you want abort during a setup
process, press power button to cancel.
4.9 MAX/MIN OPERATION
When pressing the "MAX MIN" button the meter will enter the
MAX/MIN mode. Under this mode the maximum value, minimum
value is kept in the memory simultaneously and updated with every
new sample of data.
When the MAX symbol is display, the Maximum is shown on the
display.
Press "MAX MIN" again, then the MIN symbol is on the display and
also the minimum reading.
Press "MAX MIN" again, MAX, and MIN will blink together. This
means that all these data is updated in the memory and the reading
is the present temperature.
One may press "MAX MIN" to circulate the display mode among
these options.
When the meter is under "MAX MIN" operation and “ °C/°F ” button
are disabled.(when you press “ C/°F ” button in "MAX MIN" mode,
there will be two continuous beep).
4. OPERATION INSTRUCTIONS
P. 9
