Pepperl+Fuchs NVO5-111 Manual de usuario
ISO9001
NVO5-111
WARNING DEVICE
WARNANLAGE
RELAIS D'ALARME
ALARMRELÆ
EN
DE
FR
DA
PROCESS AUTOMATION
MANUAL
With regard to the supply of products, the current issue of the following docu-
ment is applicable: The General Terms of Delivery for Products and Services of
the Electrical Industry, published by the Central Association of the Electrical In-
dustry (Zentralverband Elektrotechnik und Elektroindustrie (ZVEI) e.V.) in its
most recent version as well as the supplementary clause: "Expanded reserva-
tion of proprietorship"
Es gelten die Allgemeinen Lieferbedingungen für Erzeugnisse und Leistungen
der Elektroindustrie, herausgegeben vom Zentralverband Elektroindustrie
(ZVEI) e.V. in ihrer neusten Fassung sowie die Ergänzungsklausel: "Erweiterter
Eigentumsvorbehalt".
Les conditions de vente générales pour les produits et les services de l'industrie
des équipements électriques publiées par la Fédération de l'industrie électron-
ique (ZVEI) s'appliquent dans leur toute dernière version, tout comme la clause
complémentaire "Réserve de propriété élargie".
De almene leveringsbetingelser for produkter og ydelser fra elektronikindustrien,
der er udgivet af Zentralverband Elektroindustrie (ZVEI) e.V. i den seneste ud-
gave samt tillægsklasulen: "Udvidet ejendomforbehold" er gældende".
EN
DE
FR
DA
Warning Device NVO5-111
Warning Device NVO5-111
Contents
233953 2012-04
EN - 1
EN
1 Safety................................................................................... 2
1.1 Validity ..........................................................................................................2
1.2 Target Group/Personnel ................................................................................2
1.3 Reference to further documentation..............................................................2
1.4 Symbols used ...............................................................................................3
1.5 Marking.........................................................................................................3
1.6 Intended Use ................................................................................................4
1.7 Improper Use ................................................................................................4
1.8 Mounting/Installation.....................................................................................4
1.9 Operation, Maintenance, Repair ...................................................................5
1.10 Delivery, Transport, Disposal.........................................................................5
2 Product Specifications....................................................... 6
2.1 Function........................................................................................................6
2.2 Components .................................................................................................7
2.3 Design and Dimensions................................................................................8
3 Installation........................................................................... 9
3.1 Mounting the Sensors...................................................................................9
3.2 Mounting the Warning Device .....................................................................10
3.3 Connecting the Warning Device..................................................................11
4 Commissioning................................................................. 14
4.1 Configuring the Warning Device using DIP Switches ..................................14
5 Operation........................................................................... 16
5.1 Alarm Signals..............................................................................................16
5.2 Resetting the Alarm Signal..........................................................................17
5.3 Function Testing..........................................................................................18
6 Troubleshooting................................................................ 19
6.1 Troubleshooting and Alarm Statuses...........................................................19
6.2 Maintaining the Alarm System.....................................................................20
7 Technical specifications .................................................. 21
7.1 Warning Device NVO5-111.........................................................................21
233953 2012-04
2 - EN
Warning Device NVO5-111
Safety
EN
1Safety
1.1 Validity
The chapter “Safety”is valid as instruction manual.
Specific processes and instructions in this document require special precautions
to guarantee the safety of the operating personnel.
1.2 Target Group/Personnel
The plant owner is responsible for its planning, installation, commissioning,
operation, maintenance and disassembly.
Mounting, installation, commissioning, operation, maintenance and disassembly
of any devices may only be carried out by trained, qualified personnel.
The instruction manual must be read and understood.
1.3 Reference to further documentation
Laws, standards, or directives applicable to the intended use must be observed.
In relation to hazardous areas, Directive 1999/92/EC must be observed.
The corresponding data sheets, declarations of conformity, EC Type-examination
certificates, certificates and Control Drawings if applicable (see data sheet) are an
integral part of this document. You can find this information under
www.pepperl-fuchs.com.
Due to constant revisions, documentation is subject to permanent change. Please
refer only to the most up-to-date version, which can be found under
www.pepperl-fuchs.com.
Warning Device NVO5-111
Safety
233953 2012-04
EN - 3
EN
1.4 Symbols used
This document contains information that you must read for your own personal
safety and to avoid property damage. Depending on the hazard category, the
warning signs are displayed in descending order as follows:
Safety-relevant symbols
Informative symbols
Action
This symbol indicates a paragraph with instructions.
1.5 Marking
Danger!
This symbol indicates a warning about an immediate possible danger.
In case of ignoring the consequences may range from personal injury to death.
Warning!
This symbol indicates a warning about a possible fault or danger.
In case of ignoring the consequences may cause personal injury or heaviest
property damage.
Caution!
This symbol indicates a warning about a possible fault.
In case of ignoring the devices and any connected facilities or systems may be
interrupted or fail completely.
Note!
This symbol brings important information to your attention.
Warning device
Pepperl+Fuchs GmbH
Lilienthalstrasse 200, 68307 Mannheim, Germany
NVO5-111
BVS 09 ATEX E 137
¬II (1)G [Ex ia] IIB
233953 2012-04
4 - EN
Warning Device NVO5-111
Safety
EN
1.6 Intended Use
The warning device is component of an alarm system. The warning device is
suitable for the monitoring of a sensor in the Zone 0 hazardous area of containers,
tanks or double-walled pipes.
The warning device must only be installed in a suitable control cabinet or
NVO5-KV installation housing.
Only one the following sensors must be connected to the warning device:
NVF-104/34-PF overflow sensor
NVFRH-125E overflow sensor
NVF-12* overflow sensor
KVF-103-PF oil level sensor
ON/OFF switch, customer-side
The devices are only approved for appropriate and intended use. Ignoring these
instructions will void any warranty and absolve the manufacturer from any liability.
The device must only be operated in the ambient temperature range and at the
relative humidity (non-condensing) specified.
1.7 Improper Use
Protection of the operating personnel and the overall system is not ensured if the
product is not being used according to its intended purpose.
The equipment is not suitable for isolating signals in high current applications
unless this is noted separately in the corresponding datasheet.
1.8 Mounting/Installation
Prior to mounting, installation, and commissioning of the device you should make
yourself familiar with the device and carefully read the instruction manual.
The device must be disconnected from the power supply prior to installation and
maintenance. The power supply may be activated only after all the circuits
required for operation have been fully assembled and connected.
The devices must be installed outside of the hazardous area.
The device must not be installed at locations where corrosive vapors may be
present.
The devices fulfill a degree of protection IP20 according to IEC/EN 60529.
The devices are designed for use in pollution degree 2 and overvoltage
category III as per IEC/EN 60664-1.
Warning Device NVO5-111
Safety
233953 2012-04
EN - 5
EN
The installation instructions in accordance with IEC/EN 60079-14 must be
observed.
Circuits of type of protection "Ex i" (intrinsically safe) which have been operated
with circuits of other type of protections must not be used as "Ex i" circuits
afterwards.
Intrinsically safe circuits of associated apparatus (installed in safe areas) can be
led into hazardous areas, whereby special attention must be paid to maintain
separation distances to all non-intrinsically safe circuits according to the
requirements in IEC/EN 60079-14.
The respective peak values of the field device and the associated apparatus with
regard to explosion protection should be considered when connecting intrinsically
safe field devices with intrinsically safe circuits of associated apparatus
(verification of intrinsic safety). Make sure to observe IEC/EN 60079-14 and
IEC/EN 60079-25.
1.9 Operation, Maintenance, Repair
The devices must not be repaired, changed or manipulated. If there is a defect,
the product must always be replaced with an original device.
1.10 Delivery, Transport, Disposal
Check the packaging and contents for damage.
Check if you have received every item and if the items received are the ones you
ordered.
Keep the original packaging. Always store and transport the device in the original
packaging.
Always store the device in a clean and dry environment. The permitted storage
temperature (see data sheet) must be considered.
Disposing of devices, packaging material, and possibly contained batteries must
be in compliance with the applicable laws and guidelines of the respective
country.
233953 2012-04
6 - EN
Warning Device NVO5-111
Product Specifications
EN
2 Product Specifications
2.1 Function
The warning device is a component of an alarm system. The warning device
monitors the status of a sensor installed in containers, tanks, or double-walled
pipes. The warning device is suitable for use:
As a safeguard to prevent flammable liquids from overflowing or leaking
To detect the oil layer thickness
As a replacement for a faulty NVO5-11 warning device
LEDs at the device indicate alarm, sensor fault and system and sensor status.
In the event of an alarm, an additional acoustic signal sounds.
Input
Only one of the following devices may be connected to the warning device:
NVF-104/34-PF overflow sensor
NVFRH-125E overflow sensor
NVF-12* overflow sensor
KVF-103-PF oil level sensor
ON/OFF switch, customer-side
ON/OFF switches may be:
Floating switches
Reed contacts
Mechanical switches
The ON/OFF switch sends an input signal to the warning device:
0Ω= closed
∝Ω= open
Output
If required, you can connect a remote alarm or a central monitoring system to the
volt-free relay contacts on the outputs.
Connect a central monitoring system to the alarm relay.
Connect a remote alarm, for example a sounder, to the signal relay.
Warning Device NVO5-111
Product Specifications
233953 2012-04
EN - 7
EN
2.2 Components
The alarm system can comprise the following components:
Warning device
Sensors
Accessories
Description Type code
Intrinsically safe warning device, 230 VAC NVO5-111
Description Type code
Overflow sensor, for detecting excessively high liquid levels NVF-104/34-PF
Overflow sensor, for detecting excessively high liquid levels
Can no longer be delivered. NVFRH-125E
Overflow sensor, for detecting excessively high liquid levels
Can no longer be delivered. NVF-12*
Oil level sensor, for detecting the oil layer thickness
Can no longer be delivered. KVF-103-PF
Description Type code
Cable connector for one sensor LAL-SK2
Mounting set for one sensor NVO5-B
Installation housing with DIN mounting rail NVO5-KV
233953 2012-04
8 - EN
Warning Device NVO5-111
Product Specifications
EN
2.3 Design and Dimensions
Figure 2.1
1DIP switches
2LEDs
3Connections for power supply, alarm relay, and signal relay
4Reset button
5Connections for sensor or ON/OFF switches
NV05-111
SUPPLYALARM
RESET SENSOR
FAILURE
ALARMSYSTEM
OK
68301 Mannheim Germany
www.pepperl-fuchs.com
LEVELALARM
70 58
86
54
423
51
Tabla de contenidos
Idiomas:
Otros manuales de Sistema de seguridad de Pepperl+Fuchs
Manuales populares de Sistema de seguridad de otras marcas
EDM
EDM Solution 6+6 Wireless-AE Manual de usuario
Highway Safety Group
Highway Safety Group EA401 Manual de usuario
Siren
Siren LED GSM Manual de usuario
Detection Systems
Detection Systems 7090i Instrucciones de montaje
Se-Kure Controls
Se-Kure Controls MicroMini SK-4841 Manual de usuario
Siemens
Siemens FDM273 Manual de usuario
